4 Mapping User’s Manual Test Program S ITEST Software Version 403.xx Edition 07/97 4 - 2
User’s Manual Test Program SITEST 4 Mapping
Software Version 403.xx Edition 07/97
4 - 1
4 Mapping
WARNING
∆
!
∆
!
The gantries will be moving during the performance of the mapping function described in this section.
Prior to the execution of this function make sure that neither any part of your body nor any objects are in the
traversing range of the gantries - DANGER OF INJURY.
4 Mapping User’s Manual Test Program SITEST
Software Version 403.xx Edition 07/97
4 - 2
User’s Manual Test Program SITEST 4 Mapping
Software Version 403.xx Edition 07/97 4.1 Preparatory Steps for the Mapping Operation
4 - 3
4.1 Preparatory Steps for the Mapping Operation
●
In the main view click on the Overall reference run button to perform a reference run of all gantry and
head axes.
●
Manually slide the PCB stopper to the center of the conveyor width.
●
Place the mapping plate onto the center conveyor.
NOTE
For RV and IC mapping a mapping plate with a dark, dull surface must be used.
In the case of dual conveyors, mapping must be performed for the right and left conveyor tracks.
CAUTION
∆
!
On no account must the PCB clamping mechanism be actuated during PCB mapping
. If the glass map-
ping plate for PCB mapping is clamped, it may be damaged so severely, that it cannot be used any more.
