3.1 Preparation for the Performance of the Calibration
Functions
●
In the main view click on the Overall reference run button to have all gantry and head axes perform a
reference run.
●
Make sure that a type 720 nozzle is attached to all (center) sleeves of the revolver heads, and a type
416 nozzle is attached to the IC head of SIPLACE 80F
4
.
NOTE
When you perform the calibration of the machine, the gantry that is not currently required will auto-
matically be moved to the park position.
●
Place the calibration tool into the "calibration piece pocket" (see Fig. 3.12.1).
NOTE
The calibration tool must be absolutely free of contamination and is to be placed into the "calibration tool
pocket" with the imprint of the fiducial structure facing down.
●
In the main view select the desired gantry by clicking on the corresponding icon.
NOTE
If the calibration activities are performed using the Calibrate machine... function, a selection of the gantry
is not required.
