User’s Manual Test Program SITEST 4 Mapping
Software Version 403.xx Edition 07/97 4.2 PCB Mapping
4 - 7
4.2.1 Mapping Run for Both Gantries (SIPLACE 80S-20)
●
Click on the
PCB mapping both gantries
button.
The mapping run is performed for gantry 1. After the mapping run, gantry 1 is automatically moved to
the park position and subsequently the mapping run for gantry 2 is performed.
After the mapping run has been completed without any errors, the data thus determined is automatically
saved.
●
If a dual conveyor is installed, activate the radio button for the conveyor track for which mapping has
not yet been performed.
●
Click on the
PCB mapping both gantries
button.
The mapping run is performed for both gantries on the selected conveyor track.
After the mapping run has been completed without any errors, the data thus determined is automatically
saved.
●
To review the mapping data for the current conveyor track, click on the
Display mapping data
button.
The data determined is displayed in a dialog box.
●
Close the dialog box by clicking on
OK
.
●
Click on the
Check run
button if you wish to check whether the values determined are correct. The
check run is now started.
●
Click on the
Display check run data
button.
The data determined during the check run is displayed in a dialog box.
●
Close the dialog box by clicking on
OK
.
●
Click on the icon to return to the main view.
4.2.2 Mapping Run for the Second Gantry
●
Click on the
Start
button. The active gantry now performs the mapping run.
●
If a dual conveyor is installed, activate the radio button for the conveyor track for which mapping has
not yet been performed.
●
Click on the
Start
button again.
The active gantry performs the mapping run on the selected conveyor track.
●
Click on the icon to return to the main view.
●
In the main view "SIPLACE 80S-20" click on the icon to switch to the "Gantry 2" display.
CAUTION
∆
!
On no account must the position of the mapping plate(s) be changed when switching from one gantry
to the other.
●
Click on the icon to switch to the "PCB mapping" display.
●
Click on the
Start
button. The mapping run is performed for gantry 2.
After the mapping run has been completed without any errors, the data thus determined is automatically
saved.
4 Mapping User’s Manual Test Program SITEST
4.2 PCB Mapping Software Version 403.xx Edition 07/97
4 - 8
●
If a dual conveyor is installed, activate the radio button for the conveyor track for which mapping has
not yet been performed.
●
Click on the
Start
button again.
Gantry 2 performs the mapping run on the selected conveyor track.
After the mapping run has been completed without any errors, the data thus determined is automatically
saved.
●
Remove the mapping plate(s) for PCB mapping.
●
Click on the icon to return to the main view.
NOTE
PCB mapping can also be performed using the
Calibrate machine...
-->
PCB mapping
function (see
chapt. 3, section 3.2). On SIPLACE 80S-20 machine types, this function is used to perform automatically
the mapping procedure, first for gantry 1 and then for gantry 2.
If a dual conveyor is installed on the machine, mapping is performed first on the right and then on the left
conveyor track.
User’s Manual Test Program SITEST 4 Mapping
Software Version 403.xx Edition 07/97 4.3 RV Mapping
4 - 9
4.3 RV Mapping
NOTE
Prior to the performance of RV mapping make sure that PCB mapping has already been carried out.
●
Carry out the preparatory steps as described in section 4.1.
Additional prerequisites are:
–
Segment offset
II
(RV-PCB camera offset) must already have been determined for both gantries.
–
The calibration tool must be in the calibration tool pocket.
–
The calibration tool position must already have been determined.
–
On segment 1 of each revolver head a type 720 nozzle must be attached.
●
In the main view click on the icon (for revolver head 1 of SIPLACE 80S-20) or on the icon
(for the revolver head of SIPLACE 80F
4
)
to switch the screen display to the "RV head" display
(see Fig. 0.3.4).
●
Click on the icon to switch to the "RV mapping" display.
