6 WF2 SX1/2 Check and clean the X- and Y-Axis magnets. 1.5 min 2 / 2 C A U T I O N ! R e f e r t o s a f e t y i n s t r u c t i o n s i n u s e r m a n u a l b e f o r e c o m m e n c i n g M a i n t e n a n c e Machi…
6 WF2 SX1/2 Check and clean the X- and Y-Axis magnets. 1.5 min 1 / 2
CAUTION! Refer to safety instructions in user manual before commencing Maintenance
Machine Status OFF Transport Empty
NOTICE! ESD guidelines are to be followed Tool:
T3
Wear Part: Consumables:
C3
www.asm-smt.com
1 Move all gantries to the end limit. 2 Check all X-Axis magnets for contamina-
tion and damage.
3 Clean all X-Axis magnets.
4 Move the gantry to the other side. 5 Check all Y-Axis magnets for contamina-
tion and damage.
6 Clean all Y-Axis magnets.
6 WF2 SX1/2 Check and clean the X- and Y-Axis magnets. 1.5 min 2 / 2
CAUTION! Refer to safety instructions in user manual before commencing Maintenance
Machine Status OFF Transport Empty
NOTICE! ESD guidelines are to be followed Tool:
T3
Wear Part: Consumables:
C3
www.asm-smt.com
7 Repeat all steps at the other gantry.
7 WF2 SX1/2 Clean the X-Axis loose bearing, contact surface and scale and replace
the lubrication system.
2.75 min 1 / 3
CAUTION! Refer to safety instructions in user manual before commencing Maintenance
Machine Status OFF Transport Empty
NOTICE! ESD guidelines are to be followed Tool:
T11
Wear Part:
W51
Consumables:
C3, C4, C5, C31
www.asm-smt.com
1 Move all gantries to the end limit. 2 Insert a cloth below the head to catch the
lubrication system in case it drops when
removing it.
3 Unplug the hose from the head (only with
C&P20x).
4 Remove the protection cover (only with
C&P20x).
5 Unscrew the old lubrication system (only
with C&P20x).
6 Unscrew the old lubrication system (only
with CPP).
