21 WF2 SX1/2 Appendix: Calibrate the maintained C&P head 4.5 min 5 / 5
CAUTION! Refer to safety instructions in user manual before commencing Maintenance
Machine Status ON Transport Empty
NOTICE! ESD guidelines are to be followed Tool:
T2, K01
Wear Part: Consumables:
C3
www.asm-smt.com
25 Proceed with task “Check the filter discs of
all C&P20x”.
www.asm-smt.com
22 WF2 SX 1/2 - Appendix: Calibrate the TwinHead 8 min 1 / 9
CAUTION! Refer to safety instructions in user manual before commencing Maintenance
Machine Status ON Conveyor Empty
NOTICE! ESD guidelines are to be followed Tool:
K01
Wear Part: Consumables:
www.asm-smt.com
1 Open the cover. 2 Remove all nozzles from the nozzle
changer.
3 Insert nozzle type 517 into magazine 2
and nozzle type 518 into magazine 3.
4 Insert the calibration tool. 5 Close all covers. 6 Click on "Settings and options".
