15 WF2 SX1/2 Check the anti glare shields of C&P20 A. 3 min 1 / 1
CAUTION! Refer to safety instructions in user manual before commencing Maintenance
Machine Status ON Transport Empty
NOTICE! ESD guidelines are to be followed Tool: Wear Part: Consumables:
www.asm-smt.com
1 Click on "Check anti-glare shields". 2 Check if result OK (green hook). 3 If result is not OK (red cross) contact ser-
vice.
www.asm-smt.com
16 WF2 SX1/2 Endurance run. 4 min 1 / 2
CAUTION! Refer to safety instructions in user manual before commencing Maintenance
Machine Status ON Transport Empty
NOTICE! ESD guidelines are to be followed Tool: Wear Part: Consumables:
www.asm-smt.com
1 Click on "Endurance run after mainten-
ance".
2 Check results. 3 If the result is OK (green hook) proceed
with step 7.
4 If the result is not OK (red cross) save re-
port and contact service.
5 Click on "Generate report". 6 Enter comment and click on "Save".
