xxiv
Safety instructions
3.4 Label positions
Thefollowingwarning/cautionlabelsareattachedtotheYAMAHAproductstoensuresafeandcorrectuse.
Checkthattheinformationoneachlabelisclearlylegibleandcomplywiththeinstructions.
Forsafetyprecautionsotherthanthoseonthelabelsshowninthissection,seetheinstructionsin"1.Safety".
n
NOTE
Basically, labels are attached to the positions shown below, although they may differ slightly depending on the
machine model.
n
NOTE
When connecting power to this equipment, refer to "Power connection terminals" described in the appendix of the
maintenance manual or user's manual.
Warning/caution labels
Front
■ Top of cutter slope
■ Top of cutter slope
■ Open/close cover
(front and rear sides)
■ Open/close cover inner side
(front and rear sides)
■ Open/close cover
(front and rear sides)
■ At panel
■ Feeder setup section
(front and rear sides)
■ Panel inner side
■ Cutter section
■ Cutter section
■ Conveyor opening
(front and rear sides,
right and left sides)
■ Main switch
93201-N5-10
xxv
Safety instructions
n
Label positions
Warning/caution labels
Rear
■ Conveyor opening
(front and rear sides,
right and left sides)
■ Panel inner side
■ Top of cutter slope
■ Top of cutter slope
■ Feeder setup section
(front and rear sides)
■ Open/close cover
(front and rear sides)
■ Open/close cover
(front and rear sides)
■ Open/close cover inner side
(front and rear sides)
■ Cutter section
■ Cutter section
93202-N5-10
