Chapter 3 Periodic maintenance items
Contents
1. Weekly inspection 3-1
1.1 Nozzle inspection 3-1
1.1.1 Buffing area inspection 3-1
1.1.2 Checking the nozzle leaf spring condition 3-2
1.1.3 Replacing nozzle leaf springs 3-3
1.2 Nozzle cleaning 3-8
1.2.1 Cleaning the nozzle buffing area 3-8
1.2.2 Cleaning the nozzle air path (monthly) 3-9
1.2.3 Cleaning the nozzle tip 3-10
1.3 Cleaning the multi-camera lighting's protective cover 3-11
  2
2.1 Rotary unit 3-13
2.1.1 Cleaning the rotary unit 3-13
2.1.2 Cleaning the rotary unit collectively (ultrasonic cleaning) 3-16
2.2 X-axis 3-19
2.2.1 Cleaning and greasing the X-axis ball screw (4-beam type) 3-19
2.2.2 Cleaning and greasing the X-axis ball screw (2-beam type) 3-21
2.2.3 Cleaning and lubricating the X-axis guide (4-beam type) 3-23
2.2.4 Cleaning and lubricating the X-axis guide (2-beam type) 3-25
  7
2.3.1 Cleaning and lubricating the Y-axis guide (4-beam type) 3-27
2.3.2 Cleaning and lubricating the Y-axis guide (2-beam type) 3-29
  0
2.4.1 Board sensors 3-30
2.4.2 Feeder lift sensor 3-30
3. Three-month inspection 3-31
  1
3.1.1 Cleaning and replacing the air filter 3-31
3.2 HS head 3-32
3.2.1 Cleaning and replacing the air filter 3-32
  3
3.3.1 Cleaning and replacing the air filter 3-33
3.3.2 Cleaning and lubricating the spline shaft 3-34
3.3.3 Cleaning and lubricating the ball screw 3-34
3.4 Air intake fan filter 3-35
3.4.1 Cleaning the filters 3-36
4. Six-month inspection 3-37
4.1 Cleaning the camera lighting unit 3-37
4.1.1 Fiducial camera 3-37
4.1.2 Multi-camera 3-38
4.1.3 Side-view camera (multi-camera installed type) 3-39
4.1.4 Side-view camera (HS head) 3-40
  1
  1
5.1.1 Cleaning the spline shaft 3-41
5.2 HS head 3-43
5.2.1 Cleaning and lubricating the ball cage and main shaft 3-43
5.2.2 Cleaning and lubricating the scissors gears 3-44
5.2.3 Cleaning and lubricating the clutch and hook 3-45
5.2.4 Cleaning the switching valve gasket 3-46
  7
5.3.1 Cleaning the spline shaft 3-47
5.3.2 Cleaning and lubricating the scissors gear 3-48
5.4 Conveyor 3-49
5.4.1 Inspecting the conveyor belt and cleaning the guides 3-49
5.4.2 Cleaning and greasing the hexagon spline 3-51
5.5 W-axis 3-52
5.5.1 Cleaning and lubricating the W-axis ball screw 3-52
5.5.2 Cleaning and lubricating the W-axis guide 3-53
5.6 PU axis 3-54
5.6.1 Cleaning and lubricating the PU axis ball screw 3-54
5.7 Controller 3-55
5.7.1 Cleaning the filter 3-55
  6
5.8.1 Cleaning the filter and cup 3-56
3-1
3
Periodic maintenance items
1. Weekly inspection
This section mainly describes weekly inspection and cleaning.
1.1 Nozzle inspection
Afaultybuffingoperation(springaction)cancausepickuperrors.Topreventthis,inspecteachnozzle.
1.1.1 Buffing area inspection
Checkthespringactionofthenozzles.Pressonanozzleandifitreturnsnormallythereisnoproblem.
However,ifthereturnactionispoor(sluggish)thenpickuperrorsandrecognitionerrorswilloccur.
c


tip returns to its original position after being pressed in approximately 1mm.
Checking the nozzle spring action
Example showing type 502A nozzle
Press on the nozzle tip with your hand.
Returns to original
position
Returns sluggishly
or does not return.
OK
No good
53300-N5-00
