2.4.2 Lubricating tools and grease
Lubricating and greasing tools
Parts supplied with machine
Lithium-based grease NSL
Nozzle buffing lube supply syringe
Grease gun
Standard nozzle
Flexible type nozzle
Bent type nozzle
GREASE GUN SET
53107-N5-10
n
Lubricating and greasing tools
Partssuppliedwithmachine
Product Name Parts List Designation Parts No. Note
Lithium-based grease GREASE PACK K48-M3856-00X NSL 80g
Low dust-generation lithium grease GREASE PACK KW7-M3851-00X For HS head LG2 80g
Nozzle buffing lube supply syringe SYRING, OIL KV8-M8870-00X Turbine oil VG32
Grease gun (with standard nozzle) GREASE GUN K48-M3852-00X
GREASE GUN SET
KHW-M3852-A0X
Nozzle (flexible type) GREASE NOZZLE K48-M3857-00X
Nozzle (bent type) GREASE NOZZLE K48-M3854-00X
c

The part Nos. given in this manual are the original part Nos. which were assigned to the parts when this manual was

ordering parts.
1-16
1
Maintenance
n
Precautions when handling grease
w
WARNING


w
WARNING


w
WARNING

c



1-17
1
Maintenance
2.4.3 Special tools
Special tools
Optional parts
Nozzle attach/detach tool for HS head
ANC nozzle attach/detach tool for MU head
Nozzle lubrication tool
ANC nozzle attach/detach tool for HS head
Nozzle leaf spring mount tool for HS head
53114-N5-00
n
Special tools
Optionalparts
Product Name Parts List Designation Parts No. Note
Nozzle lubrication tool NOZZLE TOOL OIL KLF-M88MP-00X
Nozzle attach/detach tool for HS head NOZZLE TOOL HS HEAD KLF-M88M1-A0X Dedicated tool for HS head
ANC nozzle attach/detach tool for HS head
NOZZLE TOOL HS ANC KLF-M88M2-A0X Dedicated tool for HS head
ANC nozzle attach/detach tool for MU head
NOZZLE TOOL MU ANC KLF-M88M3-A0X Dedicated tool for MU head
Nozzle leaf spring mount tool for HS head
TOOL LEAF SPRING KLF-M88NB-00X Dedicated tool for HS head
c

The part Nos. given in this manual are the original part Nos. which were assigned to the parts when this manual was

ordering parts.
