1-6 1 Maintenance 2 . 2 M a i n t e n a n c e t o o l s 2 . 2 . 1 C l e a n i n g t o o l s Spline shaft cleaning kit Nozzle cleaning wire Cleaning tools Parts supplied with machine 53 1 0 3 - F 9 -1 0 n C l e a n i n g …
1-5
1
Maintenance
2.1.2 Replaceable parts (for repairs)
The term "Replaceable parts" in this manual indicates parts that might cause a machine stoppage as these parts
lose their functions but do not require machine adjustment after replacement work. Methods for replacing the
following parts are described in this manual.
Replaceable parts
Replace if broken
Operate valve +ejector body
Conveyor unit valve
Blow valve
Feeder valve
Blow valve
Operate valve
Shaft blow valve
Ejector body
Manifold
53102-F9-10
n
Replaceable parts list
Replace if broken
Product Name Parts List Designation Parts No. Note
Feeder valve VALVE KIT KGA-M37P0-00X
For feeder drive (with air hose
supplied)
Ejector assembly VALVE UNIT KGS-M7171-A0X
Operate valve + Ejector body +
Vacuum break valve
Blow valve VALVE KM1-M7163-20X For vacuum break
Conveyor unit valve
VALVE(SPARE) KG2-M8582-400 Main stopper, etc.
Operate valve VALVE KM1-M7163-30X For air ejection
Shaft blow valve VALVE KGS-M7176-00X Exhaust stop valve
1-6
1
Maintenance
2.2 Maintenance tools
2.2.1 Cleaning tools
Spline shaft cleaning kitNozzle cleaning wire
Cleaning tools
Parts supplied with machine
53103-F9-10
n
Cleaning tools
Parts supplied with machine
Product Name Parts List Designation Parts No. Note
Nozzle cleaning wire
NEEDLE ASSY KV8-M8883-A0X
Nozzle tip cleaning tape
TAPE, CLEANER KGT-M8895-00X
Spline shaft cleaning kit
CLEANING KIT KV8-M8860-00X
1-7
1
Maintenance
Cotton swab sticks
Lens cleaner
Lens blower brush
Cleaning tools
Optional parts
Nozzle cleaning wire handle
Air blow gun
53104-F9-10
n
Cleaning tools
Optional parts
Product Name Parts List Designation Parts No. Note
Nozzle cleaning wire handle
NEEDLE CLEANER ASSY KV8-M8881-A0X
Air blow gun
AIR GUN ASSY KU4-M8590-00X
Cotton swab sticks
SWAB KGA-M3802-00X
Lens blower brush BLOWER KGA-M3803-00X
Lens cleaner CLEANER, LENS KGA-M3801-00X
