PC200
PVA
Revision G (2019)
48 of 56
Spare Part Kit For: PC200RW / Urethane Seals
P/N: PC2RW-SP
ITEM
D
ESCRIPTION
SYMB
OL QTY
1
Seal, loaded lip, Urethane
12500187
2
2
O-ring, 030 Buna
VLV-030B
1
3
O-ring, 123 Buna
VLV-123B
1
4
O-ring, 108 Buna
VLV-108B
2
5
O-ring, 016 Viton
VLV-016V
6
6
O-ring, 006 Viton
VLV-006V
2
7
Bearing, sintered sleeve, .188 x .375 x .250” long
01502
1
8
Bearing, sintered sleeve, .125 x .250 x .250” long
01503
1
9
Washer, nylon
214-5368
2
Contact PVA for information on replacement parts or to order.
PC200
PVA
Revision G (2019)
49 of 56
Spare Part Kit For: PC200RW / Teflon Seals
P/N: PC2RW-T-SP
Contact PVA
ITEM
DESCRIPTION SYMBOL QTY
1
Seal, loaded lip, Teflon
Contact PVA
2
2
O-ring, 030 Buna
VLV-030B
1
3
O-ring, 123 Buna
VLV-123B
1
4
O-ring, 108 Buna
VLV-108B
2
5
O-ring, 016 Kalrez
VLV-016K
6
6
O-ring, 006 Kalrez
VLV-006K
2
7
Bearing, sintered sleeve, .188 x .375 x .250” long
01502
1
8
Bearing, sintered sleeve, .125 x .250 x .250” long
01503
1
9
Washer, nylon
214-5368
2
Contact PVA for information on replacement parts or to order.
PC200
PVA
Revision G (2019)
50 of 56
Technical Specifications
Table 2: PC200 Technical Specifications
Weight
PC200R-AL
PC200RW-AL
Approximately 2.3 lbs (36.8 oz)
Approximately 3.7 lbs (59.2 oz)
PC200R-SS
PC200RW-SS
Material inlets
9/16-18 SAE
Air ports
#10-32 UNRF
Operating Air Pressure
60 – 100 psi
Maximum Fluid Pressure
1500 psi
Viscosity Range
1 cps – 250,000 cps
