6 ProFlow Manual 156020 Issue 3 ProFl ow Mechanism GA 5 4 3 2 1 A B C C B A 123 45 67 8 91 0 11 12 13 6 7 8 9 10 11 12 13 D E F G H I D E F G H I PROJECTION DRAWN APPROVED DATE C COPYRIGHT DO NOT SCALE SCALE TITLE DRAWIN…

100%1 / 92
ProFlow Manual 5
137894 Issue 1 ProFlow SCAR Assembly GA (SMC)
F
E
D
C
B
A
654321
E
F
987
123456789
PROJECTION
D
C
B
A
DRAWN
APPROVED
DATE
C
COPYRIGHT
DO NOT SCALE
SCALE
TITLE
DRAWING NUMBER
1999
BOM NUMBER
ITEM PART NO. DESCRIPTION QTY.
1
107526 ELBOW (KQL 08-01) 2
2
112004 SILENCER (AN 110-01) 1
3
118544 HOSE FIXING 1
4
137891 ELECTRO_PNEU REGULATOR 1
5
137892 STRAIGHT CONNECTOR (1/4 - 6) 1
6
137893 REGULATOR BRACKET 1
7
141229 AIR PILOT VALVE 1
8
143813 SILENCER, EBKX SERIES, 1/4 BSP 1
9
G4346 CONN M-5H-4 1
LATEST
ISSUE
No. DATE DCR INITIAL
01 26-Mar-99 DEV CJL
THIS DRAWING AND THE COPYRIGHT
IN IT, IS THE PROPERTY OF
DEK PRINTING MACHINES LIMITED
IT MAY NOT BE COPIED, REPRODUCED,
PUBLISHED OR DISCLOSED IN WHOLE
OR IN PART WITHOUT OUR WRITTEN
CONSENT.
1:1
C LECLERC
ITV REGULATOR ASSY
26-Mar-99
137894
137902
SH 1
OF 1
A
1
2
1
3
1
4
1
6
1
9
1
5
1
7
1
8
1
6 ProFlow Manual
156020 Issue 3 ProFlow Mechanism GA
54321
A
B
CC
B
A
12345
67
8
910
11 12
13
6
7
8
9
10 11
12
13
D
E
F
G
H
I
D
E
F
G
H
I
PROJECTION
DRAWN
APPROVED
DATE
C
COPYRIGHT
DO NOT SCALE
SCALE
TITLE
DRAWING NUMBER
2001
BOM NUMBER
X
X
ITEM PART NO. DESCRIPTION QTY.
1
112414 CABLE TIE CLAMP 2
2
137470 BULKHEAD UNION 4.0MM SELF SEAL 2
3
140327 SOLID STATE PUSH BUTTON SWITCH 1
4
145686 BEARING, ANGULAR CONTACT 1
5
155788 PROFLOW INTERFACE LOOM BOM 1
6
155804 STEPPER MOTOR, FRONT 1
7
155835 PROFLOW HOME LOOM BOM 1
8
156196 LEADSCREW 1
9
156220 LEADSCREW END NUT 1
10
156227 PULLEY, DIA. 6.35 BORE 1
11
156228 PULLEY, DIA. 12 BORE 1
12
156248 BEARING, CROSS ROLLER RB2508UUCC0 1
13
156249 BEARING CLAMP PLATE 1
14
156320 MOTOR SUPPORT PLATE 1
15
156321 ATTACHMENT PLATE 1
16
156324 LINEAR GUIDE 2
17
156370 BEARING RETAINING PLATE 1
18
156373 DRIVE PLATE 1
19
156374 SUPERNUT 1
20
156377 BEARING SPINDLE 1
21
156379 BEARING BLOCK 1
22
156399 WAISTED SCREW 4
23
156420 CONNECTOR PANEL 1
24
156461 SWITCH BRACKET 1
25
700511 NUT M6 HEX. LOCK ST.ST 1
26
700611 WASHER M5 CRINKLE BE/CU 4
27
700735 DOWEL 6DIA X 12LG H&G(GRD 1) 3
28
G1401 CLP EXT D1400/6 1
29
G4952 TIMING BELT 1
THIS DRAWING AND THE COPYRIGHT
IN IT, IS THE PROPERTY OF
DEK PRINTING MACHINES LIMITED
IT MAY NOT BE COPIED, REPRODUCED,
PUBLISHED OR DISCLOSED IN WHOLE
OR IN PART WITHOUT OUR WRITTEN
CONSENT.
1:1
R PIATEK
PROFLOW MECHANISM G.A.
05-Feb-99
156020
156829
SH 1
OF 1
A
0
LATEST
ISSUE
No. DATE DCR INITIAL
03 13-JUN-01 26872 NS
M/TRAY 156402
T/TRAY 156403
F/BOM 156404
2
5
SECTION X-X
4
9
12
13
17
19
28
6
8
14
15
16
18
20
21
22
26
29
1
10
11
25
27
24
3
7
ProFlow Manual 7
156553 Issue 3 Light Shroud Assembly GA
54321
A
B
CC
B
A
12345
67
8
910
11 12
13
6
7
8
9
10 11
12
13
D
E
F
G
H
I
D
E
F
G
H
I
PROJECTION
DRAWN
APPROVED
DATE
C
COPYRIGHT
DO NOT SCALE
SCALE
TITLE
DRAWING NUMBER
1999
BOM NUMBER
A
A
ITEM PART NO. DESCRIPTION QTY.
1
113822 CABLE TIE CLAMP (M5) 1
2
137470 BULKHEAD UNION 4.0MM SELF SEAL 2
3
140228 FESTOON BULB 1
4
140251 PLATE,CONTACT 2
5
155868 PROFLOW PRINT CARRIAGE LOOM BOM 1
6
155948 PASTE ROLL LAMP LOOM BOM 1
7
156093 COVER, MIDDLE 1
8
156094 COVER, LEFT 1
9
156095 COVER, RIGHT 1
10
156638 BRACKET, BULKHEAD FITTING 1
11
156640 LIGHT SHIELD 1
12
156641 BELT COVER 1
13
156644 PUSH FASTENER 2
14
700010 SCREW M5X12 PN.HD SLTD MC ST.ST 1
15
700101 SCREW M3X8 CAP HD ST.ST 2
16
700111 SCREW M4X12 CAP HD ST.ST 2
17
700132 SCREW M5X10 CAP HD ST.ST 2
18
700500 NUT M3 FULL ST.ST 5
19
700515 NUT M3 NI-LOCK 985 2
20
700601 WASHER M3 PLAIN FORM A ST.ST 8
21
700603 WASHER M5 PLAIN FORM A ST.ST 2
22
701106 SCREW M3X10 SLTD CH HD NYLON 4
THIS DRAWING AND THE COPYRIGHT
IN IT, IS THE PROPERTY OF
DEK PRINTING MACHINES LIMITED
IT MAY NOT BE COPIED, REPRODUCED,
PUBLISHED OR DISCLOSED IN WHOLE
OR IN PART WITHOUT OUR WRITTEN
CONSENT.
1:2
R PIATEK
LIGHT SHROUD GA (CAST PRINT CARRIAGE)
13-May-99
156553 156659
SH 1
OF 1
A
0
LATEST
ISSUE
No. DATE DCR INITIAL
03 07-Sept-99 21254 DMH
13
16
17
21
2
3
10
12
15
COVER, MIDDLE REMOVED FROM THIS
VIEW FOR CLARITY
6
5
7
8
9
SECTION A-A
SCALE 1:1
4
11
19
20
1
14
18
22
