Installation

Setup Center Software Installation

Installation Manual SIPLACE Setup Center 2.3

X Enter the Password for the SQL Server user "SiplaceSetupCenterUSR".

X Choose your SQL Server Instance from the pull-down menu.

X Click Next.

Step 4

X The Start Copying Files dialog box gives you a chance to check the information again, which you

have entered during the previous steps.

X Click Next if you accept all the information entered so far.

X If you want to alter one or more details, click the Back button until you get back to the dialog box in

question.

X There, enter your changes and click Next to continue as usual.

NOTE:

This password is empty if MSDE/SQL Server has been freshly installed. In this case, erase the

displayed default password. Subsequently, a window will open, prompting you to change this

password. You may accept the Siemens Service default password or choose one of your own.

Installation

Software Installation Setup Center

50 Installation Manual SIPLACE Setup Center 2.3

Step 5

X The installation routine starts.

X The "Installation Complete" window appears if the installation has been completed successfully.

X Click Finish.

Setup Type – Database

This setup type contains the database components of the SIPLACE Setup Center. Setup detects if SQL

Server or MSDE (Microsoft Data Desktop Engine) has already been installed. Select this type to install

the SIPLACE Setup Center database to a SQL Server.

Step 1

X Run through the steps in chapter "Gerneral Settings".

X Select the SIPLACE Setup Center Database setup type.

X Click Next.

Installation

Setup Center Software Installation

Installation Manual SIPLACE Setup Center 2.3

Step 2

X Enter the information required to be connected with the SQL Server and database in the Select SQL-

Server dialog box.

X Enter the Password for the SQL Server user "sa", i.e. the SQL server system administrator.

X Choose your SQL Server Instance from the pull-down menu.

X Click Next.

The following dialog appears, in case no database with the name

SiplaceSetupCenter

exists:

X Choose Select another SQL Server you return to the previous dialog.

X Click Next to create a new database.

NOTE:

This password is empty if MSDE/SQL Server has been freshly installed. In this case, erase the

displayed default password. Subsequently, a window will open, prompting you to change this

password. You may accept the Siemens Service default password or choose one of your own.

ATTENTION:

Only the SQL Server Instances on the local computer are selectable.
