1 AJK-ML T-ID 0706-002 Before Use W e are grateful to you for purchasing our multi-layer tray feeder for the Hitachi direct- drive modular mounter (Chip Mounter). This product is used to load the component placement mach…
AJK-MLT-ID
Before using this manual, please note the following items.
1. The contents of this manual are subject to change for improvement
without prior notice. Please pay attention to the latest information such as
the CS news that will be provided or issued by our company.
2. The copyright of the instruction manual belongs to Hitachi High-Tech
Instruments Co., Ltd.
This manual shall not be copied, in whole or part, without written consent
of the publisher.
3. Our company shall not be held to any liability for any damages suffered
or incurred by the end user
, arising from any operations other than those
(including the purposes and methods) described in this instruction manual.
Be sure to handle the machine carefully.
4. This instruction manual neither guarantees any license to industrial
property rights, etc., nor grants any license of such rights.
0706-002
1
AJK-MLT-ID
0706-002
Before Use
We are grateful to you for purchasing our multi-layer tray feeder for the Hitachi direct-
drive modular mounter (Chip Mounter).
This product is used to load the component placement machine (GXH series) with tray
components.
This instruction manual describes the functions, handling, and operations of the multi-
layer tray feeder for those who have nished the basic training of the chip mounter.
Before operating the machine, please read this instruction manual carefully to fully
understand the instructions and precautionary measures for safety purposes.
After reading this instruction manual, be sure to keep it at hand for your quick reference.
2
AJK-MLT-ID
0706-002
About the Instruction Manual
Instruction Manual of Main Machine (GXH Series)
This describes the checking items, the safety precautions, the operation procedures,
the creation of a component library, the maintenance, the troubleshooting, etc., for
those who use the main machine and the electrical circuit diagrams, etc., for those
who are in charge of maintenance work.
Please read this instruction manual before operating the multi-layer tray feeder.
Instruction Manual of Multi-Layer Tray Feeder
This instruction manual is classied into several chapters on subjective basis as
follows.
Chapter 1: Scope
This chapter describes the basic usage of the feeder for those who use this
feeder.
Coverage:
"Outline", "Specications", "Functions", "Construction", "Name
of Each Section", "Handling", etc.
Chapter 2: Operation
This chapter describes the general items related to the operations for those
who have learned "Chapter 1: Scope".
Coverage:
"Basic Knowledge" and "Menus for
Automatic and Maintenance
Operations"
Please refer to the instruction manual of the main machine for
the other operation windows.
Chapter 3: Data
Various data is explained for the programmer for whom the pattern program is
made.
Coverage:
"Outline of Data" and "Description of Pattern Program",
"Component Library", and "System Setting"
Please refer to the instruction manual of the main machine for
the other data.
