2-22
AJK-MLT-ID
3.3.1 Tray Unit
This window enables the operator to manually operate the multi-layer tray
feeder.
[1] [2] [3]
[4] [5]
Fig. B16 "TRAY UNIT" Window
[1] Sel Tray
The installed multi-layer tray feeders are displayed, making it possible
for the operator to select one of the feeders.
[2] Set Data
Speed deceleration rates can be specied for each section of the multi-
layer
tray feeder.
Elevator #2 Dclr :
This is used to set the speed reduction rate of
Elevator #2.
Elevator #1 Dclr :
This is used to set the speed reduction rate of
Elevator #1.
Traverse Dclr :
This is used to set the speed reduction rate of the
Traverse.
Cmp Hgt Sensor :
This is used to set the level in which the height of
the Cmp Hgt Sensor.
3.3 Unit Adjustment
0804-003
2-23
AJK-MLT-ID
[3] "Information" Group Box
Displayed is the data of the multi-layer tray feeder that was used for the
previous adjustment.
The
following items are displayed.
Elev No.
Draw Step No.
Cmp Hgt
Mag Type
Time
Reference
The data being edited will not be displayed as information.
[4] Operational Object Selection Buttons
Select the object for the operation.
When pressed, this button moves the specied step to the traverse
drawout
position.
[5] Operation Selection Buttons
[Pallet Chng Pos] Button :
When pressed, this button moves the
elevator to the component supply
position.
[Mag
Chng Pos] Button :
When pressed, this button moves
the elevator to the magazine change
position.
[Pallet Draw Position] Button :
When pressed, this button moves
the elevator to the traverse drawout
position.
[Up (Step)] Button :
When pressed, this button moves the
elevator upward by 1 pitch of the
pallet.
[Down
(Step)] Button :
When pressed, this button moves the
elevator downward by 1 pitch of the
pallet.
[Pallet Draw] Button :
When pressed, this button activates
the traverse to draw out the pallet.
[Pallet Storage] Button :
When pressed, this button stores the
pallet drawn out on the traverse.
[Rack Shtr Opn/Cls] Button :
When pressed, this button opens or
closes the rack shutter.
[Chuck Opn/Cls] Button :
When pressed, this button opens or
closes the chuck.
3.3 Unit Adjustment
0706-002
2-24
AJK-MLT-ID
[Servo ON] Button :
When pressed, this button turns on
the power to the servomotor.
[Servo OFF] Button :
When pressed, this button turns off
the power to the servomotor.
[Zero] Button : W
hen pressed, this button zeros the
elevator.
3.3 Unit Adjustment
0706-002
