Stud ent Gu ide HS-5 0 Adva nced II 07/2 002 Ed ition 9 Z-Axis 11 . (1) 4 x M3 x 5 hex agon socket- head sc rew with locki ng va rnish (2) Z-axis dri ve (3) 2 x M 2.5 x 12 hex agon soc ket-hea d screw (4) Motor c lamp fi…
07/2002 Edition Student Guide HS-50 Advanced II
9 Z-Axis
10
5HSODFLQJWKH=D[LVGULYH
7RROVDQGHTXLSPHQW
– Set of DIN 911 Allen keys
– TSM belt tension measuring device, item no. 00326015-01
– "Measuring belt tensions" instructions
3DUWV
Z-axis drive, item no. 00341011-01
'LVPDQWOLQJWKH=D[LVGULYH
➠ Switch the placement system off and secure it to prevent switching on again.
➠ Remove the plugs from sockets X3 and X4 on the intermediate distribution board.
➠ Undo the four M3x5 hexagon socket-head screws with locking varnish (item 1 in Fig.
9.2 - 4
).
➠ First undo the upper M2.5x12 hexagon socket-head screw (item 3 in Fig. 9.2 - 4) of the motor
clamp fitting 2 (item 4 in Fig. 9.2 - 4
), then the lower one.
➠ Undo the two M3x14 hexagon socket-head screws (item 6 in Fig. 9.2 - 4 of the motor clamp
(item 5 in Fig. 9.2 - 4
).
X3 Motor / tacho for the Z-axis drive
X4 Track signals for the Z-axis drive
Student Guide HS-50 Advanced II 07/2002 Edition
9 Z-Axis
11
.
(1) 4 x M3x5 hexagon socket-head screw with locking varnish
(2) Z-axis drive
(3) 2 x M2.5x12 hexagon socket-head screw
(4) Motor clamp fitting 2 / DLM1
(5) Motor clamp fitting / DLM1
(6) 2x M3x14 hexagon socket-head screw
➠ Carefully remove the Z-axis drive together with the cables.
)LWWLQJWKH=D[LVGULYH
➠ Insert the Z-axis drive.
➠ Make sure that the teeth of the toothed belts engage in the teeth of the motor pinion.
➠ Use the four M3x5 hexagon socket-head screws to fix the Z-axis drive.
➠ Tension the Z toothed belt by pushing the Z drive unit upwards.
07/2002 Edition Student Guide HS-50 Advanced II
9 Z-Axis
12
6HWWLQJV
➠ Use the belt tension measuring device to check the tension of the toothed belt (see setting
instructions).
➠ Tighten the two M3x14 hexagon socket-head screws (item 6 in Fig. 9.2 - 4) for fixing the motor
clamp (item 5 in Fig. 9.2 - 4
).
➠ Tighten the two M2.5x12 hexagon socket-head screws (item 3 in Fig. 9.2 - 4) for fixing the
motor clamp 2 (item 4 in Fig. 9.2 - 4
).
PLEASE NOTE:
Now tighten the hexagon socket head screws on the Z-drive unit and the motor clamp.
)UHTXHQF\+]
EHIRUHFRQWLQXRXVRSHUDWLRQ
)UHTXHQF\+]
DIWHUFRQWLQXRXVRSHUDWLRQ
Toothed belt T2 / DLM1 280 ± 10 280 ± 10
