User’s Manual Line Computer UNIX 1 Hardware / Software Installation
Software Version 403.xx Edition 06/97 1.2 Software Installation
1 - 7
1.2 Software Installation
1.2.1 General
NOTE
Prerequisite for the installation of the line computer software is that the SCO UNIX ODT 3.0 operating system
has been properly installed.
The installation of the operating system SCO UNIX 3.0 is performed at Siemens, AUT 5.
The installation of the LC software is performed using a streaming tape.
The number of entries to be made
during the installation procedure depends upon the fact whether an initial installation or the installation of a new
version of the LC software is being performed or whether the computer is equipped with a second LAN card
(see Note, page 1 - 12).
NOTE
When loading a new version of the LC software, the master data existing on the line computer are retained.
This shortens the installation procedure as entries concerning the stations can be dispensed with.
Depending on the computer type used
the following devices are required for the installation of the LC software:
Tab. 1.2 - 1 Software Installation Devices for LC types
Computer Type
486/66 DX2 Pentium
Boot disk for PC486
(item no. 00327184-02)
Boot disk for Pentium-based computer
(item no. 00327183-02)
Installation diskette
(item no. 00327185-02)
Installation diskette
(item no. 00327185-02)
Streamer tape 250 MB with LC Software
Version x.xx
(item no. 00327186-02)
Streamer tape 250 MB with LC Software
Version x.xx
(item no. 00327186-02)
1 Hardware / Software Installation User’s Manual Line Computer UNIX
1.2 Software Installation Software Version 403.xx Edition 06/97
1 - 8
1.2.2 Definition of Terms
-
Initial Installation
Prior to the start of the installation of the LC software, the computer must be in a neutral state, i.e. the
SCO UNIX ODT 3.0 operating system has been installed by means of "MIT" (Mass Installation Tool),
but no further data exist on the hard disk yet. This basic state exists when the unit is delivered and can
be achieved by using "MIT".
When the LC software is then installed with the aid of the installation program, also the sample master
data are installed on the hard disk.
-
Update
When the only difference between the new LC software and the one already installed is their revision
level, (e.g. LRU.402.
003
=> LRU.402.
004
) this is referred to as an update.
Any errors that may have
occurred in the predecessor version have been eliminated in the update version, and the software has
been optimized. In the case of an update, the master data are retained.
-
Upgrade
When the new software differs from the one already installed in that their version designations are
different, (e.g. LRU.
401
.006 => LRU.
402
.001) this is referred to as an upgrade.
An upgrade version con-
tains new functions.
In the case of an upgrade, the master data are retained and, if required, automati-
cally converted into the new data format.
1.2.3 Installation of LC Software
●
Insert the Boot Diskette (1).
ATTENTION
∆
!
Be sure to use only the boot diskette appropriate for your specific computer type (see chart in
section 1.2.1).
●
Turn on the UPS.
●
Press RETURN when the line "
Boot:
" is displayed on the screen.
The line computer is now booted from the diskette.
After approx. 1 minute the following message is displayed on the screen:
Insert installdisk and press <Return> to continue
or remove the bootdisk and press <Return> to quit (ignore Warnings)
NOTE
When this message is displayed, the installation procedure can still be stopped by removing the boot
diskette and subsequently pressing the RETURN key. The error messages subsequently displayed
can be ignored. The state of the LC software is unchanged.
●
Remove Boot Diskette, insert Installation Diskette (2) and press RETURN.
User’s Manual Line Computer UNIX 1 Hardware / Software Installation
Software Version 403.xx Edition 06/97 1.2 Software Installation
1 - 9
After a while, the following messages are displayed on the screen:
This is the last point to abort the LRU-installation
without changing any data.
If you have installed OEM-software, you have to reinstall it
after the LRU-installation
Do you want to continue the LRU-installation [y/n]
Abort Installation:
●
Enter
n
for the installation to be aborted and then press RETURN.
The following steps are displayed for terminating the installation procedure and rebooting the
line computer:
Next steps
1.) Remove the floppy after the Safe to Power Off message
2.) reboot your system
3.) login as plr
** Safe to Power Off **
- or -
** Press Any Key to Reboot **
The computer can now be rebooted. The LC software’s state is still unchanged.
Continue Installation:
●
Enter
y
to continue the installation process and then press RETURN.
The computer system is shut down. The following steps are displayed for continuing the
installation procedure:
AUT 51 pre-install finished
Next steps
1.) Remove the floppy after the Safe to Power Off message
2.) insert the tape
2.) reboot your system
3.) login as plr
** Safe to Power Off **
- or -
** Press Any Key to Reboot **
