1 Introduction

1.2 Qualification and training of personnel

10 User Manual SIPLACE Head Care Station 10/2017

1.2 Qualification and training of personnel

Personnel used for operation and installation must hold the relevant qualifications for the job. The

user must keep tight control over their responsibilities, assignment and supervision. Any employee

who does not have the relevant training must be trained and given appropriate instruction. The in-

struction is to be given by trained and authorized personnel.

SMTAcademy

The SMTAcademy provides technical training courses for your team, covering everything from ba-

sic SIPLACEoperator training to advanced follow-up training for your experts. Our courses can

either be held at your company or at one of our SIPLACE training centers worldwide. In addition to

our range of standard training programs, we can also offer customized courses to meet your indi-

vidual requirements.

SIPLACEtraining courses are always on a modular basis. This means that you can either book a

standard course or compile your own training program with the individual topics required for your

production environment.

Special training courses for SIPLACEHCS

Expert and technical training courses are available for the SIPLACEHCS.

Standard training courses for

SIPLACE HCS

Technical training for the HCS.

Follow-up courses and customized

courses

Customized training available on request.

Other training courses SIPLACE placement heads – modular training units

NOTICE

Operation of system only by qualified personnel

► Only staff with the relevant qualifications may start up, operate or otherwise work on

the machine.

► The qualification must be proven by means of training courses or instruction for the

personnel.

1.3 Operator levels

Certain functions or menus may only be executed or accessed by specially trained personnel. A

differentiation is made between the following operator levels:

●

Production

●

Advanced production

●

Service (customer)

The operator levels "Advanced production" and "Service (customer)" can be password protected.

The operator level "Service (SIPLACE)" is already password protected.

Production

This operator level includes those people who have been trained to operate the machine. These

people are authorized to use any functions associated with operating the machine and may call up

any menus needed to use the machine.

Advanced production

People with this operator level have completed special training and are authorized to perform setup

tasks e.g. creating setup configurations or determining Vision parameters etc.

Service (customer)

People with this operator level are specially trained technicians at the customer end, who can, for

example, define machine option settings.

1 Introduction

1.4 Important notes on this user manual

User Manual SIPLACE Head Care Station 10/2017 11

1.4 Important notes on this user manual

1.4.1 Contents and filing of this user manual

This user manual contains basic information that must be observed when setting up, operating and

maintaining the machine. The service engineers, qualified staff, operators and users plus system

owner must therefore read it before commencing installation and commissioning. The instructions

must be kept permanently accessible where the machine is used.

In addition, the user must ensure that the employees have fully understood the contents of the user

manual.

1.4.2 Notes on danger, warnings and cautions

WARNING

Read the user manual thoroughly!

► Tasks may only be performed by qualified staff who have completed the relevant training.

► Only perform tasks on the machine if you have precise knowledge of the relevant section in

the user manual.

► Observe all danger notes, warnings and cautions.

► Please also carefully read through chapter 2 "Safety" [}13] of this user manual.

1.4.3 Manufacturer's/supplier's liability

We hereby confirm that the contents of this user manual are of a descriptive and explanatory

nature only and do not contain any contractual conditions or guaranties. The liability and obliga-

tions assumed by ASMAssemblySystemsGmbH&Co.KG can be found exclusively in the relev-

ant contract agreement concerning the supply of the machine described in this manual. This ap-

plies in particular to all statements regarding performance or service life and the agreed liability for

faults or defects. The provisions of the contract regarding the liability for faults or defect are neither

extended nor restricted by any statements in this user manual.

1.4.4 Revision table

Edition Amendments

01/2013

●

First edition

●

Station software 707.1

●

Operation System WESXP

05/2015

●

Correction of errors and supplements

●

Prepared for GigE retrofit

07/2017

●

Formal adjustments

●

Modified tool clamping

●

Station software 709.1

●

Operation System WES7

●

GigE functionality

●

C&P20A verification with vacuum pump

●

C&P20P verification with compressed air

1 Introduction

1.4 Important notes on this user manual

12 User Manual SIPLACE Head Care Station 10/2017

1.4.5 Further information about and contents of the documentation package

1.4.5.1 How to get information

If you have any further questions concerning this manual or if you would like additional information

on a particular topic, please get in touch with your local SIPLACE organization.

1.4.5.2 SIPLACE on the World Wide Web (WWW)

homepage at http://www.siplace.com.

You can choose between the German and English versions.

The different sections contain information about our products, services and contact persons.

In addition, registered customers can also access the MySIPLACE user group. Here you can call

up special information about our placement systems, e.g.

●

technical documentation

●

technical information

●

spare parts lists etc.

Registration for theMySIPLACE user group is very simple:

► Click at the head of the web site on and then on the Register

link.

► Fill in the registration form and send it off to us.

Soon afterwards, you will receive your access authorization with user name and password

1.4.6 Abbreviations

CEE Commission on the Rules for the Approval of the Electrical Equipment

C&P20 P SIPLACE SpeedStar C&P20P for top placement performance

C&P20 M2 SIPLACE SpeedStar C&P20M2 for high-precision placement

C&P20 A SIPLACE SpeedStar C&P20A for very high speed placement

C&P20 M SIPLACE SpeedStar C&P20M for top placement accuracy

CPP SIPLACE MultiStar CPP for flexible placement performance

CPP M SIPLACE MultiStar CPPM for flexible placement accuracy

ESD Electrostatically-sensitive devices

EMC Electromagnetic compatibility

HCS Head Care Station

P&P Pick&Place module, SIPLACE TwinStar

TH Twin Pick&Place head, SIPLACE TwinStar
