MX-3600 / CXI3600MX / Specification
confidential 20/39 spec_mx3600_sys_10.11.doc
3. System Specification / Software
3.1. MX-3600 - Software Overview
The MX-3600 Software is developed to run under Windows XP platform – the
modular design allows flexible integration of the newest inspection and process
control components.
Table 6: MX-3600 / MIPS Software Modules
MX 3600 Basic Software
Moduls
Functional Tools
MX Control Hardware
MIPS-Inspect Hardware (refer to 24.)
Control PC
* PC with embedded Dual Processor Setup
* High Speed Framegrabbing
* Windows ™ XP Platform
MIPS_Inspect
MIPS_Inspect Software Tools
X-RAY Image Processing
& Inspection
MX Systemsoftware
* MX Sequencer
* X-RAY Task
* Image Acquisition Task
* Motion Task
* I/O Task
* Calib & Diagnostic Task
X-Inspection Engine
* Parameter Tuning Display
* Inspection Performer
* Inspection Report Interface
X-Algorithm Library
* Advanced SMT Solderjoint Algorithm Library
* Advanced Semi-Backend Library
X-Classificator
* Measurement Analyser
* Rule Performer & Classificator
MIPS_Process
X-SPC / Real Time Processing Control
Inspection Data
Processing & Real Time
SPC
* yield display
* ppm display
* apw signal (automatic process warning)
optional:
X-DCS / Data Collection System ( or X-Collect)
MX-3600 / CXI3600MX / Specification
confidential 21/39 spec_mx3600_sys_10.11.doc
3.2. MX-3600 / System Software & GUI
The main sequencer controls and manages all software tasks of the system
software.
A graphical ease to use GUI is the Interface to the operator. The following
operator levels are defined and secured by password protection as standard
setup:
Operator Level
Application Level
Administration Level
The touch-screen bottoms are related to all operator functions. Application and
Administration level may use the keyboard for X2/MX-3600 programming!
Fig. 11: MX-3600 System Software Structure
Ethernet
Socket Interface
MIPS
X-Ray IO Acq Report Ident
GUI
Sequencer
Motion
MIPS
Image Processor Matrix
Factory
QS System
MX-3600 / CXI3600MX / Specification
confidential 22/39 spec_mx3600_sys_10.11.doc
3.3. X-Inspection Engine
The inspection engine is the core part of the inspection program processing – the
key modules are:
Inspection Data Manager
Inspection Program Emulator
Algorithm Processor
Parameter Tuning
Inspection View Processor
Measurement Output IF
Fig. 12: Inspection Process Principle
