MX-3600 / CXI3600MX / Specification
confidential 37/39 spec_mx3600_sys_10.11.doc
6. Specification Overview
Pls. refer for:
general performance overview to AppendiX A
detailed specification overview to AppendiX B
MX-3600 / CXI3600MX / Specification
confidential 38/39 spec_mx3600_sys_10.11.doc
7. Documentation & Standards
7.1. Manuals
The following manuals are part of the standard documentation package:
MX-3600 Operator Manual English/German &
local language
+ functional overview
+ operator instructions
+ preventive maintenance instructions
MX-3600 Service and Maintenance Manual English
+ system calibration
+ system service instructions
+ system troubleshooting and system checker
+ spare part lists & explosions figures/drawings
MX-3600 / MIPS Programmers Manual English
+ system software description and instructions
+ application program management
+ application program generation
+ application debugging
MX-3600 Algorithm Manual English
+ solder joint inspection principles
+ solder joint algorithm library
+ parameter debugging & tuning
+ classification debugging and tuning
MX-3600 / CXI3600MX / Specification
confidential 39/39 spec_mx3600_sys_10.11.doc
7.2. Technical Standards
The relevant manufacturing standards are listed in AppendiX D1 in
conjunction with the CE certification.
The specific UL standards are listed in AppendiX D2 !
Solder joint classification standards (incl. IPC guidelines) in
Appendix F
