第 1 部基本篇第 1 章装置概要 ······································ 1-1 第 2 章生产 ············································ 2-1 第 3 章维护 ············································ 3-1 第 4 章制作生产程序 ···························…

12-7-3 使用方法 ···························································································· 12-22

12-8 手持操作盘（HOD） ·················································································· 12-26

12-8-1 概要 ·································································································· 12-26

12-8-2 示教的操作方法 ··················································································· 12-28

12-8-3 其他在 HOD 上可进行的操作方法 ···························································· 12-37

12-9 切割机 ····································································································· 12-40

12-9-1 概述 ·································································································· 12-40

12-9-2 操作方法 ···························································································· 12-40

12-10 对应长尺寸基板 ······················································································· 12-44

12-10-1 对应基板尺寸 ···················································································· 12-44

12-10-2 基板停止位置与贴片范围 ····································································· 12-45

12-10-3 BOC 标记 ·························································································· 12-46

12-11 镀锡识别照明 ·························································································· 12-47

12-11-1 使用镀锡照明时的示教 ········································································ 12-47

12-12 螺丝式吸嘴 ····························································································· 12-48

12-12-1 特点 ································································································ 12-48

12-12-2 规格 ································································································ 12-49

12-12-3 安装方法 ·························································································· 12-50

12-12-4 设置 ································································································ 12-52

12-12-5 设置使用单元 ···················································································· 12-53

12-12-6 吸嘴配置 ·························································································· 12-53

12-12-7 编辑程序 ·························································································· 12-54

12-12-8 生产 ································································································ 12-55

第 13 章程序补充 ·································································································· 13-1

13-1 元件尺寸图例 ······························································································ 13-1

13-2 控制数据管理 ······························································································ 13-9

13-2-1 将控制数据保存到闪存的处理 ································································· 13-10

13-2-2 把控制数据保存到 USB 存储器 ······························································· 13-12

13-2-3 从闪存复原控制数据的处理 ···································································· 13-14

13-2-4 从

USB 存储器等复原控制数据的处理 ······················································ 13-15

13-3 各用户级别可使用的功能 ············································································ 13-17

13-4 生产程序的文件格式 ·················································································· 13-18

13-4-1 可读取的文件格式一览 ·········································································· 13-18

13-4-2 可保存的文件格式一览 ·········································································· 13-20

13-5 作为用户指定模板的可登录模式 ··································································· 13-21

13-6 激光状态一览表 ························································································· 13-22

13-7 维护日志 ·································································································· 13-23

13-7-1 取得实时日志 ······················································································ 13-23

13-7-2 取得维护日志 ······················································································ 13-24

附录

用语集 ················································································································ A-1

第 1 部基本篇

第 1 章装置概要 ······································ 1-1

第 2 章生产 ············································ 2-1

第 3 章维护 ············································ 3-1

第 4 章制作生产程序 ································ 4-1

第 5 章数据库 ········································· 5-1

第 1 部基本篇第 1 章装置概要

1-1

第1章装置概要

1-1 本装置概要

1-1-1 前言

JX-350 配备了带有并排 6 个贴装轴的激光校准传感器（LNC60），是提升了贴装生产效率的“One By

One(逐一)排列方式的多轴式贴片头型贴片机”，用于生产照明机器及液晶 TV、PC 显示器等中大型

LCD 背光源的中型 LED 包装及 LED 扩散镜片、长尺寸基板等需要进行特殊处理的芯片元件/镜片元

件。

JX-350 除了可选择以往的机械式供料器规格之外，还可选择电动式供料器规格，通过安装 RX/FX/KE

系列共通的电动式供料器，构筑运行稳定的生产线。

（1）各机型的特性

1）基本规格

基板规格标准选项

基板尺寸

1 次传送

650×250mm

2 次传送

1,200×250 mm

3 次传送

- 1,500×250 mm

3 缓冲

410×360 mm

传送基准前面基准

对应语言日语・英语・中文的实时切换

基板传送高度

900 mm±20 mm

950 mm±20 mm（选项、EN 机为标准装备）

元件高度

SC（6 mm）

NC（12 mm）

元件贴片速度

*注 1 *注 2

芯片元件

（IPC9850）

21,000(CPH)

元件尺寸

*注 1

激光识别 0604～□33.5 mm 或对角 47 mm

贴片精度*注 1 激光识别 ±50μm (Cpk≧1)

元件贴装数*注 3 最大 160 个品种（使用 EF08HD 时）

EN 规格对应

*注 1：详细规格请参见 1-5 章对象元件及元件包装。

*注 2：元件高度：6mm 时。

*注 3：使用后侧台架选购项时。

2）识别装置、Head

JX-350 说明

LNC60 ○

可使用 6 个吸嘴对小型・薄型芯片进行高速贴片。

・LNC60(Laser Align New Concept) ：可使用 6 个吸嘴实现小型、薄型芯片的高速贴片。
