Symbols/Notes 8 Installation Manual SIPLACE Traceability 3.1
Symbols/Notes
Installation Manual SIPLACE Traceability 3.1
7
2 Symbols/Notes
This document uses the following symbols and notes for your convenience.
Words in bold/italic print This text is a dialog, a dialog box, menu item or command.
Step … An installation step includes all the actions relating to a
specific dialog box. A dialog may be composed of several
actions (→).
X
Requires an action (e.g. mouse click, open file)
Corresponds to a warning. This warning is critical for
successful operation.
Indicates explanatory information.
Symbols/Notes
8 Installation Manual SIPLACE Traceability 3.1
Scope of Delivery
Installation Manual SIPLACE Traceability 3.1
9
3 Scope of Delivery
The SIPLACE Traceability 3.1 basic software package (item no. 00169576-03) contains the following
components:
SIPLACE Traceability Basic License V3.x (License only) [00169566-01]
SIPLACE Traceability Upgrade License V3.x (License only) [00169567-01]
SIPLACE Traceability Server V3.1 Media Package [00169568-01]:
1 Traceability 3.1 CD
– Installation SIPLACE Trace Service
– Installation SIPLACE Trace Host
– Installation Trace Host option for SIPLACE Explorer
– Activation of traceability data generation at the station
1 Support Media DVD V1.8
Installation of system requirements:
– Java 2 Java Runtime Environment 1.6
– SQL Server 2008 SP1 Express
– Tomcat Web Server 5.5
– Microsoft.NET 3.5 SP1 Framework
– Microsoft Internet Explorer 7.0, 6.0 SP2
– Adobe Acrobat Reader 7.0
– License Manager 2.2
Basic documents:
– Installation Manual (Item No.: 00196589-xx [English])
– Version Description (Item No.: 00196588-xx [English, German])
– User Manual (Item No.: 00196586-xx [German] / 00196587-xx [English])
NOTE:
Please use the document “Navigation Guide for the Installation Procedure of SIPLACE Software
Systems” (Item. No. 00195050-xx) to help you find your way through the documentation.The
Navigation Guide and all the other documents referred to can be found on the Support Media
DVD (Item No. 00383100-xx), supplied with each software product.
