- - 39. AIR BL OW UNIT COM P O N ENTS (OPT IO N) 2 4 6 9 8 7 5 1 0 1 1 1 1 1 2 1 3 1 6 1 5 2 0 2 1 2 2 1 9 3 1 9 1 7 1 4 1 8 1 REF.NO N O TE PART NO D E S C R I P T I O N Qty 1 E4001-802 -0 A0 AI R BLOW UNIT ASM. 1 2 E…
- -
38. BLANK RUN UNIT COMPONENTS
3 6
2
3
4
7
8
5
9
6
1 0
1 1
1 2
1 2
1 2
1 4
1 5
2 8
1 6
3 2
3 3
3 3
3 3
3 4
3 5
2 8
3 0
1 5
1 9
3 1
1 8
1 7
2 9
2 0
1 3
2 1
2 5
2 6
2 7
2 4
2 3
2 2
3 7
2 9
4 0
3 9
3 8
1
REF.NO NOTE PART NO D E S C R I P T I O N Qty
1 E3920-802-0A0-A BLANK RUN UNIT ASM. 1
2 400-11079 FLANGE SHAFT COMPL. (1)
3 E3924-802-000 PULLEY SHAFT (1)
4 E3925-802-000 TAPE ROLL SHAFT KNOB (1)
5 E3926-802-0A0 TAPE ROLL SHAFT COMPL. (1)
6 E3928-802-000 ROLL SHAFT (1)
7 E3930-802-0A0 ROLL CLUTCH SHAFT COMPL. (1)
8 E3932-802-0A0 FLANGE B COMPL. (1)
9 E3932-802-000 FLANGE B (1)
10 E3935-802-000 CYLINDER KNUCKLE (1)
11 E3936-802-000 ROLL DRIVING LEVER (1)
12 E3937-802-000 TAPE PRESSER SPRING (3)
13 E3938-802-000 DETECTOR SWITICH FITTING PLATE (1)
14 E3939-802-000 BLANK RUN TAPE (1)
15 E3940-802-000 SCREW (2)
16 WZ-1450302-KP WASHER (3)
17 E3942-802-000 SPACER (8)
18 E3943-802-000 CYLINDER STUD (2)
19 WP-0430800-SC WASHER M4 (1)
20 PA-1503013-A0 AIR CYLINDER (1)
21 E9557-802-0A0 FULL DETECTOR SWITICH (1)
22 E3944-802-0A0 TAPE BREAK SENSOR (1)
23 E3944-802-000 SENSOR FIXED BLOCK (1)
24 E9560-802-0A0 SENSOR CABLE ASM. (1)
25 SL-4020591-SC SCREW M2X5 (1)
26 SL-4021291-SC SCREW M2 X 12 (1)
27 SL-4021091-SC SCREW M2 L=10 (1)
28 SM-1030501-SC SCREW M3 L=5 (6)
29 PC-0105080-00 SPEED CONTROLLER (2)
30 NM-6050001-SC NUT M5 (2)
31 SM-6050652-TP HEXAGON SOCKET HEAD SCREW M5X6 (2)
32 SL-4030481-SF SCREW (2)
33 SM-0030601-SC SCREW M3X0.5 L=6 (3)
34 SM-0031201-SC SCREW M3 L=12 (2)
35 SM-4020801-SN SCREW M2 X 8 (2)
36 E3921-802-000-A FITTING BASE PLATE (1)
37 400-69935 ROLL COLLAR (1)
38 SM-6053002-TN SCREW M5X0.8 L=30 (1)
39 SB-1050003-00 BALL BEARING (4)
40 WP-0531001-SC WASHER (2)
- -
39. AIR BLOW UNIT COMPONENTS (OPTION)
2
4
6
9
8
7
5
1 0
1 1
1 1
1 2
1 3
1 6
1 5
2 0
2 1
2 2
1 9
3
1 9
1 7
1 4
1 8
1
REF.NO NOTE PART NO D E S C R I P T I O N Qty
1 E4001-802-0A0 AIR BLOW UNIT ASM. 1
2 E4001-802-000 REGULATER BRACKET (1)
3 E4002-802-000 SYRINGE HOOK (1)
4 SM-0040601-SC SCREW M4X0.7 L=6 (2)
5 E4005-802-0A0 VALVE BRACKET ASM. (1)
6 E4005-802-000 VALVE BRACKET (1)
7 PV-0100060-00 HAND VALVE (1)
8 SL-4042591-SC SCREW M4 L=25 (2)
9 SM-0040601-SC SCREW M4X0.7 L=6 (2)
10 PF-0205010-B0 REGUIATER (1)
11 PJ-3040605-02 ELBOW UNION 6XM5 (2)
12 SM-0040601-SC SCREW M4X0.7 L=6 (2)
13 PJ-2300061-00 UNION 06 (1)
14 E4003-802-0A0 ADAPTER HEAD ASM. (1)
15 E4003-802-000 ADAPTER HEAD (1)
16 E4004-802-000 AIR CLAMP (1)
17 BT-0600400-EC TUBE HOSE, BLUE (0.35)
18 RO-1582401-00 O-RING (1)
19 BT-0600400-EC TUBE HOSE, BLUE (0.4)
20 PJ-3041053-01 ELBOW UNION (1)
21 PJ-3010600-04 REDUCER (1)
22 BT-0600400-EC TUBE HOSE, BLUE (2.5)
