MSP-GANG.dll Description

www.ti.com

102

SLAU358Q–September 2011–Revised October 2019

Submit Documentation Feedback

Dynamic Link Library for MSP-GANG Programmer

whole range from Vccmin to Vccmax

#define POWER_SUPPLIED_BY_MSPGANG 1 // targets supplied by

MSP-GANG

#define EXTERNAL_POWER_IN_RANGE 2 // external power supply -

verified range - selected Vcc +/- 0.3V

#define CFG_VCCINDEX 7

// Vcc in mV 1800 - 3600

#define CFG_ICC_HI_EN 8

// disable 0 (up to 30mA from MSP-GANG to each targets)

// enable 1 (up to 50mA from MSP-GANG to each targets)

#define CFG_BLOWFUSE 9

// disable 0

// enable 1

#define CFG_TARGET_EN_INDEX 10

// Targets GANG enable mask - 0x00 ...0xFF. Enable all targets -

> 0xFF

#define TARGET_1_MASK 0x01

#define TARGET_2_MASK 0x02

#define TARGET_3_MASK 0x04

#define TARGET_4_MASK 0x08

#define TARGET_5_MASK 0x10

#define TARGET_6_MASK 0x20

#define TARGET_7_MASK 0x40

#define TARGET_8_MASK 0x80

#define CFG_FLASHERASEMODE 11

#define ERASE_NONE_MEM_INDEX 0

#define ERASE_ALL_MEM_INDEX 1

#define ERASE_PRG_ONLY_MEM_INDEX 2

#define ERASE_INFILE_MEM_INDEX 3

#define ERASE_DEF_CM_INDEX 4

#define ERASE_MAX_INDEX ERASE_DEF_CM_INDEX

#define CFG_ERASEINFOA 12 \

// disable 0

// enable 1

#define CFG_ERASEINFOB 13

// disable 0

// enable 1

#define CFG_ERASEINFOC 14

// disable 0

// enable 1

#define CFG_ERASEINFOD 15

// disable 0

// enable 1

#define CFG_MASSERASE_AND_INFOA_EN 16

// disable 0

// enable 1

#define CFG_ERASESTARTADDR 17

// FLASH/FRAM start erase address

www.ti.com

MSP-GANG.dll Description

103

SLAU358Q–September 2011–Revised October 2019

Submit Documentation Feedback

Dynamic Link Library for MSP-GANG Programmer

#define CFG_ERASESTOPADDR 18

// FLASH/FRAM end erase address

#define CFG_FLASHREADMODE 19

#define READ_ALL_MEM_INDEX 0

#define READ_PRGMEM_ONLY_INDEX 1

#define READ_INFOMEM_ONLY_INDEX 2

#define READ_DEF_MEM_INDEX 3

#define READ_MEM_MAX_INDEX READ_DEF_MEM_INDEX

#define CFG_READINFOA 20

// disable 0

// enable 1

#define CFG_READINFOB 21

// disable 0

// enable 1

#define CFG_READINFOC 22

// disable 0

// enable 1

#define CFG_READINFOD 23

// disable 0

// enable 1

#define CFG_FINALACTION_MODE 24

#define APPLICATION_NO_RESET 0

#define APPLICATION_TOGGLE_RESET 1

#define APPLICATION_TOGGLE_VCC 2

#define APPLICATION_JTAG_RESET 3

#define APPLICATION_RESET_MAX_INDEX APPLICATION_JTAG_RESET

#define CFG_BEEPMODE 25

// sum of following bits

#define BEEP_PCSPK_EN_BIT 1 //Beep via PC Speaker

enable

#define BEEP_OK_EN_BIT 2 //Beep when OK enable

#define BEEP_SOUND_EN_BIT 4 //Sound enable

#define CFG_DEFERASEMAINEN 26

// disable 0

// enable 1

#define CFG_CUSTOMRESETPULSETIME 27

// time in ms 1.....2000

#define CFG_CUSTOMRESETIDLETIME 28

// time in ms 1.....2000

#define CFG_BSL_ENH_ENABLE 29

// disable 0

// enable 1

#define CFG_BSL_ENH_INDEX 30

//for future usage

#define BSL_ENH_DISABLE 0

#define BSL_ENH_NONE 1

#define BSL_ENH_ERASE 2

#define BSL_ENH_MAX_INDEX 2

MSP-GANG.dll Description

www.ti.com

104

SLAU358Q–September 2011–Revised October 2019

Submit Documentation Feedback

Dynamic Link Library for MSP-GANG Programmer

#define CFG_RETAIN_CAL_DATA_INDEX 31

// disable 0

// enable 1

#define CFG_FINALACTIONRUNTIME 32

// 0 - infinite,

// 1...120 time in seconds

#define CFG_FINALACTIONVCCOFFTIME 33

// Vcc-OFF (then again ON) time after programming when the

// APPLICATION_TOGGLE_VCC option is selected.

#define CFG_DCO_CONST_2XX_VERIFY_EN 35

// disable 0

// enable 1

#define CFG_DCOCAL_2XX_EN 36

// disable 0

// enable 1

#define CFG_BSL_FLASH_WR_EN 37

// mask for 4 BSL segments - disable->0, enable->1

// bit 0 -> 0x01 BSL segment 1

// bit 1 -> 0x02 BSL segment 2

// bit 2 -> 0x04 BSL segment 3

// bit 3 -> 0x08 BSL segment 4

#define CFG_BSL_FLASH_RD_EN 38

// mask for 4 BSL segments - disable->0, enable->1

// bit 0 -> 0x01 BSL segment 1

// bit 1 -> 0x02 BSL segment 2

// bit 2 -> 0x04 BSL segment 3

// bit 3 -> 0x08 BSL segment 4

#define CFG_READMAINMEMEN 39

// disable 0

// enable 1

#define CFG_READDEFSTARTADDR 40

// Memory READ start address

#define CFG_READDEFSTOPADDR 41

// Memory READ end address

#define CFG_COMPORT_NO 42

// Communication COM Port number - 0..255

#define CFG_UART_SPEED 43

// Baud Rate index

#define UART_9600 0

#define UART_19200 1

#define UART_38400 2

#define UART_57600 3

#define UART_115200 4

#define CFG_OPEN_FILE_TYPE 44

#define CODE_FILE_INDEX 0

#define APPEND_FILE_INDEX 1

#define PASSW_FILE_INDEX 2
