4.2.30 MSPGANG_VerifyPSAImageBlock
MSPGANG_VerifyPSAImageBlock verifies the checksum of all blocks used in the selected image
memory. The image memory number should be selected first using MSPGANG_SelectImage function.
Syntax
LONG MSPGANG_VerifyPSAImageBlock(void)
Arguments
None
Result
LONG Error code
4.2.31 MSPGANG_ReadImageBlock
MSPGANG_ReadImageBlock reads the header from the selected image memory. A maximum of
254 bytes can be read. Access to the remaining image memory (up to 512KB) is blocked.
Syntax
LONG MSPGANG_ReadImageBlock(LONG addr, LONG size, void *lpData)
Arguments
LONG address
LONG size
void *lpData Pointer to byte buffer where the result is saved
Result
LONG Error code
Data Format
union _IMAGE_HEADER
{
BYTE bytes[IMAGE_HEADER_SIZE];
WORD words[IMAGE_HEADER_SIZE/2];
struct
{
WORD own_PSA;
WORD global_PSA;
BYTE year;
BYTE month;
BYTE day;
BYTE hour;
BYTE min;
BYTE sec;
#define GLOBAL_PSA_START_OFFSET 10
// down - covered by global_PSA ----
#define SHORT_ID_2BYTE_OFFSET 10
WORD shortID;
#define CHUNKS_NO_2BYTE_OFFSET 12
WORD chunks;
#define IMAGE_DATA_2BYTE_OFFSET 14
WORD image_data_offset;
#define GLOBAL_SIZE_4BYTE_OFFSET 16
DWORD size; //global_size;
www.ti.com
MSP-GANG.dll Description
97
SLAU358Q–September 2011–Revised October 2019
Submit Documentation Feedback
Copyright © 2011–2019, Texas Instruments Incorporated
Dynamic Link Library for MSP-GANG Programmer
WORD ID_rev; //20
BYTE ID_name[HEADER_ID_SIZE]; //22
DWORD DLL_ver; //32
#define HEADER_COMMENT_ADDR 36
char comment[SCRIPT_TEXT_SIZE];
WORD used_tasks_mask; //52
BYTE Interface; //54 type (JTAG, SBW, BSL), speed(Fast,
Med, Slow)
BYTE GangMask; //55
BYTE Vcc_PowerEn; //56
BYTE Icc_HiEn; //57
WORD Vcc_mV; //58
WORD min_Vcc_mV; //60
WORD max_Vcc_mV; //62
WORD RST_time_ms; //64
WORD RST_release_ms; //66
BYTE InfoA_Erase_En; //68
BYTE BSL_Erase_En_mask; //69
BYTE SecureDev_En; //70
BYTE DCO_Flags; //71
#define DCO_RETAIN_EN 0x01
#define DCO_VALIDATION_EN 0x02
#define DCO_RECAL_EN 0x04
#define DCO_ONE_CONSTANTS 0x08
BYTE IO_cfg; //72
#define SBW_VIA_RST_BIT 0x01
BYTE MemoryOption; //73 for GUI only -
for displaying used memory option. No impact in firmware
BYTE InterfaceSpeed; //74 for GUI only -
for displaying used speeds (JTAG/SBW/CJTAG/BSL). No impact in firmware
BYTE VccSettleTime; //75 settle time *20ms
BYTE JTAG_unlockEn : 1; //76
BYTE HasLockedInfoA : 1;
BYTE HasAutoEraseInBSL : 1;
BYTE BSL_X_type : 1;
BYTE spare_flag4 : 1;
BYTE spare_flag5 : 1;
BYTE spare_flag6 : 1;
BYTE spare_flag7 : 1;
BYTE ClrSegments; //77 MSP432
// #define MSP432_CLR_LOCKING_INFOA_BIT 0x01
// #define MSP432_CLR_LOCKING_BSL_BIT 0x02
BYTE BSL_1st_Passw; //78
//BYTE free[112-78];
}prg;
struct
{
BYTE offset[IMAGE_HEADER_CTRL_OFFSET]; //offset 112
BYTE flags; //0x70
#define IMAGE_LOCK 0x10 //must be the same bit as in LOCK_LD_PRJ
BYTE sp1; //0x71
BYTE sp2; //0x72
BYTE sp3; //0x73
BYTE sp4; //0x74
MSP-GANG.dll Description
www.ti.com
98
SLAU358Q–September 2011–Revised October 2019
Submit Documentation Feedback
Copyright © 2011–2019, Texas Instruments Incorporated
Dynamic Link Library for MSP-GANG Programmer
BYTE sp5; //0x75
BYTE sp6; //0x76
BYTE sp7; //0x77
BYTE sp8; //0x78
BYTE sp9; //0x79
BYTE sp10; //0x7A
BYTE sp11; //0x7B
BYTE sp12; //0x7C
BYTE sp13; //0x7D
BYTE sp14; //0x7E
BYTE sp15; //0x7F
}ctrl;
struct
{
BYTE offset[IMAGE_HEADER_SIZE/2];
char MCU_name[SCRIPT_MCU_NAME_SIZE]; //0
WORD Id[2]; //16
WORD SubId[2]; //20
WORD MainEraseMode; //24
WORD minPVcc; //26
WORD RAM_size; //28
WORD SubIDAddr; //30
BYTE FRAM; //32
//#define FRAM_NONE 0
//#define FRAM_ASIC 1
//#define FRAM_MSPXV2_57 2
//#define FRAM_APOLLO 3
//#define FRAM_MSPXV2_59 4
// --- one byte
BYTE DefaultDCO : 1; //33
BYTE ASIC : 1;
BYTE MPU : 1;
BYTE JTAG_Passw : 1;
BYTE BSLprogrammable : 1;
BYTE JTAG_Unlockable : 1;
BYTE BSL_16B_passw : 1;
BYTE F1_80 : 1; //spare
// --- one byte
BYTE TestPin; //34
BYTE CpuX; //35
BYTE Quick_W :1; //36
BYTE Quick_R :1;
BYTE Quick_W_bug :1;
BYTE Quick_0x08 :1;
BYTE Quick_0x10 :1;
BYTE Quick_0x20 :1;
BYTE Quick_0x40 :1;
BYTE Quick_0x80 :1;
BYTE FastFlash; //37
BYTE EnhVerify; //38
BYTE JTAG; //39
BYTE SpyBiWire; //40
BYTE Marginal; //41
