MSP-GANG.dll Description

www.ti.com

106

SLAU358Q–September 2011–Revised October 2019

Submit Documentation Feedback

Dynamic Link Library for MSP-GANG Programmer

#define CFG_SECURE_CODE_SOURCE 58

enum {USER_SOURCE=0, FILE_SOURCE=1};

#define CFG_MSP432_CLR_LOCKING_OPTIONS 59

#define MSP432_CLR_LOCKING_INFOA_BIT 0x01

#define MSP432_CLR_LOCKING_BSL_BIT 0x02

#define MSP432_CLR_LOCKING_MASK ( MSP432_CLR_LOCKING_INFOA_BIT |

MSP432_CLR_LOCKING_BSL_BIT )

#define CFG_WRDEF_EXCLUDE_SECTIONS 60

// mask for 4 Read_Defined excluded sections disable->0, enable->1

// bit 0 -> 0x01 section 1

// bit 1 -> 0x02 section 2

// bit 2 -> 0x04 section 3

// bit 3 -> 0x08 section 4

#define CFG_RDDEF_EXCLUDE_SECTIONS 61

// mask for 4 Read_Defined excluded sections disable->0, enable->1

// bit 0 -> 0x01 section 1

// bit 1 -> 0x02 section 2

// bit 2 -> 0x04 section 3

// bit 3 -> 0x08 section 4

#define CFG_WRDEF_EXCLUDE_S1_START_ADDR 62

#define CFG_WRDEF_EXCLUDE_S1_END_ADDR 63

#define CFG_WRDEF_EXCLUDE_S2_START_ADDR 64

#define CFG_WRDEF_EXCLUDE_S2_END_ADDR 65

#define CFG_WRDEF_EXCLUDE_S3_START_ADDR 66

#define CFG_WRDEF_EXCLUDE_S3_END_ADDR 67

#define CFG_WRDEF_EXCLUDE_S4_START_ADDR 68

#define CFG_WRDEF_EXCLUDE_S4_END_ADDR 69

#define CFG_RDDEF_EXCLUDE_S1_START_ADDR 70

#define CFG_RDDEF_EXCLUDE_S1_END_ADDR 71

#define CFG_RDDEF_EXCLUDE_S2_START_ADDR 72

#define CFG_RDDEF_EXCLUDE_S2_END_ADDR 73

#define CFG_RDDEF_EXCLUDE_S3_START_ADDR 74

#define CFG_RDDEF_EXCLUDE_S3_END_ADDR 75

#define CFG_RDDEF_EXCLUDE_S4_START_ADDR 76

#define CFG_RDDEF_EXCLUDE_S4_END_ADDR 77

#define CFG_RD_TLV_EN 78

#define CFG_SERIALIZATION_EN 80

// disable 0

// enable 1

#define CFG_SN_ADDRESS_IN_MEMORY 81

//address must be even

#define CFG_SN_DATA_SIZE_IN_BYTES 82

//Size must be even 2...16

#define SN_DATA_MAX_SIZE 16

#define CFG_SN_REMOVE_CODE_FROM_SN_LOCATION 83

// disable 0

// enable 1

#define CFG_SN_SOURCE 84

#define SN_SOURCE_DEFINED 0

#define SN_SOURCE_FROM_FILE 1

// 0 - defined

// 1 - from file

www.ti.com

MSP-GANG.dll Description

107

SLAU358Q–September 2011–Revised October 2019

Submit Documentation Feedback

Dynamic Link Library for MSP-GANG Programmer

#define CFG_SN_FORMAT_IN_MEMORY 85

#define SN_FORMAT_LSB_FIRST 0

#define SN_FORMAT_MSB_FIRST 1

#define CFG_SN_DATA_INCREMENT 86

#define CFG_INIT_SN_DATA_0 87

//Bits 0-31 of the SN init data

#define CFG_INIT_SN_DATA_1 (CFG_INIT_SN_DATA_0+1)

//Bits 32-63 of the SN init data

#define CFG_INIT_SN_DATA_2 (CFG_INIT_SN_DATA_0+2)

//Bits 64-91 of the SN init data

#define CFG_INIT_SN_DATA_3 (CFG_INIT_SN_DATA_0+3)

//Bits 92-127 of the SN init data

#define CFG_SN_DESTINATION 91

#define NUMBER_TO_FLASH 0

#define NUMBER_TO_MAC_REG 1

#define CFG_MPU_IPE_WR_LOCKED 92

// disable 0

// enable 1

#define CFG_MPU_IPE_WR_UNLOCKED 93

// disable 0

// enable 1

#define CFG_MPU_IPE_RD_UNLOCKED 94

// disable 0

// enable 1

#define CFG_MPU_IPE_START_ADDR 95

#define CFG_MPU_IPE_END_ADDR 96

#define CFG_ADDITIONAL_COMPORT_NO 200

// 0 - disable (default)

// 1-255 added COM port number 1-255

// MSP432P protection configuration

#define CFG_MSP432_MB_CMD 300

#define CFG_MSP432_MB_JTAG_SWD_LOCK_SECEN 301

#define CFG_MSP432_MB_JTAG_SWD_LOCK_AES_INIT_VECT0 302

#define CFG_MSP432_MB_JTAG_SWD_LOCK_AES_INIT_VECT1 303

#define CFG_MSP432_MB_JTAG_SWD_LOCK_AES_INIT_VECT2 304

#define CFG_MSP432_MB_JTAG_SWD_LOCK_AES_INIT_VECT3 305

#define CFG_MSP432_MB_JTAG_SWD_LOCK_AES_SECKEYS0 306

#define CFG_MSP432_MB_JTAG_SWD_LOCK_AES_SECKEYS1 307

#define CFG_MSP432_MB_JTAG_SWD_LOCK_AES_SECKEYS2 308

#define CFG_MSP432_MB_JTAG_SWD_LOCK_AES_SECKEYS3 309

#define CFG_MSP432_MB_JTAG_SWD_LOCK_AES_SECKEYS4 310

#define CFG_MSP432_MB_JTAG_SWD_LOCK_AES_SECKEYS5 311

#define CFG_MSP432_MB_JTAG_SWD_LOCK_AES_SECKEYS6 312

#define CFG_MSP432_MB_JTAG_SWD_LOCK_AES_SECKEYS7 313

#define CFG_MSP432_MB_JTAG_SWD_LOCK_UNENC_PWD0 314

#define CFG_MSP432_MB_JTAG_SWD_LOCK_UNENC_PWD1 315

#define CFG_MSP432_MB_JTAG_SWD_LOCK_UNENC_PWD2 316

#define CFG_MSP432_MB_JTAG_SWD_LOCK_UNENC_PWD3 317

#define CFG_MSP432_MB_SEC_ZONE0_SECEN 318

#define CFG_MSP432_MB_SEC_ZONE0_START_ADDR 319

#define CFG_MSP432_MB_SEC_ZONE0_LENGTH 320

#define CFG_MSP432_MB_SEC_ZONE0_AESINIT_VECT0 321

#define CFG_MSP432_MB_SEC_ZONE0_AESINIT_VECT1 322

#define CFG_MSP432_MB_SEC_ZONE0_AESINIT_VECT2 323

MSP-GANG.dll Description

www.ti.com

108

SLAU358Q–September 2011–Revised October 2019

Submit Documentation Feedback

Dynamic Link Library for MSP-GANG Programmer

#define CFG_MSP432_MB_SEC_ZONE0_AESINIT_VECT3 324

#define CFG_MSP432_MB_SEC_ZONE0_SECKEYS0 325

#define CFG_MSP432_MB_SEC_ZONE0_SECKEYS1 326

#define CFG_MSP432_MB_SEC_ZONE0_SECKEYS2 327

#define CFG_MSP432_MB_SEC_ZONE0_SECKEYS3 328

#define CFG_MSP432_MB_SEC_ZONE0_SECKEYS4 329

#define CFG_MSP432_MB_SEC_ZONE0_SECKEYS5 330

#define CFG_MSP432_MB_SEC_ZONE0_SECKEYS6 331

#define CFG_MSP432_MB_SEC_ZONE0_SECKEYS7 332

#define CFG_MSP432_MB_SEC_ZONE0_UNENC_PWD0 333

#define CFG_MSP432_MB_SEC_ZONE0_UNENC_PWD1 334

#define CFG_MSP432_MB_SEC_ZONE0_UNENC_PWD2 335

#define CFG_MSP432_MB_SEC_ZONE0_UNENC_PWD3 336

#define CFG_MSP432_MB_SEC_ZONE0_ENCUPDATE_EN 337

#define CFG_MSP432_MB_SEC_ZONE0_DATA_EN 338

#define CFG_MSP432_MB_SEC_ZONE1_SECEN 339

#define CFG_MSP432_MB_SEC_ZONE1_START_ADDR 340

#define CFG_MSP432_MB_SEC_ZONE1_LENGTH 341

#define CFG_MSP432_MB_SEC_ZONE1_AESINIT_VECT0 342

#define CFG_MSP432_MB_SEC_ZONE1_AESINIT_VECT1 343

#define CFG_MSP432_MB_SEC_ZONE1_AESINIT_VECT2 344

#define CFG_MSP432_MB_SEC_ZONE1_AESINIT_VECT3 345

#define CFG_MSP432_MB_SEC_ZONE1_SECKEYS0 346

#define CFG_MSP432_MB_SEC_ZONE1_SECKEYS1 347

#define CFG_MSP432_MB_SEC_ZONE1_SECKEYS2 348

#define CFG_MSP432_MB_SEC_ZONE1_SECKEYS3 349

#define CFG_MSP432_MB_SEC_ZONE1_SECKEYS4 350

#define CFG_MSP432_MB_SEC_ZONE1_SECKEYS5 351

#define CFG_MSP432_MB_SEC_ZONE1_SECKEYS6 352

#define CFG_MSP432_MB_SEC_ZONE1_SECKEYS7 353

#define CFG_MSP432_MB_SEC_ZONE1_UNENC_PWD0 354

#define CFG_MSP432_MB_SEC_ZONE1_UNENC_PWD1 355

#define CFG_MSP432_MB_SEC_ZONE1_UNENC_PWD2 356

#define CFG_MSP432_MB_SEC_ZONE1_UNENC_PWD3 357

#define CFG_MSP432_MB_SEC_ZONE1_ENCUPDATE_EN 358

#define CFG_MSP432_MB_SEC_ZONE1_DATA_EN 359

#define CFG_MSP432_MB_SEC_ZONE2_SECEN 360

#define CFG_MSP432_MB_SEC_ZONE2_START_ADDR 361

#define CFG_MSP432_MB_SEC_ZONE2_LENGTH 362

#define CFG_MSP432_MB_SEC_ZONE2_AESINIT_VECT0 363

#define CFG_MSP432_MB_SEC_ZONE2_AESINIT_VECT1 364

#define CFG_MSP432_MB_SEC_ZONE2_AESINIT_VECT2 365

#define CFG_MSP432_MB_SEC_ZONE2_AESINIT_VECT3 366

#define CFG_MSP432_MB_SEC_ZONE2_SECKEYS0 367

#define CFG_MSP432_MB_SEC_ZONE2_SECKEYS1 368

#define CFG_MSP432_MB_SEC_ZONE2_SECKEYS2 369

#define CFG_MSP432_MB_SEC_ZONE2_SECKEYS3 370

#define CFG_MSP432_MB_SEC_ZONE2_SECKEYS4 371

#define CFG_MSP432_MB_SEC_ZONE2_SECKEYS5 372

#define CFG_MSP432_MB_SEC_ZONE2_SECKEYS6 373

#define CFG_MSP432_MB_SEC_ZONE2_SECKEYS7 374

#define CFG_MSP432_MB_SEC_ZONE2_UNENC_PWD0 375

#define CFG_MSP432_MB_SEC_ZONE2_UNENC_PWD1 376

#define CFG_MSP432_MB_SEC_ZONE2_UNENC_PWD2 377

#define CFG_MSP432_MB_SEC_ZONE2_UNENC_PWD3 378

#define CFG_MSP432_MB_SEC_ZONE2_ENCUPDATE_EN 379

#define CFG_MSP432_MB_SEC_ZONE2_DATA_EN 380

#define CFG_MSP432_MB_SEC_ZONE3_SECEN 381

#define CFG_MSP432_MB_SEC_ZONE3_START_ADDR 382

#define CFG_MSP432_MB_SEC_ZONE3_LENGTH 383
