5 TECHNICAL REFERENCE
5.4 REPLACEMENT PROCEDURES
36 STANDALONE MANUAL HIGH FLOW VACUUM (TQ) 12/2020
5.4.6 Tooling Table Surface Plate
WARNING
BOARD CLAMPS. EXTREME CARE MUST BE EXERCISED WHEN WORKING IN
THE TOOLING AREA OF THE MACHINE TO AVOID INJURY. THE FOILS ON THE
FRONT AND REAR BOARD CLAMPS ARE VERY SHARP.
1
2
1. On the HMI select the Menu button.
2. Select Service.
3. Select Diagnostics.
4. Select Confirm.
5. Select Chase.
6. Select Unload Stencil.
7. Open the front cover.
8. Remove any non-reusable items: squeegees, material, support tooling etc.
9. Close the front cover.
10. Press the System button.
11. Select Table and Conveyor Lift.
12. Select Print Height.
13. Read the warning and select Confirm.
14. Open the front cover.
15. Remove the two 4mm x 40 cap head screws (12) with an M3 Allen key.
16. Lift the tooling tabletop off the lifting table.
17. Fit the replacement tooling tabletop using the 4mm screws.
18. Clean the top of the tooling table surface plate.
19. Fit any tooling, as required.
20. Load the stencil into the chase.
5 TECHNICAL REFERENCE
5.4 REPLACEMENT PROCEDURES
STANDALONE MANUAL HIGH FLOW VACUUM (TQ) 12/2020 37
21. Close the front cover.
22. Press the System button.
23. Select Home.
24. Select Chase.
25. Select Load Stencil.
26. Select Exit.
27. Select Accept.
5 TECHNICAL REFERENCE
5.5 MAINTENANCE
38 STANDALONE MANUAL HIGH FLOW VACUUM (TQ) 12/2020
5.5 MAINTENANCE
WARNING
BOARD CLAMPS. EXTREME CARE MUST BE EXERCISED WHEN WORKING IN
THE TOOLING AREA OF THE MACHINE TO AVOID INJURY. THE FOILS ON THE
FRONT AND REAR BOARD CLAMPS ARE VERY SHARP.
MANDATORY
TOXIC SUBSTANCES MAY BE PRESENT. SAFETY GLOVES MUST BE WORN.
MANDATORY
TOXIC SUBSTANCES MAY BE PRESENT. EYE PROTECTION MUST BE WORN.
5.5.1 Daily
Daily maintenance consists of cleaning the parts:
●
Tooling Table Surface Plate (2)
●
Vacuum Tooling (not shown)
