Installation and Configuration Guide SIPLACE Explorer 4 Configur ation Edition 11/2020 EN 4.1 Standard Monitoring Application (SMA) 5 9 NOTE We recommend activating this DB compression step, when the user has restored th…
4 Configuration Installation and Configuration Guide SIPLACE Explorer
4.1 Standard Monitoring Application (SMA) Edition 11/2020 EN
58
Enter the following information here:
– the folder where the website will be generated to;
– the website URL;
This URL contains a port number, which applies to the web server (Tomcat) e.g. "8080". If
you change the port number here, you will also need to update the port number of the web
server see “Port Configuration after Changing Tomcat Port Number” on page 37.
– the refresh rate;
For capacity purposes, we recommend a refresh rate of at least one minute (60000 ms).
– website language
– specify whether the login page is to be generated
If Excel 2007 or Excel Viewer 2007 is installed, disable the MS Excel documents compatible
with MS Excel 2007 option. The new features of Excel 2007 for a better display are used
during the xlsx generation for websites.
Once you have made and checked all entries, click on the Build button.
Dependent of the database size, you can compress the database. The Compress System
Database dialog box will open.
4
Fig. 4 - 25 Compress DB
If you want to compress the DB now, select the Compress now option. Confirm with OK.
Installation and Configuration Guide SIPLACE Explorer 4 Configuration
Edition 11/2020 EN 4.1 Standard Monitoring Application (SMA)
59
NOTE
We recommend activating this DB compression step, when the user has restored the
SIPLACE Explorer line database or has moved the raw database files to another disk or to
another computer.
With the DB compression it is possible to avoid extended access times of the websites.
The DB compression may take up to one hour, this time depends on the size of the database
and the performance of the computer. 4
If you have enabled the Backup database option, the DB backup location dialog box will
open.
4
Fig. 4 - 26 DB backup location
If enabled, before performing the compression, the system creates a backup file of the
database. Specify the folder for this file in the Folder for database backup field. Click on the
Browse ... button to select an existing folder.
Confirm your choice with OK. The DB compression will be started.
An information box will appear, showing the DB compression and the website generation.
4 Configuration Installation and Configuration Guide SIPLACE Explorer
4.2 Configuring the Factory Configuration Utility Edition 11/2020 EN
60
4
Fig. 4 - 27 Build configuration
At this point, the application is generated automatically and is loaded into SIPLACE Explorer.4
Once the website has been fully generated, click on Close. The SMA has been completed.
Click on the Exit button in the Line Configuration - Website Generation dialog box.
4.2 Configuring the Factory Configuration Utility
4.2.1 Starting the SIPLACE Factory Configuration Utility
Start the SIPLACE Factory Configuration Utility via the Programs SIPLACE Explorer
Factory Configuration Utility menu in Windows.
Or click on the Factory Configuration Utility icon on your desktop.
NOTE
Access to the Runtime Environment tools is restricted or permitted as required, by using the
SE Security Manager. For details of the relevant settings in the SE Security Manager, refer
to the Getting Started for SIPLACE Explorer. 4
The Load settings from... dialog box will open. You need to establish a connection to the
factory database, before data can be called up.
