00197728-12_IM_SE3.11_EN.pdf - 第63页
Installation and Configuration Guide SIPLACE Explorer 4 Configur ation Edition 11/2020 EN 4.2 Configuring the Factory C onfiguration Uti lity 6 3 C onfirm your entries with OK . The DB backup location dialog box will o…
4 Configuration Installation and Configuration Guide SIPLACE Explorer
4.2 Configuring the Factory Configuration Utility Edition 11/2020 EN
62
If the connection does not function properly, you will see the following information box:
4
Fig. 4 - 29 DB error
Click on the Setup DB Connection button to start the DB Connection Wizard setup
sequence and configure the SIPLACE Explorer factory database. Follow the instructions at
“Database Connection Wizard” on page 80.
If the connection functions properly, you will see the following information box:
4
Fig. 4 - 30 Success
Click OK. The system will check the database data. If the database has data from SIPLACE
Explorer 2.0 - 3.10, you will need to convert the database for SIPLACE 3.11, due to the
changed data structure in the SIPLACE Explorer 3.11 database. In this case, the Convert
Database dialog box will open.
NOTE
Consider the following when converting the database
- You require database administrator privileges.
- Once you have started the conversion, this process can not be stopped.
- The conversion time depends on the size of the database and on the performance of the
computer. It may take up to one hour. 4
Specify the access data for the database administrator and enable the Backup database
option.
Installation and Configuration Guide SIPLACE Explorer 4 Configuration
Edition 11/2020 EN 4.2 Configuring the Factory Configuration Utility
63
Confirm your entries with OK. The DB backup location dialog box will open
4
Fig. 4 - 31 DB backup location
Before performing the conversion, the system creates a backup file of the database. Specify
the folder for this file in the Folder for database backup field. Click on the Browse ...
button to select an existing folder.
Confirm your choice with OK. The database will be converted. This may take up to one
hour. The conversion time depends on the size of the database.
4
Fig. 4 - 32 DB backup
After successful conversion of the database, the following information window will open:
4
Fig. 4 - 33 Success
Dependent of the database size, you can compress the database, the following information
window will open:
4
Fig. 4 - 34 Database compression
4 Configuration Installation and Configuration Guide SIPLACE Explorer
4.2 Configuring the Factory Configuration Utility Edition 11/2020 EN
64
NOTE
We recommend activating this DB compression step, when the user has restored the
SIPLACE Explorer factory database or has moved the raw database files to another disk or
to another computer.
With the DB compression it is possible to avoid extended access times of the websites. 4
Click Yes, to compress the database at next DB maintenance.
Click OK. The Factory Configuration Utility dialog box will open.
4.2.2 Configuring Production Lines
The SIPLACE Explorer Factory Configuration Utility can be used to add production lines to an ex-
isting list of lines to be monitored. This is performed by calling up the relevant production line data
from the SIPLACE Explorer host. A list of the lines already configured in SIPLACE Explorer will
be provided via the connection to the SIPLACE Explorer host. 4
If you have already configured a production line with the Line Configuration and generated a web-
site, the configured production line will automatically be added to the Factory Configuration Utility
and to the factory website. 4
NOTE
We do not recommend that you change the production line data in SIPLACE Explorer Factory
Configuration Utility. If you do so, you must also adjust/synchronize this data in the SIPLACE
Explorer host. 4
After editing the data in the Factory Configuration Utility, save the modified data in the factory da-
tabase in which all Factory Configuration Utility data are stored. During data backup, data is sent
between the SIPLACE Explorer line host and the factory host. To be more exact, the sequence of
transfer is from the SIPLACE Explorer factory host to the line host and from the SIPLACE Explorer
line host to the SIPLACE Explorer factory host. 4
Transfer of data from SIPLACE Explorer factory host to SIPLACE Explorer line host: 4
– Factory Calendar
– Factory database settings
– Central user management, with e-mail accounts
