Installation and Configuration Guide SIPLACE Explorer 4 Configur ation Edition 11/2020 EN 4.2 Configuring the Factory C onfiguration Uti lity 6 1 4 Fig. 4 - 28 Loading settings Enter the followin g information: – MS SQ…
4 Configuration Installation and Configuration Guide SIPLACE Explorer
4.2 Configuring the Factory Configuration Utility Edition 11/2020 EN
60
4
Fig. 4 - 27 Build configuration
At this point, the application is generated automatically and is loaded into SIPLACE Explorer.4
Once the website has been fully generated, click on Close. The SMA has been completed.
Click on the Exit button in the Line Configuration - Website Generation dialog box.
4.2 Configuring the Factory Configuration Utility
4.2.1 Starting the SIPLACE Factory Configuration Utility
Start the SIPLACE Factory Configuration Utility via the Programs SIPLACE Explorer
Factory Configuration Utility menu in Windows.
Or click on the Factory Configuration Utility icon on your desktop.
NOTE
Access to the Runtime Environment tools is restricted or permitted as required, by using the
SE Security Manager. For details of the relevant settings in the SE Security Manager, refer
to the Getting Started for SIPLACE Explorer. 4
The Load settings from... dialog box will open. You need to establish a connection to the
factory database, before data can be called up.
Installation and Configuration Guide SIPLACE Explorer 4 Configuration
Edition 11/2020 EN 4.2 Configuring the Factory Configuration Utility
61
4
Fig. 4 - 28 Loading settings
Enter the following information:
– MS SQL Server:port number
You can add the port number to the SQL Server instance, separated by a colon, for
example: PLK0495A\SIPLACE_2005EXPR:12345.
– Database name
– Database user
– DB password
NOTE
Click on the Browse for SQL instances icon. All SQL server instances available will be
shown in the Select SQL Server instance dialog box.
If the Select SQL Server instance dialog box shows no entries, you need to specify the SQL
server instance manually in the MS SQL Server field. 4
After entering the database access parameters, we strongly recommend that you check the
connection to the database. Click Test to check whether the connection to the database can
be established.
4 Configuration Installation and Configuration Guide SIPLACE Explorer
4.2 Configuring the Factory Configuration Utility Edition 11/2020 EN
62
If the connection does not function properly, you will see the following information box:
4
Fig. 4 - 29 DB error
Click on the Setup DB Connection button to start the DB Connection Wizard setup
sequence and configure the SIPLACE Explorer factory database. Follow the instructions at
“Database Connection Wizard” on page 80.
If the connection functions properly, you will see the following information box:
4
Fig. 4 - 30 Success
Click OK. The system will check the database data. If the database has data from SIPLACE
Explorer 2.0 - 3.10, you will need to convert the database for SIPLACE 3.11, due to the
changed data structure in the SIPLACE Explorer 3.11 database. In this case, the Convert
Database dialog box will open.
NOTE
Consider the following when converting the database
- You require database administrator privileges.
- Once you have started the conversion, this process can not be stopped.
- The conversion time depends on the size of the database and on the performance of the
computer. It may take up to one hour. 4
Specify the access data for the database administrator and enable the Backup database
option.
