9.2 ACCESSORIES
BENCH MOUNTING KIT
PART NUMBER DESCRIPTION
918-033-000
918-000-012
Production master stand
Rod clamp
TE SERIES NEEDLE
HUB (POLYPROPYLENE)
CANNULA (STAINLESS STEEL)
GAUGECOLOR HUBPART #
TE714050 OLIVE 14
Ø"A" DIM."C" DIM.
1/2" 0.0610/0.0650
Ø"B" DIM.
0.0820/0.0840
TE732025 YELLOW 32 0.0090/0.00950.0035/0.00501/4"
TE714100
TE714150 OLIVE
OLIVE
14
14 0.0820/0.0840
0.0820/0.0840
0.0610/0.0650
0.0610/0.06501-1/2"
1.0"
AMBER 15 1/2" 0.0525/0.0555 0.0715/0.0725TE715050
TE715150
TE715100 AMBER
AMBER
15
15
1.0"
1-1/2"
0.0525/0.0555
0.0525/0.0555
0.0715/0.0725
0.0715/0.0725
GREENTE718050 18 1/2" 0.0315/0.0345 0.0495/0.0505
GREEN
GREEN
TE718100
TE718150
18
18
1.0"
1-1/2"
0.0315/0.0345
0.0315/0.0345
0.0495/0.0505
0.0495/0.0505
PINK 20TE720050 1/2" 0.0230/0.0245 0.0355/0.0360
PINK
PINK
20
20TE720150
TE720100 1.0"
1-1/2"
0.0230/0.0245
0.0230/0.0245
0.0355/0.0360
0.0355/0.0360
PURPLETE721050 1/2"21 0.0195/0.0210 0.0320/0.0325
PURPLE
PURPLE
TE721100
TE721150
1.0"
1-1/2"
21
21
0.0195/0.0210
0.0195/0.0210
0.0320/0.0325
0.0320/0.0325
BLUETE722050 22 1/2" 0.0155/0.0170 0.0280/0.0285
BLUE
BLUE
TE722100
TE722150
22
22
1.0"
1-1/2"
0.0155/0.0170
0.0155/0.0170
0.0280/0.0285
0.0280/0.0285
ORANGETE723050 23 1/2" 0.0125/0.0140 0.0250/0.0255
ORANGE
ORANGE
TE723100
TE723150
23
23
1.0"
1-1/2"
0.0125/0.0140
0.0125/0.0140
0.0250/0.0255
0.0250/0.0255
TE725050 RED 25 1/2" 0.0095/0.0110 0.0200/0.0205
TE725100
TE725150 RED
RED
25
25 1.0"
1-1/2"
0.0095/0.0110
0.0095/0.0110
0.0200/0.0205
0.0200/0.0205
CLEARTE727050 0.0075/0.009027 1/2" 0.0160/0.0165
TE727025 CLEAR 27 1/4" 0.0075/0.0090 0.0160/0.0165
TE730050 LAVENDER 30 1/2" 0.0055/0.0070 0.0120/0.0125
TE730025 LAVENDER 30 1/4" 0.0055/0.0070 0.0120/0.0125
(.684±.025)
(Ø.170)
"C" DIM.
"B" DIM.
"A" DIM.
13
10. LIMITED WARRANTY
Manufacturer warrants this product to the original purchaser for a period of one (1) year from date of
purchase to be free from defects in material and workmanship, but not against damages by misuse,
negligence, accident, faulty installations and instructions. Manufacturer will repair or replace (at
factory’s option), free of charge, any component of the equipment thus found to be defective, on return
of the component “PREPAID” to the factory during the warranty period. In no event shall any liability
or obligation of the Manufacturer arising from this warranty exceed the purchase price of the equipment.
This warranty is only valid if the defective product is returned as a complete assembly without physical
damage. The Manufacturer’s liability, as stated herein, cannot be altered or enlarged except by a written
statement signed by an officer of the company. In no event shall the Manufacturer be liable for
consequential or incidental damages. A return authorization is required from Techcon Systems prior to
shipping a defective unit to the factory.
Manufacturer reserves the right to make engineering product modifications without notice.
Send warranty returns to:
OK International
Garden Grove Division
12151 Monarch Street
Garden Grove, Ca 92841
