GEM Manual for DEK Printers Equipment Variables
Issue 1.1 March 20th, 2014 Page 102 of 152 Page 102 of 152
7.1 Introduction
A set of variable definitions is provided to enable the host to monitor and sometimes alter, the
behaviour of the equipment. These are known as machine variables.
Machine variables are divided into the following three categories.
Equipment Constants: Allow the host to modify certain aspects of the equipment’s
behaviour. See section 5.5 for a discussion on the use of EC’s.
Status Variables: As the name suggests, these variables track continuous system
status values. The host can interrogate the equipment at any time
and can programme the equipment to transmit values on a
regular schedule. The host cannot change these values.
See section 5.2 for a discussion on data collection methods.
Discrete Data Variables: Are similar to Status Variables except that their values are valid
only when specific events occur. The host should not interrogate
these values, but should include them in reports linked to
collection events.
See section 5.2 for a discussion in on data collection methods.
Process Attributes: These variables are used to request name and value information
about the currently loaded printer product.
The machine variables are listed by category in the following sections.
GEM Manual for DEK Printers Equipment Variables
Issue 1.1 March 20th, 2014 Page 103 of 152 Page 103 of 152
7.2 Equipment Constants
The equipment constants are defined in the table below:
Note: Default values are shown bold.
NAME
ECID
DESCRIPTION
Type
Value Range
GemConfigConnect
1
Select establish communications type.
U1
1 = S1F13
DeviceName
2
Equipment name as defined by the host.
A20
20 characters
GemEstabCommDelay
3
Time between each S1F13 poll.
U2
0-60-1800 s
GemPollDelay
4
Time between each S1F1 poll.
U2
0-60-1800 s
GemInitCommState
5
Initial communications state.
U1
1 = Enable
0 = Disable
GemInitControlState
6
Initial control state.
U1
1 = OFF-LINE
2 = ON-LINE
GemOfflineSubstate
7
Set default control sub-state when equipment is
OFF-LINE.
U1
1 = Equipment Off-Line
2 = Attempt On-Line
3 = Host Off-Line
GemOnlineFailed
8
Default sub-state following ON-LINE failure.
U1
1 = Equipment Off-Line
2 = Host Off-Line
GemOnlineSubstate
9
Default sub-state when entering ON-LINE state.
U1
4 = Local
5 = Remote
received_mode
10
Set System Mode. This constant is volatile and
defaults to Auto on machine power up.
U1
1 = Auto
3 = Pass Through
InspectRate
11
Number of print cycles between board
inspections. 0 indicates no inspection
F8
0 – 100
BatchLimit
12
Number of boards to be printed in a production
batch. O indicates no batch limit
U4
0 - 99999
process_adjustments
13
Enables/disables adjustment of the current
printing process while the machine is running.
U1
0 = Enabled
1 = Operator disabled
2 = Remote command
disabled
3 = Both disabled
MaxSpoolTransmit
14
The maximum number of messages that the
equipment will transmit from the spool in
response to a S6F23”Transmit spooled
Messages” request. If MaxSpoolTransmit is set
to zero, no limit is placed on the messages sent
from the spool. Multi-block inquire/grant
messages are not counted in this total.
U4
Minimum = 0
Maximum = value of
SpoolCountActual
OverWriteSpool
15
Tells the printer to overwrite data in the spool
area or stop spooling whenever the spool area
limits are exceeded.
B1
1 = TRUE to overwrite
spooled data
0 = FALSE to stop
spooling when limits are
exceeded.
spooling_enabled
16
Allows the equipment to default to a condition
where spooling is disabled completely. This is
provided for older Hosts that do not support
S6F23. This EC is set to TRUE = 1 on receipt of
S2F43 defining messages to be spooled.
B1
0 = FALSE spooling
disabled
If the Host sets this EC to
FALSE any data in the
spool will be purged.
Reserved
17-39
Not used by the 265.
TimeFormat
40
The setting of this ECV controls whether the
equipment shall send the Data Items STIME and
TIME in 12-byte or 16-byte format. It also
controls the format of START_TIME. to be 6 or
7 bytes.
B1
0 = 12 byte format
1 = 16 byte format
>1 reserved
GEM Manual for DEK Printers Equipment Variables
Issue 1.1 March 20th, 2014 Page 104 of 152 Page 104 of 152
RunGEMRemote
41
Allows control of the Run With GEM Remote
parameter. When enabled, only the host can
start the printer and the operator is given an
appropriate message.
U1
0 = Disable
1 = Enable
CompoundProductFiles
46
Controls whether Compound Product
functionality is enabled or disabled.
U1
0 = Disable
1 = Enable
Make
50
Printer make. Always returns “DEK”
A20
“DEK”
Model
51
The model of the printer
A20
For example “Galaxy”
StencilCleaningSystem
53
The currently selected cleaner module
U1
0 = None
1 = Blue
2 = Vortex
3 = Cyclone
ApplicatorType
54
The currently selected applicator module
U1
0 = Squeegees
1 = ProFlow (classic)
2 = Ball Placement
3 = ProFlow Tx
4 = ProFlow ATx
ConveyorType
55
The fitted conveyor type
U1
0 = Standard
1 = HTC
2 = RTC
TransportMode
56
The current rail transport mode
U1
0=LeftToRight
1=RightToLeft
2=RightToRight
3=LeftToLeft
4=NoTransfer/Shuttle
MachineUnits
57
The current machine units
U1
0=Metric
1=Imperial
UplineProtocol
58
The current up-line FMI protocol
U1
0=NoFMI
1=MIU
2=Manual
DownlineProtocol
59
The current downline FMI protocol
U1
0=NoFMI
1=MIU
2=Manual
TransferPeriod
60
FMI transfer period (s)
U2
0 – 999, 20
PasteDispensePosition
61
The position the paste dispenser uses
U1
0=Front
1=Rear
2=Auto
ToolingHardware
62
The currently selected tooling type
U1
0=Magnetic
2=Vacuum
6=FormFlex
7=GridLok
FiducialReference
63
The current fiducial reference
U1
0=Left
1=Right
ProductBarcodeHardw
are
64
The status of the product barcode scanner
U1
0=Not Fitted
1=Fitted
RemoteBarcodeHardw
are
65
The status of the remote barcode scanner
U1
0=Not Fitted
1=Fitted
AdvancedProflow
66
Status of the Advanced ProFlow option
U1
0=Disabled
1=Enabled
PressureHardware
67
The currently selected pressure hardware
U1
0=NotFitted
1=Fitted
PasteDispenser
68
The status of the automatic paste dispenser
U1
0=NotFitted
1=Fitted
ScreenSize
69
The current screen type selection
U1
0=256
1=Fuji
2=249
3=Sanyo
4=Library
