GEM Manual for DEK Printers Equipment Variables
Issue 1.1 March 20th, 2014 Page 114 of 152 Page 114 of 152
Category
Item Name
Description and Comments
Rear Pressure
The rear squeegee process defined pressure value
(not actual – SPC data contains actual).
Front Print Speed
The process defined front print speed (i.e. the rate
the front squeegee moves when performing the
print stroke). The SPC data contains the actual
value.
Rear Print Speed
The process defined rear print speed (i.e. the rate
the rear squeegee moves when performing the
print stroke). The SPC data contains the actual
value.
Print Front Limit
The maximum limit the front print stroke can be
started from
Print Rear Limit
The maximum limit the rear print stroke can be
started from
Forward X Offset
The offset applied in X to the screen when
performing the forward print stroke
Reverse X Offset
The offset applied in X to the screen when
performing the rear print stroke
Forward Y Offset
The offset in Y applied to the screen during the
front print stroke
Reverse Y Offset
The offset in Y applied to the screen during the
rear print stroke
Reverse Theta Offset
The angle at which the screen is positioned for the
reverse print stroke
Forward Theta Offset
The angle at which the screen is positioned for the
forward print stroke
Separation Speed
The rate at which the board is separated from the
screen/stencil.
Separation Distance
The distance the separation speed applies to
before separating normally.
Print Gap
The gap left between the board and stencil/screen
when printing.
Clean Rate 1 / Cyclone Clean Rate /
Blue Clean Rate
The number of print cycles that the clean 1,
cyclone or blue cleaner operation occurs.
Clean Rate 2
The number of print cycles that the clean 2
operation occurs.
Vortex Clean Rate
The number of print cycles that the Vortex clean
operation occurs.
Paste While Clean
Indicates if a dispense operation is performed
when a clean operation occurs.
Paste Dispense Rate
The number of prints that occur before the paste
dispenser performs a dispense operation.
Alternative Dispense Rate
The number of prints that occur before the
alternative dispense operation is performed.
Proflow System Pressure
The pressure that was applied to the Proflow unit
when printing
Ball Place App Speed
The rate at which the ball placement applicator
moves
Ball Place App Dist
The distance the ball placement applicator moves
Ball Place Tbl Dwn Speed
The rate at which the table moves down when
using ball placement
Ball Place Hopper Pressure
The pressure applied to the ball placement hopper
SPC
X Pre Align Dev
Deviation in the x axis for the pre print alignment
Y Pre Align Dev
Deviation in the y axis for the pre print alignment
Theta Pre Align Dev
Deviation in the theta angle for the pre print
alignment
Board Stretch
The board length.
Pre Board Stretch
Deviation in the pre print board length stretch
Pre Fid 1 X Align Dev
Pre fiducial 1 deviation in the x alignment
GEM Manual for DEK Printers Equipment Variables
Issue 1.1 March 20th, 2014 Page 115 of 152 Page 115 of 152
Category
Item Name
Description and Comments
Pre Fid 1 Y Align Dev
Pre fiducial 1 deviation in the y alignment
Pre Fid 2 X Align Dev
Pre fiducial 2 deviation in the x alignment
Pre Fid 2 Y Align Dev
Pre fiducial 2 deviation in the y alignment
Pre Fid 3 X Align Dev
Pre fiducial 3 deviation in the x alignment
Pre Fid 3 Y Align Dev
Pre fiducial 3 deviation in the y alignment
X Align Dev
Deviation in the X axis alignment
Y Align Dev
Deviation in the Y axis alignment
Theta Align Dev
Deviation in the theta alignment
Board 1 Fid Score
The score of the first defined fiducial on the
board.
Screen 1 Fid Score
The score of the first defined fiducial on the
screen.
Board 2 Fid Score
The score of the second defined fiducial on the
board.
Screen 2 Fid Score
The score of the second defined fiducial on the
screen.
Board 3 Fid Score
The score of the third defined fiducial on the
board.
Screen 3 Fid Score
The score of the third defined fiducial on the
screen.
Front X Act Rel Move
Front X actuator relative movement
Rear X Act Rel Move
Rear X actuator relative movement
Act Y Rel Move
Y Actuator relative movement
Actual Front Pressure
The measured front squeegee / Proflow pressure.
Actual Rear Pressure
The measured rear squeegee pressure.
Actual Separation Speed
The measured separation speed when performing
the print operation.
Actual Temperature
The measured internal temperature
Actual Humidity
The measured relative humidity
Cycle Time
The number of seconds taken to perform the print
operation.
Table Position
The height of the table when at print position.
Post Fid 1 X Align Dev
Post fiducial 1 deviation in the x alignment
Post Fid 1 Y Align Dev
Post fiducial 1 deviation in the x alignment
Post Fid 2 X Align Dev
Post fiducial 2 deviation in the x alignment
Post Fid 2 Y Align Dev
Post fiducial 2 deviation in the y alignment
Post Fid 3 X Align Dev
Post fiducial 3 deviation in the x alignment
Post Fid 3 Y Align Dev
Post fiducial 3 deviation in the y alignment
Front X Act Pos
Front X actuator absolute position
Rear X Act Pos
Rear X actuator absolute position
Act Y Pos
Y actuator absolute position
Actual Front Print Speed
The measured print speed variation for the front
squeegee.
Actual Rear Print Speed
The measured print speed variation for the rear
squeegee.
Hawkeye Area Error
The number of Hawkeye sites in error
Hawkeye Area Warning
The number of Hawkeye sites in warning
Hawkeye Feat Error
The number of Hawkeye features in error
Hawkeye Feat Warning
The number of Hawkeye features in warning
Verification Data
Product Index
The name of the verification index that passed the
product identifier validation
Screen ID
The value of the identifier (barcode) that is
currently being used for the stencil or screen.
Stencil Screen Index
The name of the verification index that passed the
screen or stencil identifier validation
Print Medium ID
The value of the identifier (barcode) that is
currently being used for the print medium (manual
paste etc..)
GEM Manual for DEK Printers Equipment Variables
Issue 1.1 March 20th, 2014 Page 116 of 152 Page 116 of 152
Category
Item Name
Description and Comments
Print Medium Index
The name of the verification index that passed the
Print Medium identifier validation
Print Medium Cartridge ID
The value of the identifier (barcode) that is
currently being used for the print medium
cartridge (paste dispenser etc..)
Print Medium Cartridge Index
The name of the verification index that passed the
Print Medium Cartridge identifier validation
Tooling ID
The value of the identifier (barcode) that is
currently being used for the tooling (magnetic,
custom etc..)
Tooling Index
The name of the verification index that passed the
Tooling identifier validation
Vortex Cassette ID
The value of the identifier (barcode) that is
currently being used for the vortex cleaner
cassette.
Vortex Cassette Index
The name of the verification index that passed the
Vortex Cassette identifier validation
Cleaner Solvent ID
The value of the identifier (barcode) that is
currently being used for the cleaner solvent.
Cleaner Solvent Index
The name of the verification index that passed the
Cleaner Solvent identifier validation
Cleaner Paper ID
The value of the identifier (barcode) that is
currently being used for the cleaner paper.
Cleaner Paper Index
The name of the verification index that passed the
Cleaner Paper identifier validation
Front Squeegee Holders ID
The value of the identifier (barcode) that is
currently being used for the front squeegee
holders.
Front Squeegee Holders Index
The name of the verification index that passed the
Front Squeegee Holders identifier validation
Rear Squeegee Holders ID
The value of the identifier (barcode) that is
currently being used for the rear squeegee holders.
Rear Squeegee Holders Index
The name of the verification index that passed the
Rear Squeegee Holders identifier validation
Front Squeegee Blades ID
The value of the identifier (barcode) that is
currently being used for the front squeegee blades.
Front Squeegee Blades Index
The name of the verification index that passed the
Front Squeegee Blades identifier validation
Rear Squeegee Blades ID
The value of the identifier (barcode) that is
currently being used for the rear squeegee blades.
Rear Squeegee Blades Index
The name of the verification index that passed the
Rear Squeegee Blades identifier validation
Proflow Cassette ID
The value of the identifier (barcode) that is
currently being used for the Proflow cassette.
Proflow Cassette Index
The name of the verification index that passed the
Proflow Cassette identifier validation
Proflow Head ID
The value of the identifier (barcode) that is
currently being used for the Proflow head unit.
Proflow Head Index
The name of the verification index that passed the
Proflow Head identifier validation
7.4.4 Failed Verification Items Data
The traceability data is a list of items structured as follows:
Structure: L, m ; m = number of failed items
1. L,1
1. Item name ; Type A
