GEM Manual for DEK Printe rs Equipment Variables Issue 1.1 March 20th, 2014 Page 116 of 152 Page 116 of 152 Category Item Nam e Description and Comm ent s Print Medium Index The name of the verification index that passed…

100%1 / 152
GEM Manual for DEK Printers Equipment Variables
Issue 1.1 March 20th, 2014 Page 115 of 152 Page 115 of 152
Category
Item Name
Description and Comments
Pre Fid 1 Y Align Dev
Pre fiducial 1 deviation in the y alignment
Pre Fid 2 X Align Dev
Pre fiducial 2 deviation in the x alignment
Pre Fid 2 Y Align Dev
Pre fiducial 2 deviation in the y alignment
Pre Fid 3 X Align Dev
Pre fiducial 3 deviation in the x alignment
Pre Fid 3 Y Align Dev
Pre fiducial 3 deviation in the y alignment
X Align Dev
Deviation in the X axis alignment
Y Align Dev
Deviation in the Y axis alignment
Theta Align Dev
Deviation in the theta alignment
Board 1 Fid Score
The score of the first defined fiducial on the
board.
Screen 1 Fid Score
The score of the first defined fiducial on the
screen.
Board 2 Fid Score
The score of the second defined fiducial on the
board.
Screen 2 Fid Score
The score of the second defined fiducial on the
screen.
Board 3 Fid Score
The score of the third defined fiducial on the
board.
Screen 3 Fid Score
The score of the third defined fiducial on the
screen.
Front X Act Rel Move
Front X actuator relative movement
Rear X Act Rel Move
Rear X actuator relative movement
Act Y Rel Move
Y Actuator relative movement
Actual Front Pressure
The measured front squeegee / Proflow pressure.
Actual Rear Pressure
The measured rear squeegee pressure.
Actual Separation Speed
The measured separation speed when performing
the print operation.
Actual Temperature
The measured internal temperature
Actual Humidity
The measured relative humidity
Cycle Time
The number of seconds taken to perform the print
operation.
Table Position
The height of the table when at print position.
Post Fid 1 X Align Dev
Post fiducial 1 deviation in the x alignment
Post Fid 1 Y Align Dev
Post fiducial 1 deviation in the x alignment
Post Fid 2 X Align Dev
Post fiducial 2 deviation in the x alignment
Post Fid 2 Y Align Dev
Post fiducial 2 deviation in the y alignment
Post Fid 3 X Align Dev
Post fiducial 3 deviation in the x alignment
Post Fid 3 Y Align Dev
Post fiducial 3 deviation in the y alignment
Front X Act Pos
Front X actuator absolute position
Rear X Act Pos
Rear X actuator absolute position
Act Y Pos
Y actuator absolute position
Actual Front Print Speed
The measured print speed variation for the front
squeegee.
Actual Rear Print Speed
The measured print speed variation for the rear
squeegee.
Hawkeye Area Error
The number of Hawkeye sites in error
Hawkeye Area Warning
The number of Hawkeye sites in warning
Hawkeye Feat Error
The number of Hawkeye features in error
Hawkeye Feat Warning
The number of Hawkeye features in warning
Verification Data
Product Index
The name of the verification index that passed the
product identifier validation
Screen ID
The value of the identifier (barcode) that is
currently being used for the stencil or screen.
Stencil Screen Index
The name of the verification index that passed the
screen or stencil identifier validation
Print Medium ID
The value of the identifier (barcode) that is
currently being used for the print medium (manual
paste etc..)
GEM Manual for DEK Printers Equipment Variables
Issue 1.1 March 20th, 2014 Page 116 of 152 Page 116 of 152
Category
Item Name
Description and Comments
Print Medium Index
The name of the verification index that passed the
Print Medium identifier validation
Print Medium Cartridge ID
The value of the identifier (barcode) that is
currently being used for the print medium
cartridge (paste dispenser etc..)
Print Medium Cartridge Index
The name of the verification index that passed the
Print Medium Cartridge identifier validation
Tooling ID
The value of the identifier (barcode) that is
currently being used for the tooling (magnetic,
custom etc..)
Tooling Index
The name of the verification index that passed the
Tooling identifier validation
Vortex Cassette ID
The value of the identifier (barcode) that is
currently being used for the vortex cleaner
cassette.
Vortex Cassette Index
The name of the verification index that passed the
Vortex Cassette identifier validation
Cleaner Solvent ID
The value of the identifier (barcode) that is
currently being used for the cleaner solvent.
Cleaner Solvent Index
The name of the verification index that passed the
Cleaner Solvent identifier validation
Cleaner Paper ID
The value of the identifier (barcode) that is
currently being used for the cleaner paper.
Cleaner Paper Index
The name of the verification index that passed the
Cleaner Paper identifier validation
Front Squeegee Holders ID
The value of the identifier (barcode) that is
currently being used for the front squeegee
holders.
Front Squeegee Holders Index
The name of the verification index that passed the
Front Squeegee Holders identifier validation
Rear Squeegee Holders ID
The value of the identifier (barcode) that is
currently being used for the rear squeegee holders.
Rear Squeegee Holders Index
The name of the verification index that passed the
Rear Squeegee Holders identifier validation
Front Squeegee Blades ID
The value of the identifier (barcode) that is
currently being used for the front squeegee blades.
Front Squeegee Blades Index
The name of the verification index that passed the
Front Squeegee Blades identifier validation
Rear Squeegee Blades ID
The value of the identifier (barcode) that is
currently being used for the rear squeegee blades.
Rear Squeegee Blades Index
The name of the verification index that passed the
Rear Squeegee Blades identifier validation
Proflow Cassette ID
The value of the identifier (barcode) that is
currently being used for the Proflow cassette.
Proflow Cassette Index
The name of the verification index that passed the
Proflow Cassette identifier validation
Proflow Head ID
The value of the identifier (barcode) that is
currently being used for the Proflow head unit.
Proflow Head Index
The name of the verification index that passed the
Proflow Head identifier validation
7.4.4 Failed Verification Items Data
The traceability data is a list of items structured as follows:
Structure: L, m ; m = number of failed items
1. L,1
1. Item name ; Type A
GEM Manual for DEK Printers Equipment Variables
Issue 1.1 March 20th, 2014 Page 117 of 152 Page 117 of 152
The list of possible items is the same as for Traceability Data, category Verification Data
.
7.5 Variables for Limits Monitoring
Name
SVID
DVID
CEID
LIMITMIN
LIMITMAX
Type
Humidity
1008
31008
0 %
100
F4
Temperature
1016
31016
0
100
F4
batch_count
1020
31020
0
99999
U4
measured_cycle_time
2004
32004
0
3200000
F8
throughput_cycle_time
2005
32005
0
3200000
F8
front_print_pressure
2008
32008
0
20
F8
rear_print_pressure
2009
32009
0
20
F8
print_speed
2010
32010
2
150
F8
table_separation_speed
2011
32011
0.1
20
F8
board_stretch_error
2012
32012
-5.0 mm
5.0 mm
F8
Xerr
2013
32013
-5.0 mm
5.0 mm
F8
Yerr
2014
32014
-5.0 mm
5.0 mm
F8
theta_err
2015
32015
-1000 sec
+1000 sec
F8
board_fiducial_1_score
2021
32021
0
1000
U4
board_fiducial_2_score
2022
32022
0
1000
U4
board_fiducial_3_score
2023
32023
0
1000
U4
screen_fiducial_1_score
2024
32024
0
1000
U4
screen_fiducial_2_score
2025
32025
0
1000
U4
screen_fiducial_3_score
2026
32026
0
1000
U4
ProflowPastePressure
2031
32031
0
20
F8
7.6 Process Attributes
Name
OBJID
PRODUCT BARCODE
2
SCREEN BARCODE
3
SCREEN ADAPTOR
4
SCREEN IMAGE
5
BOARD WIDTH
10
BOARD LENGTH
11
BOARD THICKNESS
12
FRONT PRINT SPEED
13
FLOOD SPEED
14
FLOOD HEIGHT
15
FRONT PRESSURE
16
REAR PRESSURE
17
PRINT GAP
18
SEPARATION SPEED
19
PRINT MODE
20
PRINT DEPOSITS
21
ALTERNATE DISP
27
ALTERNATE DISP RATE
28
PASTE DISPENSE RATE
30
PASTE DISPENSE SPEED
31
PASTE START
32
PASTE STOP
33
PASTE KNEAD PERIOD
34
KNEAD DEPOSITS
35
