GEM Manual for DEK Printers Capabilities
Issue 1.1 March 20th, 2014 Page 36 of 152 Page 36 of 152
#
Current State
Trigger
New State
Action
Comment
7
EQUIPMENT
RUNNING
1. Operator action to select
end run.
2. Batch limit complete.
3. Host action to select end
run.
EQUIPMENT
READY
None
Batch complete.
8
EQUIPMENT
READY
1. Head opening/open.
2. Paste dispense cycle.
3. Clean screen cycle.
4. Screen change.
5. Tooling change.
6. Pressure readings being
taken.
7. Operator action to select
Setup mode.
EQUIPMENT
SETUP
None
Any machine setup selected.
9
EQUIPMENT
READY
Operator selects
maintenance key.
EQUIPMENT
MAINTENANCE
None
None
10
EQUIPMENT
SETUP
Completion of :
1. Head closing/closed.
2. Clean screen cycle.
3. Paste dispense cycle.
4. Operator action to exit
Setup mode.
EQUIPMENT
READY
None
Follow on from state 8 when
function is complete.
11
EQUIPMENT
MAINTENANCE
Operator selects exit from
maintenance mode.
EQUIPMENT
READY
NONE
Follow on from state 9 when
maintenance complete.
12
EQUIPMENT
SETUP
1. Operator selects
diagnostics by using mode
change.
2. A system error occurring.
3. Restart from a system
error.
4. Initial diagnostics, when
powering-up the machine.
EQUIPMENT
DOWN
Error
notification
or
diagnostics
entered.
None
13
EQUIPMENT
WAITING
14
EQUIPMENT
RUNNING
15
EQUIPMENT
READY
16
EQUIPMENT
MAINTENANCE
17
EQUIPMENT
DOWN
1. Operator selects recover
action.
2. Restart from a system
error complete.
EQUIPMENT
RECOVER
None
Any recovery from the
Equipment Down state
18
EQUIPMENT
MAINTENANCE
1. User selects ‘Machine
Setup’ button
EQUIPMENT
SETUP
None
Move from Maintenance to
Setup screen
19
EQUIPMENT
SETUP
1. Having come from
Maintenance page (transition
18) user selects the ‘Back’
button
EQUIPMENT
MAINTENANCE
None
Move back from Setup to
Maintenance screen
GEM Manual for DEK Printers Capabilities
Issue 1.1 March 20th, 2014 Page 37 of 152 Page 37 of 152
5.5 Equipment Constants
This capability enables the host to read and set the value of the equipment constants defined in
chapter 7. For this purpose, the following functionality is provided.
Host can send a list of equipment constant identities ECID's and values ECV's.
Host can request current ECV's.
Host can request a list of EC names.
Scenarios:
Host sends equipment constants:
Comments
Host
Equipment
Comments
List of constants and values
S2F15 -->
<-- S2F16
Acknowledge
Host equipment constant request:
Comments
Host
Equipment
Comments
Request constants
S2F13 -->
<-- S2F14
List of ECID's and ECV's
Host equipment constant namelist request:
Comments
Host
Equipment
Comments
Request constant namelist
S2F29 -->
<-- S2F30
EC Name list
Operator changes equipment constant:
Comments
Host
Equipment
Comments
<-- S6F11
Equipment sends EC change event
Host Acknowledges change
S6F12 -->
GEM Manual for DEK Printers Capabilities
Issue 1.1 March 20th, 2014 Page 38 of 152 Page 38 of 152
5.6 Process Program Management
This capability provides the host with the ability to control process program (product)
distribution between DEK printers. This is achieved using the following functionality.
Each printer has a process program create / edit capability. When the operator creates a new
process program or modifies an existing one, a collection event report is generated (if enabled
by host). The host uses the event reports (3.2.1) to set up the techniques to link the machine
variables, pp_old_file_name and pp_change_status to the process program change event.
The host can upload and download, new / changed programs from and to printers. The host can
also delete and rename programs resident on a printer. It can also request a directory of
programs resident on a printer. Finally, the Equipment can upload and download new / changed
programs from and to the Host. See Appendix B for Operator procedures.
Using these functions, the host can maintain a master program library and force consistency
across multiple printers.
The DEK printer supports only unformatted process programs. Modification of the process
program is not permitted while the machine is running.
Note: Full process program management is only permitted when the machine is in the READY
machine state and in the ON-LINE:REMOTE control state. In the READY machine state and
ON-LINE:LOCAL control state, Host initiated process program management is limited to
Directory Request only.
Note: The printer normally allows limited adjustment of the process parameters, locally by the
operator or via the remote command “ADJUST_PARAMETER”. This can be altered by setting
the Equipment Constant “process_adjustments” to disable operator, remote or both.
Scenarios:
Operator creates / changes equipment process program:
Comments
Host
Equipment
Comments
PPCHANGENAME / PPCHANGESTATUS are
updated.
<-- S6F11
[IF] CEID for process program change is enabled
[THEN] Send event report.
Event report acknowledged.
S6F12 -->
Host-initiated process program upload:
Comments
Host
Equipment
Comments
Process program request
S7F5 -->
<-- S7F6
Process program data.
