GEM Manual for DEK Printers Capabilities

Issue 1.1 March 20th, 2014 Page 27 of 152 Page 27 of 152

5.2.4 Status Data Collection

The host can use this capability to request selected status information. It provides for

synchronisation of equipment status.

To obtain a status report, the host sends a request with a list of specific SVID's. The

equipment will respond with a list of status values.

Scenarios:

Equipment status variable report request:

Comments

Host

Equipment

Comments

Host requests report of selected status

values.

S1F3 -->

<-- S1F4

Equipment replies with requested data

Equipment status variable namelist request:

Comments

Host

Equipment

Comments

Host requests equipment to identify

selected status values.

S1F11 -->

<-- S1F12

Equipment replies with requested status variable

descriptions.

5.2.5 On-Line Identification

Using this capability, the host can confirm the presence of the equipment. The

equipment will send its identity MDLN and software revision SOFTREV in response to

a request from the host.

Scenarios:

On-Line data report: (Host to equipment)

Comments

Host

Equipment

Comments

Host requests On-Line data

S1F1 -->

<-- S1F2

Equipment replies MDLN & SOFTREV

On-Line data report: (Equipment to host)

Comments

Host

Equipment

Comments

<-- S1F1

Equipment requests On-Line data

Host replies Header only

S1F2 -->

GEM Manual for DEK Printers Capabilities

Issue 1.1 March 20th, 2014 Page 28 of 152 Page 28 of 152

5.3 Alarm Management

The alarm management capability enables the following functionality for host control of alarm

activity:

The host can enable, or disable, specific alarm notification.

The host can request a list of alarm texts.

The host can request a list of alarms set and enabled on the equipment.

The equipment reports both set and clear alarm events with times of alarm changes.

Each alarm has an identity (ALID), which may be in one of two states; SET or CLEAR. Each

ALID can also be ENABLED or DISABLED. The following state model determines alarm

behaviour.

The alarms implemented on the DEK printer are listed in chapter 6.

5.3.1 Alarm Management State Model

State Diagram:

Transition Table:

Current State

Trigger

New State

Action

Comment

ALARMn

CLEAR

Alarm is detected on

equipment

ALARMn SET

Send report if enabled.

Wait for operator

intervention.

ALARMn

SET

Alarm condition no longer

detected

ALARMn

CLEAR

Send report if enabled.

Operator has corrected

error.

State Definitions:

ALARMn CLEAR - The alarm ALID is in safe condition.

ALARMn SET - The alarm is active and operator intervention is required.

Scenarios:

Enable / disable alarms:

Comments

Host

Equipment

Comments

Enable / Disable alarm ALID

S5F3 -->

<-- S5F4

Equipment acknowledges change(s).

Upload alarm information:

Comments

Host

Equipment

Comments

Request alarm data / text

S5F5 -->

<-- S5F6

Equipment sends alarm data / text.

ALARMn

CLEAR

ALARMn

SET

GEM Manual for DEK Printers Capabilities

Issue 1.1 March 20th, 2014 Page 29 of 152 Page 29 of 152

Scenarios:

Send alarm report: (Alarm state change detected by equipment)

Comments

Host

Equipment

Comments

<-- S5F1

[IF] ALIDn enabled, send report.

Host Acknowledges

S5F2 -->

<-- S6F11

[IF] CEIDm enabled, send associated event

report.

Host Acknowledges

S6F12 -->
