GEM Manual for DEK Printers Event Messages
Issue 1.1 March 20th, 2014 Page 133 of 152 Page 133 of 152
40030
Insufficient paste roll height
40031
Insufficient print medium dispensed
40042
Vortex cassette expired
40055
ProFlow cassette low
40057
Fast print speed selected
40058
Normal print speed selected
40060
Board unstarved
40061
Board unblocked
40062
Board starved
40063
Board blocked
40064
Clean started
40065
Clean complete
40066
2D Inspection started
40067
2D Inspection complete
40068
Paste dispense started
40069
Paste dispense complete
40070
Paper level low
40072
Pneumatic power restored
40073
Event log nearly full
40078
Password attempt succeeded
40079
Password attempt failed
40126
Fiducial setup entered
40127
Fiducial setup ended
40128
Diagnostics ended
40129
Adjust entered
40130
Adjust ended
40131
Adjust while running entered
40132
Adjust while running ended
40151
Verification succeeded (see DVID 2034)
40153
Verification value reset (see DVID 2034)
40154
Verification value restored (see DVID 2034)
40155
Batch/lot ID changed
40156
Product ID verification succeeded
40177
Traceability Data Available
40191
Fiducial Alignment Started
40192
Fiducial Alignment Complete
40374
Fiducial Alignment SW Fallback
9.10 Specific Material Movement Events
EVENT - CEID
DESCRIPTION
31258
Paste dispensing.
31259
Paste cartridge empty.
31268
Screen unloaded.
31269
Screen loaded.
31270
Tool change started.
31271
Tool change completed.
31274
Board received.
GEM Manual for DEK Printers Event Messages
Issue 1.1 March 20th, 2014 Page 134 of 152 Page 134 of 152
31276
Printed board ready.
31319
Board delivered / removed.
40024
Vortex cassette replaced.
40071
Paper roll replaced
9.11 Host Specific Information Events
EVENT - CEID
DESCRIPTION
31400
Process program directory request.
31401
Process program request.
31402
Erase process program request.
31403
Rename process program request.
31404
Load process program request.
31405
Download process program request.
31406
Upload process program request.
31407
Download configuration request.
31408
Upload configuration request.
31409
Upload management data request.
31410
Clear management batch data request.
31411
Clear management session data request.
31412
Upload event log.
31413
Clear event log request.
31414
Comms - Start request.
31415
Comms - Stop request.
31416
Update mode request.
31417
Communication error.
31418
Parameter information uploaded.
31419
Parameter information downloaded.
31420
Upload parameter.
31421
Comms - Status request.
31422
Comms - Rebuild process program list.
31423
Paste dispense rate adjusted.
31424
Print speed adjusted.
31425
Front squeegee pressure adjusted.
31426
Rear squeegee pressure adjusted.
31427
Print gap adjusted.
31428
Separation speed adjusted.
31429
Cleaning rate adjusted.
31430
X forward offset adjusted.
31431
Y forward offset adjusted.
31432
Theta forward offset adjusted.
31433
X reverse offset adjusted.
31434
Y reverse offset adjusted.
31435
Theta reverse offset adjusted.
31436
Paste dispensed after host command.
31437
Screen cleaned after host command.
31438
Comms enabled.
31439
Comms disabled.
GEM Manual for DEK Printers Event Messages
Issue 1.1 March 20th, 2014 Page 135 of 152 Page 135 of 152
31442
Paste kneaded after host command.
31443
Paste conditioned after host command.
31458
Proflow pressure adjusted.
40010
Comms - Adjust front print speed.
40011
Comms - Adjust rear print speed.
40041
Request to start
40325
Host Command Start Failed
40326
Host Command Stop Failed
40327
Host Command Pause Failed
40328
Host Command Erase Log Failed
40329
Host Command Erase Batch Failed
40330
Host Command Erase Session Failed
40331
Host Command Rename Product Failed
40332
Host Command Adjust Product Failed
40333
Host Command Clean 1 Failed
40334
Host Command Clean 2 Failed
40335
Host Command Paste Failed
40336
Host Command PP-Select Failed
40337
Host Command Change Screen Failed
40338
Host Command Knead Paste Failed
40376
Host Command Save Product Failed
9.12 Limits Monitoring Events
EVENT - CEID
DESCRIPTION
31000-31200
Status Variables see section 5.5
32000-33000
Discrete Variables see section 5.5
