GEM Manual for DEK Printers Machine GEM Compliance
Issue 1.1 March 20th, 2014 Page 12 of 152 Page 12 of 152
GEM Requirement
Motion control timeout (CEID 31306)
Camera X failed to position (CEID 31307)
Camera Y failed to position (CEID 31308)
Stencil aperture blocked (CEID 31309)
Stencil smeared (CEID 31310)
Paste on pad inspection error (CEID 31311)
Bridging detected by inspection system (CEID 31312)
Alignment error detected by inspection system (CEID 31313)
Event log disk file full (CEID 31321)
Proflow error (CEID 31322)
CAN node down (CEID 31340)
CAN node recovered (CEID 31341)
CAN bus down (CEID 31342)
CAN bus recovered (CEID 31433)
Volume alarm (CEID 31460)
Dongle error (CEID 40006)
Cleaner detached from camera (CEID 40146)
Recovered cleaner detached from camera (CEID 40147)
Ball escape detected (CEID 40150)
Verification item failed (CEID 40152)
Product ID verification failed (CEID 40157)
Advanced Adjust Entered (CEID 40300)
Cleaner Vacuum Sense Error (CEID 40320)
Equipment Specific Information Events
System power on (CEID 10002)
Line power on (CEID 31251)
Printer ready (CEID 31255)
Head raised (CEID 31256)
Head closed (CEID 31257)
Cycle aborted (CEID 31260)
Cycle completed (CEID 31261)
Cleaning screen (CEID 31262)
Parameter adjusted (CEID 31263)
Setup started (CEID 31264)
Setup ended (CEID 31272)
Start print cycle (CEID 31273)
End print cycle (CEID 31275)
Board printed (CEID 31277)
Operator log on (CEID 31278)
Operator log off (CEID 31279)
Clear batch count (CEID 31280)
Start maintenance (CEID 31281)
End maintenance (CEID 31282)
Pressure re-calibrated (CEID 31283)
Offset recalibrated (CEID 31284)
X,Y scale recalibrated (CEID 31285)
Theta recalibrated (CEID 31286)
Configuration change (CEID 31287)
Start diagnostics (CEID 31288)
GEM Manual for DEK Printers Machine GEM Compliance
Issue 1.1 March 20th, 2014 Page 13 of 152 Page 13 of 152
GEM Requirement
End diagnostics (CEID 31289)
Camera reference reset (CEID 31291)
Vision height reset (CEID 31293)
Print height reset (CEID 31294)
Software updated (CEID 31296)
New event log (CEID 31297)
No cleaner paper (CEID 31301)
No cleaner solvent (CEID 31302)
Inspection cycle complete (CEID 31316)
Clock change request (CEID 31317)
Clock changed (CEID 31318)
Remote barcode received (CEID 31457)
Evaluation dongle detected (CEID 40004)
Valid dongle detected (CEID 40005)
Dongle changed (CEID 40007)
Front print speed (CEID 40008)
Rear print speed (CEID 40009)
ProFlow cassette low (CEID 40055)
Configuration Parameter modified (CEID 31345)
Adjust Parameter modified (CEID 31347)
Fiducial setup entered (CEID 40126)
Fiducial setup ended (CEID 40127)
Diagnostics ended (CEID 40128)
Adjust entered (CEID 40129)
Adjust ended (CEID 40130)
Adjust while running entered (CEID 40131)
Adjust while running ended (CEID 40132)
Item verification succeeded (CEID 40151)
Verification value reset (CEID 40153)
Verification value restored (CEID 40154)
Batch/lot ID changed (CEID 40155)
Product ID verification succeeded (CEID 40156)
Traceability data available (CEID 40177)
Fiducial Alignment Started (CEID 40191)
Fiducial Alignment Complete (CEID 40192)
Fiducial Alignment SW Fallback (CEID 40374)
Specific Material Movements
Paste dispensing (CEID 31258)
Paste cartridge empty (CEID 31259)
Screen unloaded (CEID 31268)
Screen loaded (CEID 31269)
Tool change started (CEID 31270)
Tool change completed (CEID 31271)
Board received (CEID 31274)
Printed board ready (CEID 31276)
Board delivered / removed (CEID 31319)
Vortex cassette replaced (CEID 40024)
Host Specific Information Events
GEM Manual for DEK Printers Machine GEM Compliance
Issue 1.1 March 20th, 2014 Page 14 of 152 Page 14 of 152
GEM Requirement
Process program directory request (CEID 31400)
Process program request (CEID 31401)
Erase process program request (CEID 31402)
Rename process program request (CEID 31403)
Load process program request (CEID 31404)
Download process program request (CEID 31405)
Upload process program request (CEID 31406)
Download configuration request (CEID 31407)
Upload configuration request (CEID 31408)
Upload management data request (CEID 31409)
Clear management batch data request (CEID 31410)
Clear management session data request (CEID 31411)
Upload event log request (CEID 31412)
Clear event log request (CEID 31413)
Comms - Start request (CEID 31414)
Comms - Stop request (CEID 31415)
Update mode request (CEID 31416)
Communication error (CEID 31417)
Parameter information uploaded (CEID 31418)
Parameter information downloaded (CEID 31419)
Upload parameter (CEID 31420)
Comms - Status request (CEID 31421)
Comms - Rebuild process program list (CEID 31422)
Paste dispense rate adjusted (CEID 31423)
Print speed adjusted (CEID 31424)
Front squeegee pressure adjusted (CEID 31425)
Rear squeegee pressure adjusted (CEID 31426)
Print gap adjusted (CEID 31427)
Separation speed adjusted (CEID 31428)
Cleaning rate adjusted (CEID 31429)
X forward offset adjusted (CEID 31430)
Y forward offset adjusted (CEID 31431)
Theta forward offset adjusted (CEID 31432)
X reverse offset adjusted (CEID 31433)
Y reverse offset adjusted (CEID 31434)
Theta reverse offset adjusted (CEID 31435)
Paste dispensed after host command (CEID 31436)
Screen cleaned after host command (CEID 31437)
Comms enabled (CEID 31438)
Comms disabled (CEID 31439)
Paste kneaded after host command (CEID 31442)
Paste conditioned after host command (CEID 31443)
Proflow pressure adjusted (CEID 31458)
Comms - Adjust front print speed (CEID 40010)
Comms - Adjust rear print speed (CEID 40011)
Host Command Start Failed (CEID 40325)
Host Command Stop Failed (CEID 40326)
Host Command Pause Failed (CEID 40327)
Host Command Erase Log Failed (CEID 40328)
Host Command Erase Batch Failed (CEID 40329)
