GEM Manual for DEK Printers Capabilities

Issue 1.1 March 20th, 2014 Page 39 of 152 Page 39 of 152

Equipment-initiated process program upload:

Comments

Host

Equipment

Comments

<-- S7F1

[IF] Process program is multi-block [THEN] PP

Load Inquire

PP Load Grant

S7F2 -->

[END_IF]

<-- S7F3

PP Send

PP Acknowledge

S7F4 -->

Host-initiated process program download:

Comments

Host

Equipment

Comments

[IF] PP is Multi-block PP Load Inquire

S7F1 -->

<-- S7F2

PP Load Grant

[END_IF]

PP Send

S7F3 -->

<-- S7F4

PP Acknowledge.

<-- S6F11

[IF] PP Validation = bad [AND] Bad Download

CEID

enabled [THEN] send Bad Download

event.

Event Acknowledge.

S6F12 -->

[END_IF]

Equipment-initiated process program download:

Comments

Host

Equipment

Comments

<-- S7F5

PP Request

PP Data

S7F6 -->

<-- S6F11

[IF] PP Validation = bad [AND] Bad Download

CEID

enabled [THEN] send Bad Download

event.

Event Acknowledge.

S6F12 -->

[END_IF]

Host-initiated process program delete:

Comments

Host

Equipment

Comments

Delete PP send

S7F17 -->

<-- S7F18

Delete PP Acknowledge. Process program

removed from non-volatile storage.

Process program directory request:

Comments

Host

Equipment

Comments

Current EPPD Request.

S7F19 -->

<-- S7F20

Current EPPD Data

See section 7-4.

GEM Manual for DEK Printers Capabilities

Issue 1.1 March 20th, 2014 Page 40 of 152 Page 40 of 152

5.7 Material Movement

Material tracking can be performed by enabling the following events. Event reporting is

covered in Section 7.

EVENT

CEID

DESCRIPTION

REFERENCE

31258

Paste dispensing.

Paste dispense cycle started.

31259

Paste cartridge empty.

Paste cartridge detected empty.

31264

Setup started.

Setup page has been entered.

31265

Process program loaded.

Process program loaded into printer.

31266

New process program.

New process program created and loaded.

31268

Screen unloaded.

Screen just unloaded.

31269

Screen loaded.

Screen just loaded.

31270

Tool change started.

Tool Change page just entered.

31271

Tool change complete.

Tool Change page just exited.

31272

Setup ended.

Setup page just exited.

31273

Start print cycle.

Print cycle/s just started.

31274

Board received.

Board received at input sensor.

31275

End print cycle.

Print cycle/s just completed.

31276

Printed board ready.

Board at output sensor.

31277

Board printed.

Board just printed.

31301

No cleaner paper.

Cleaner run out of paper.

31302

No cleaner solvent.

Cleaner run out of solvent.

31319

Board delivered / removed.

Board has left the machine.

Scenario:

Material sent to / removed from equipment:

Comments

Host

Equipment

Comments

<-- S6F11

Material movement CEID

Host acknowledges report.

S6F12 -->

GEM Manual for DEK Printers Capabilities

Issue 1.1 March 20th, 2014 Page 41 of 152 Page 41 of 152

5.8 Equipment Terminal Services

This capability enables factory operators to exchange messages with the host. It is particularly

useful for passing instructions to the operator.

When the host sends a terminal message to a DEK printer, an indication of a message is

displayed at the equipment console. This indication message will remain displayed until either,

the operator presses a button indicating it has been read or, the host sends a new zero length

text. When the operator presses the read complete button, an event report CEID is sent to the

host.

The operator can enter a terminal message, at the equipment console, which will then be sent to

the host.

For Operator procedures see Appendix B.

Terminal Services State Model:

The terminal services state model is implemented on the DEK printer.

State Diagram:

State Definitions:

Idle - No host text is displayed on the terminal.

Not Acknowledged - Host text is displayed and not yet acknowledged by the operator.

Transition Table:

Current State

Trigger

New State

Action

Comment

Idle

Host display message.

Not Acknowledged

Display

Waiting for operator button

Not Acknowledged

Operator Acknowledge

Idle

none

Not Acknowledged

New host message

Not Acknowledged

Display

Waiting for operator button

Not Acknowledged

New zero length message

Idle

none

IDLE

NOT

ACKNOWLEDGE
