GEM Manual for DEK Printers SECS II Implementation
Issue 1.1 March 20th, 2014 Page 55 of 152 Page 55 of 152
6.1 MESSAGE SUMMARY
The following is a summary of the SECS II streams and functions supported by the DEK
printer to meet the requirements of GEM. Additional non GEM messages are documented in
section 8.
Host Initiated Messages:
Primary
Description
Reply
Description
S1F1
Are You There Request
S1F2
On-Line Data
S1F3
Selected Equipment Status Request
S1F4
Selected Equipment Status Data
S1F11
Status Variable Namelist Request
S1F12
Status Variable Namelist
S1F13
Establish Communications Request
S1F14
ECR Acknowledge
S1F15
Off-Line Control State Request
S1F16
Off-Line Control State Data
S1F17
On-Line Control State Request
S1F18
On-Line State Data
S2F13
Equipment Constant Request
S2F14
Equipment Constant Data
S2F15
New Equipment Constant Send
S2F16
New Equipment Constant Acknowledge
S2F17
Date & Time Request
S2F18
Date & Time Data
S2F23
Trace Initialise Send
S1F26
Trace Initialise Acknowledge
S2F25
Loop Back Diagnostic Request
S2F26
Loop Back Diagnostic Data
S2F29
Equipment Constant Namelist Request
S2F30
Equipment Constant Namelist Data
S2F31
Date & Time Set Request
S2F32
Date & Time Acknowledge
S2F33
Define Report
S2F34
Define Report Acknowledge
S2F35
Link Event Report
S2F34
Link Event Report Acknowledge
S2F37
Enable / Disable Event Report
S2F38
Enable / Disable Event Report Acknowledge
S2F39
Multi-block Inquire
S2F40
Multi-block Grant
S2F41
Host Command Send
S2F42
Host Command Acknowledge
S2F43
Reset Spooling Streams and Functions
S2F44
Reset Spooling Acknowledge
S2F45
Define Variable Limit Attributes
S2F46
Variable Limit Attribute Acknowledge
S2F47
Variable Limit Attribute Request
S2F48
Variable Limit Attribute Send
S5F3
Enable / Disable Alarm Send
S5F4
Enable / Disable Alarm Send Acknowledge
S5F5
List Alarms Request
S5F6
List Alarms Data
S5F7
List Enabled Alarms Request
S5F8
List Enabled Alarms Data
S6F15
Event Report Request
S6F16
Event Report Data
S6F19
Individual Report Request
S6F20
Individual Report Data
S6F23
Request Spooled Data
S6F24
Request Spooled Data Acknowledge
S7F1
Process Program Load Inquire
S7F2
Process Program Load Grant
S7F3
Process Program Send
S7F4
Process Program Acknowledge
S7F5
Process Program Request
S7F6
Process Program Data
S7F17
Delete Process Program Send
S7F18
Delete Process Program Acknowledge
S7F19
Current EPPD
6
Request
S7F20
Current EPPD Data
S10F3
Terminal Display, Single
S10F4
Terminal Display, Single Acknowledge
S10F5
Terminal Display, Multiblock
S10F6
Terminal Display, Multiblock Acknowledge
S14F1
Get Attribute Request
S14F2
Get Attribute Data
Equipment Initiated Messages:
Primary
Description
Reply
Description
S1F1
Are You There Request
S1F2
On-Line Data
6
EPPD = Equipment Process Program Directory
GEM Manual for DEK Printers SECS II Implementation
Issue 1.1 March 20th, 2014 Page 56 of 152 Page 56 of 152
Primary
Description
Reply
Description
S1F13
Establish Communications Request
S1F14
ECR Acknowledge
S2F17
Date & Time Request
S2F18
Date & Time Data
S5F1
Alarm Report Send
S5F2
Alarm Report Acknowledge
S6F1
Trace Data Send
S6F2
Trace Data Acknowledge
S6F5
Multi-block Data Send Inquire
S6F6
Multi-block Grant
S6F11
Event Report Send
S6F12
Event Report Acknowledge
S7F1
Process Program Load Inquire
S7F2
Process Program Load Grant
S7F3
Process Program Send
S7F4
Process Program Acknowledge
S7F5
Process Program Request
S7F6
Process Program Data
S9F1
Unrecognised Device ID
S9F3
Unrecognised Stream Type
S9F5
Unrecognised Function Type
S9F7
Unrecognised Illegal Data
S9F9
Transaction Timer Timeout
S9F11
Data Too Long
S9F13
Conversation Timeout
S10F1
Terminal Request
S10F2
Terminal Request Acknowledge
GEM Manual for DEK Printers SECS II Implementation
Issue 1.1 March 20th, 2014 Page 57 of 152 Page 57 of 152
6.2 SECS II VARIABLE DATA DEFINITIONS
This section gives definitions of the data items required in the SECS II streams and functions
implemented by the DEK Printer. The definitions are in alphabetical order of symbol name.
Data Item
Description
Values
Format
ABS
Any binary string.
binary*1
ACKC5
Acknowledge code, responding to alarm
enable / disable or notification.
0 = Accepted.
>0 = Denied.
binary*1
ACKC6
Acknowledge code, responding to trace or
event report send.
0 = Accepted and done.
>0 = Error.
binary*1
ACKC7
Acknowledge code, responding to process
program transfer, or delete.
0 = Done.
1 = Permission denied.
2 = Length error.
4 = PPID not found.
6 = File Format error
7-63 = Reserved.
64 = Process program
parameter error.
65 = Format Error
binary*1
ACKC10
Acknowledge code, responding to text
message.
0 = Accepted for display.
1 = Will not display.
unsigned int*1
ACKC13
Return code for secondary messages
used by S13F4.
0 = Data set opened
successfully.
1 = 265 is not ready.
2 = Unknown data set.
3 = Invalid check point.
4 = Invalid length.
5 = File error.
6 = Processing error.
7 = Cannot continue.
8 = End of file.
binary*1
ALCD
Alarm code.
Bit 8 = 1 is alarm set.
Bit 8 = 0 is alarm clear.
binary*1
ALED
Alarm enable / disable code.
Bit 8 = 1 to enable alarm
Bit 8 = 0 to disable alarm
binary*1
ALID
Alarm identification.
See chapter 6 for a list.
unsigned int*1
ALTX
Alarm text.
See chapter 6.
ASCII 40
ATTRDATA
Attribute Data, the value of a requested
attribute for a particular object id
Any text string
ASCII 80
ATTRID
Attribute Identifier, specifies which attribute
to return for an object
0 = Name
1 = Current Value
unsigned int*4
ATTRRELN
Attribute relationship qualifier
Used by S14F1 - Not currently implemented
CEED
Collection event enable / disable code.
>0 = Enable.
0 = Disable.
boolean
CEID
Collection event identity.
See chapter 7 for list.
unsigned int*4
CKPNT
Check Point, (data block number)
used by S13,F3 F6.
unsigned int*4
