GEM Manual for DEK Printers Equipment Variables
Issue 1.1 March 20th, 2014 Page 117 of 152 Page 117 of 152
The list of possible items is the same as for Traceability Data, category Verification Data
.
7.5 Variables for Limits Monitoring
Name
SVID
DVID
CEID
LIMITMIN
LIMITMAX
Type
Humidity
1008
31008
0 %
100
F4
Temperature
1016
31016
0
100
F4
batch_count
1020
31020
0
99999
U4
measured_cycle_time
2004
32004
0
3200000
F8
throughput_cycle_time
2005
32005
0
3200000
F8
front_print_pressure
2008
32008
0
20
F8
rear_print_pressure
2009
32009
0
20
F8
print_speed
2010
32010
2
150
F8
table_separation_speed
2011
32011
0.1
20
F8
board_stretch_error
2012
32012
-5.0 mm
5.0 mm
F8
Xerr
2013
32013
-5.0 mm
5.0 mm
F8
Yerr
2014
32014
-5.0 mm
5.0 mm
F8
theta_err
2015
32015
-1000 sec
+1000 sec
F8
board_fiducial_1_score
2021
32021
0
1000
U4
board_fiducial_2_score
2022
32022
0
1000
U4
board_fiducial_3_score
2023
32023
0
1000
U4
screen_fiducial_1_score
2024
32024
0
1000
U4
screen_fiducial_2_score
2025
32025
0
1000
U4
screen_fiducial_3_score
2026
32026
0
1000
U4
ProflowPastePressure
2031
32031
0
20
F8
7.6 Process Attributes
Name
OBJID
PRODUCT BARCODE
2
SCREEN BARCODE
3
SCREEN ADAPTOR
4
SCREEN IMAGE
5
BOARD WIDTH
10
BOARD LENGTH
11
BOARD THICKNESS
12
FRONT PRINT SPEED
13
FLOOD SPEED
14
FLOOD HEIGHT
15
FRONT PRESSURE
16
REAR PRESSURE
17
PRINT GAP
18
SEPARATION SPEED
19
PRINT MODE
20
PRINT DEPOSITS
21
ALTERNATE DISP
27
ALTERNATE DISP RATE
28
PASTE DISPENSE RATE
30
PASTE DISPENSE SPEED
31
PASTE START
32
PASTE STOP
33
PASTE KNEAD PERIOD
34
KNEAD DEPOSITS
35
GEM Manual for DEK Printers Equipment Variables
Issue 1.1 March 20th, 2014 Page 118 of 152 Page 118 of 152
KNEAD BOARDS
36
CLEAN AFTER KNEAD
37
BOARD COUNT
38
PASTE WHILE CLEAN
39
SCREEN CLEAN RATE 1
40
SCREEN CLEAN MODE 1
41
SCREEN CLEAN RATE 2
42
SCREEN CLEAN MODE 2
43
KNEAD AFTER DISPENSE
45
STOP AFTER IDLE
46
ALIGNMENT MODE
50
FIDUCIAL 1 X
51
FIDUCIAL 1 Y
52
FIDUCIAL 2 X
53
FIDUCIAL 2 Y
54
FIDUCIAL 3 X
55
FIDUCIAL 3 Y
56
FORWARD X OFFSET
57
FORWARD Y OFFSET
58
FORWARD THETA OFFSET
59
REVERSE X OFFSET
60
REVERSE Y OFFSET
61
REVERSE THETA OFFSET
62
ALIGNMENT WEIGHTING
66
X ALIGN WEIGHTING
67
Y ALIGN WEIGHTING
68
BOARD STOP X
70
BOARD STOP Y
71
UNDER CLEARANCE
72
PRINT FRONT LIMIT
73
PRINT REAR LIMIT
74
DRY CLEAN SPEED
83
WET CLEAN SPEED
84
VAC CLEAN SPEED
85
FRONT START OFFSET
86
REAR START OFFSET
87
SEPARATION DELAY
89
PRINT AREA WIDTH
100
PASTE WITH BOARD
104
PRINT AREA LENGTH
105
DIST TO IMAGE
110
PRINT PASTE PRESSURE
115
IDLE PASTE PRESSURE
116
CUSTOM SCREEN
120
PASTE RIDGE REMOVAL
185
SEPARATE VAC DELAY
187
FLATTEN VAC DELAY
188
REAR PRINT SPEED
199
VORTEX SOLVENT RATE
223
VACUUM ON PERIOD
224
VORTEX VACUUM RATE
225
VORTEX VAC START
226
VORTEX VAC STOP
227
VORTEX CLEAN RATE
228
GEM Manual for DEK Printers Equipment Variables
Issue 1.1 March 20th, 2014 Page 119 of 152 Page 119 of 152
VORTEX CASSETTE LIFE
229
FRONT KNEAD PRESSURE
245
REAR KNEAD PRESSURE
246
FRONT KNEAD SPEED
247
REAR KNEAD SPEED
248
SELECT MARK TYPE
252
SELECT MARK X
267
SELECT MARK Y
268
FRONT PASTE RECOVERY
273
REAR PASTE RECOVERY
274
PASTE RECOVERY RATE
275
KNEAD BEFORE PRINT
276
KNEAD OFF
277
STENCIL PROTECTION
278
SYSTEM PRESSURE
280
TOOLING DEVIATION
284
SINGULATION
342
PALLET THICKNESS
346
FIRST PART TO EDGE
348
PITCH OF PARTS
349
PALLET WIDTH
350
PALLET LENGTH
351
NUMBER OF PARTS
352
VAC CLEAN START TIME
387
BOARD AT STOP RUN ON
399
KNEAD PASTE PRESSURE
428
KNEAD AFTER REPLENISH
429
CLEAN AFTER KNEAD
430
RWD END PRESSURE
431
RWD START PRESSURE
432
FWD END PRESSURE
433
FWD START PRESSURE
434
RWD END SPEED
435
RWD START SPEED
436
FWD END SPEED
437
FWD START SPEED
438
VACUUM SENSOR DELAY
451
FLOOD SPEED
452
REAR KNEAD SPEED
453
FRONT KNEAD SPEED
454
REAR PRINT SPEED
455
FRONT PRINT SPEED
456
FWD END SPEED
457
FWD START SPEED
458
RWD START SPEED
459
RWD END SPEED
460
LOADING FRAME REAR
571
SELECTIVE PRINT
625
SELECTIVE PRINT OK
626
SELECTIVE PRINT FAIL
627
SOFT RAIL LIFT/LAND
628
SOFT LIFT/LAND SPEED
629
SOFT LIFT/LAND DIST
630
VIEW ROUGH ALIGNMENT
692
