YAMAHA Motor Co Ltd.,
IM Operation
Mounter Soft Gr
MDOC-SOFT50011
TT6094.ProductionHistory(YAMAHA_BRAND).doc
19 / 53
Stage A(Each
Mounting
Log)
Or MCH
None
Mounting stage which
outputs the logs, or MCH
*1
Start Date 2001/06/08
11:50:04
Date the board data is
switched.
←
*1
Setup Date 2001/06/08
11:55:17
Time when the machine
starts auto-running after
setting up.
(Not recorded as Setup Date
with some errors like a data
error, even when the START
button is pushed)
←
*1
Finish Date 2001/06/08
15:43:25
Time when it switches to the
next board, or when the
power off.
[Each Stage]
Time when it finishes to
produce on the last
mounting stage.
[WCH]
Time when it switches to
the next board, or when
the power off.
*1
Board Count Max 10 Planned number of boards
mounted.
(Final counted value is
recorded if it is changed
during the production.)
←
*1
Produced Board 8 Actual number of board
mounted until finish.
(Uncompleted boards not
counted)
[Each Stage]
The number of boards
arriving at the exit of each
stage in a program.
[WCH]
The number of boards
arriving at the exit of the
last stage.
*1
Mount CT Max 35.59 The longest time taken for
mounting a board of all
[Each Stage]
The longest time taken
*1
YAMAHA Motor Co Ltd.,
IM Operation
Mounter Soft Gr
MDOC-SOFT50011
TT6094.ProductionHistory(YAMAHA_BRAND).doc
20 / 53
stages in a program. for mounting a board on a
stage in a program.
[WCH]
Not outputted
Mount CT Min 35.59 The shortest time taken for
mounting a board of all
stages in a program.
[Each Stage]
The shortest time taken for
mounting a board on a
stage in a program.
[WCH]
Not outputted
*1
Mount CT Ave 35.59 The average time taken for
mounting a board of all
stages in a program.
[Each Stage]
The average time taken for
mounting a board on a
stage in a program.
[WCH]
Not outputted
*1
Transfer CT Max 4.76 The longest time taken for
transferring a board of all
stages in a program.
[Each Stage]
The longest time taken for
transferring a board on a
stage in a program.
[WCH]
Not outputted
*1
Transfer CT Min 4.76 The shortest time taken for
transferring a board of all
stages in a program.
[Each Stage]
The shortest time taken for
transferring a board on a
stage in a program.
[WCH]
Not outputted
*1
Transfer CT Ave 4.76 The average time taken for
transferring a board of all
stages in a program.
[Each Stage]
The average time taken for
transferring a board on a
stage in a program.
[WCH]
Not outputted
*1
Standby CT Max 1.24 The longest time of all
stages for a board to
[Each Stage]
The longest time for a
*1
YAMAHA Motor Co Ltd.,
IM Operation
Mounter Soft Gr
MDOC-SOFT50011
TT6094.ProductionHistory(YAMAHA_BRAND).doc
21 / 53
standby in a program. board to standby on a
stage in a program.
[WCH]
Not outputted
Standby CT Min 1.24 The shortest time of all
stages for a board to
standby in a program
[Each Stage]
The shortest time for a
board to standby on a
stage in a program
[WCH]
Not outputted
*1
Standby CT Ave 1.24 The average time of all
stages for a board to
standby in a program.
[Each Stage]
The average time for a
board to standby on a
stage in a program.
[WCH]
Not outputted
*1
Mark Rec CT Max 2.41 The longest time taken for
mark recognition of a board
of all stages in a program.
[Each Stage]
The longest time taken for
mark recognition of a
board on a stage in a
program.
[WCH]
Not outputted
*1
Mark Rec CT Min 2.41 The shortest time taken for
mark recognition of a board
of all stages in a program.
[Each Stage]
The shortest time taken for
mark recognition of a
board on a stage in a
program.
[WCH]
Not outputted
*1
MarkRec CT Ave 2.41 The shortest time taken for
mark recognition of a board
of all stages in a program.
[Each Stage]
The shortest time taken for
mark recognition of a
board on a stage in a
program.
[WCH]
*1
