YAMAHA Motor Co Ltd.,
IM Operation
Mounter Soft Gr
MDOC-SOFT50011
TT6094.ProductionHistory(YAMAHA_BRAND).doc
20 / 53
stages in a program. for mounting a board on a
stage in a program.
[WCH]
Not outputted
Mount CT Min 35.59 The shortest time taken for
mounting a board of all
stages in a program.
[Each Stage]
The shortest time taken for
mounting a board on a
stage in a program.
[WCH]
Not outputted
*1
Mount CT Ave 35.59 The average time taken for
mounting a board of all
stages in a program.
[Each Stage]
The average time taken for
mounting a board on a
stage in a program.
[WCH]
Not outputted
*1
Transfer CT Max 4.76 The longest time taken for
transferring a board of all
stages in a program.
[Each Stage]
The longest time taken for
transferring a board on a
stage in a program.
[WCH]
Not outputted
*1
Transfer CT Min 4.76 The shortest time taken for
transferring a board of all
stages in a program.
[Each Stage]
The shortest time taken for
transferring a board on a
stage in a program.
[WCH]
Not outputted
*1
Transfer CT Ave 4.76 The average time taken for
transferring a board of all
stages in a program.
[Each Stage]
The average time taken for
transferring a board on a
stage in a program.
[WCH]
Not outputted
*1
Standby CT Max 1.24 The longest time of all
stages for a board to
[Each Stage]
The longest time for a
*1
YAMAHA Motor Co Ltd.,
IM Operation
Mounter Soft Gr
MDOC-SOFT50011
TT6094.ProductionHistory(YAMAHA_BRAND).doc
21 / 53
standby in a program. board to standby on a
stage in a program.
[WCH]
Not outputted
Standby CT Min 1.24 The shortest time of all
stages for a board to
standby in a program
[Each Stage]
The shortest time for a
board to standby on a
stage in a program
[WCH]
Not outputted
*1
Standby CT Ave 1.24 The average time of all
stages for a board to
standby in a program.
[Each Stage]
The average time for a
board to standby on a
stage in a program.
[WCH]
Not outputted
*1
Mark Rec CT Max 2.41 The longest time taken for
mark recognition of a board
of all stages in a program.
[Each Stage]
The longest time taken for
mark recognition of a
board on a stage in a
program.
[WCH]
Not outputted
*1
Mark Rec CT Min 2.41 The shortest time taken for
mark recognition of a board
of all stages in a program.
[Each Stage]
The shortest time taken for
mark recognition of a
board on a stage in a
program.
[WCH]
Not outputted
*1
MarkRec CT Ave 2.41 The shortest time taken for
mark recognition of a board
of all stages in a program.
[Each Stage]
The shortest time taken for
mark recognition of a
board on a stage in a
program.
[WCH]
*1
YAMAHA Motor Co Ltd.,
IM Operation
Mounter Soft Gr
MDOC-SOFT50011
TT6094.ProductionHistory(YAMAHA_BRAND).doc
22 / 53
Not outputted
Pickup Error 3 The number of Pickup Errors
on all stages in a program.
(Includes retries)
[Each Stage]
The number of Pickup
Errors on a stage in a
program.
(Includes retries)
[WCH]
The number of Pickup
Errors on all stages in a
program.
(Includes retries)
*1
Parts Vision Error 2 The number of Parts Vision
Errors with the board
production on all stages in a
program.
(Includes retries)
[Each Stage]
The number of Parts
Vision Errors on a stage in
a program.
(Includes retries)
[WCH]
The number of Parts
Vision Errors on all stages
in a program.
(Includes retries)
*1
Co-Planarity Error 1 The number of Co-planarity
Errors occurring when the
board is under the operation.
(Includes retries)
This is displayed only in a
machine with a Co-planarity
Checker, or in Special
Function on.
[Each Stage]
The number of
Co-planarity Errors on a
stage in a program.
(Includes retries)
[WCH]
The number of
Co-planarity Errors on all
stages in a program.
(Includes retries)
V1.01
V2.01
V3.01
V3.11
only
Mark Vision Error 1 The number of Mark Vision
Error with the board
production on all stages in a
program.
(Includes retries)
[Each Stage]
The number of Mark Vision
Errors on a stage in a
program.
(Includes retries)
*1
