1 Introduction
1.1 Module Description
6 User Manual SIPLACE MeasuringFeeder X 03/2020
1.1.3 EU Declaration of Conformity
The product described below conforms to the regulations and standards listed in the EU Decla-
ration of Conformity provided.
Type SIPLACE MeasuringFeeder X
Item no.: 00141440-xx
Manufacturer:
ASM Assembly Systems GmbH & Co. KG
Rupert-Mayer-Str. 44
81379 München
Deutschland
1.1.4 Correct Usage
The product may only be used for the application cases described in the catalogues and technical
specifications i.e. for placement of SMD components and only in connection with the third party
devices and components recommended or approved by ASM Assembly Systems GmbH & Co. KG.
Any other use is deemed to be incorrect and not as prescribed.
If the product is not used as prescribed, ASM Assembly Systems GmbH & Co. KG will accept no
liability for any damage that may occur and will not guarantee that the components will work prop-
erly and without problems.
Prescribed or correct usage includes the observance of all the instructions in the user manual.
The proper and safe operation of the product requires correct transportation, storage, installation
and assembly, plus careful, accurate utilization and servicing.
1.1.5 Incorrect Usage
Failure to use the product as prescribed can result in both danger to life and limb and material
damage. For this reason, non-prescribed usage is prohibited. If the product is not used as pre-
scribed, ASM Assembly Systems GmbH & Co. KG will not accept liability for any damage that may
occur and will not guarantee that the components will work properly and without problems.
Non-prescribed use of the module includes the following examples:
●
Operation of the module with safety equipment deactivated or removed.
●
Placement of components that do not meet the permitted specification.
●
Use of unauthorized accessories and additional modules.
●
Use of the module by unqualified personnel.
1.1.6 Environmentally-friendly disposal of materials and components
Our products are manufactured using only materials and parts that can be easily separated and
disposed of in an environmentally-friendly way.
NOTICE
Observe the applicable regulations
The company operating the system has sole responsibility for the proper, environmentally-
friendly disposal of machines, working materials, consumable materials and wear parts.
► Please observe your national statutory provisions for waste disposal and environ-
mental protection.
1 Introduction
1.2 Important Notes about this Manual
User Manual SIPLACE MeasuringFeeder X 03/2020 7
1.1.7 Electromagnetic compatibility (EMC)
All SIPLACE products are designed and tested for professional use in industrial applications. Elec-
tromagnetic compatibility in terms of the emission of interference cannot be guaranteed in any
other environment.
1.1.8 Use of original accessories and spare parts
Only use original spare parts and authorized accessories. The use of other parts will affect safety
and will invalidate the liability for any consequential damage.
1.2 Important Notes about this Manual
1.2.1 Contents and Filing of this Manual
This User Manual contains basic information that must be observed when setting up, operating and
maintaining the module. The service engineers, qualified staff, operators and users must therefore
read it before commencing installation and commissioning. The instructions must be kept perman-
ently accessible wherever the module is used.
In addition, the user must ensure that the employees have fully understood the contents of the user
manual.
1.2.2 Danger notes
WARNING
Danger notes
► Work may only be performed on the SIPLACE MeasuringFeeder X if the personnel
concerned have a thorough knowledge of the relevant section of the user manual.
► All work must be carried out by appropriately trained and qualified personnel.
► All warnings, cautions and hazard notes must be observed.
► Carefully read through the chapter on operational safety for this purpose.
1.2.3 Manufacturer's/supplier's liability
We draw your attention to the fact that these instructions only contain descriptive and explanatory
material and do not include any contractual conditions or undertakings. All obligations of ASM
Assembly Systems GmbH & Co. KG are conclusively specified in the respective contract, on the
basis of which you have received the machine described therein. This applies in particular to all
statements regarding performance or service life and the agreed liability for faults or defects. The
provisions of the contract regarding the liability for faults or defect are neither extended nor restric-
ted by any statements in this manual.
1.2.4 Release History
Document
SIPLACE MeasuringFeeder X
User Manual
Edition Changes
12/2018
11/2019
03/2020
First edition
Revised chapter 4.1.6 on special nozzles
Revised chapter 3.1, Footnote for capacitor measurement ranges
1 Introduction
1.2 Important Notes about this Manual
8 User Manual SIPLACE MeasuringFeeder X 03/2020
1.2.5 Further Information
1.2.5.1 How To Get Information
If you have any questions about this manual or if you would like more information about certain
subjects, please contact your local SIPLACE branch or us directly:
ASM Assembly Systems GmbH & Co. KG
Rupert-Mayer-Str. 44
81379 München
1.2.5.2 SIPLACE on the World Wide Web (WWW)
Log in to our SIPLACE® homepage at http://www.asm-smt.com.
You can choose between the German and English version.
The different sections contain information about our products, services and contact persons.
In addition, registered customers can also access the MySIPLACE user group. Here you can call
up special information about our placement systems, e.g.
●
technical documentation
●
technical information
●
spare parts lists etc.
Registration for the MySIPLACE user group is very simple:
► At the head of the web site, click on and then on the Register
link.
► Fill in the registration form and send it off to us.
Soon afterwards, you will receive your access authorization with user name and password.
