Station Software 705.04 SP2 / Installation Manual Ausgabe 06/2012 Edition
5.5 Installing SIPLACE Smart GUI
The SIPLACE Smart GUI can optionally be installed after the station software has been installed. If
the station software has not been installed first, a corresponding error message is displayed.
► Insert the SIPLACE Smart GUI installation DVD in the drive.
It is read in automatically.
NOTICE
If auto start has been disabled for the drive, you must start the installation manually from
the Windows Explorer.
► Open the Explorer and start SmartGUI.exe under drive E by double clicking it.
The SIPLACE Choice Center dialog box is opened.
Figure 5-14: "SIPLACE Choice Center" dialog box
► Click the Smart GUI for station computer button.
Installation of the SIPLACE Smart GUI continues with the welcome screen.
36
Station Software 705.04 SP2 / Installation Manual Ausgabe 06/2012 Edition
5.5.1 Welcome screen
Figure 5-15: Welcome screen
► Click the Next button.
The necessary files are installed.
5.5.2 Finalizing the installation
Figure 5-16: Finalizing the installation
► Click the Finish button.
37
Station Software 705.04 SP2 / Installation Manual Ausgabe 06/2012 Edition
6 Installing the Vision computer software (with or
without Coplan)
CAUTION
The station software must not run on the station computer during installation of the
Vision computer software!
NOTICE
In one-computer operation the Vision computer software is automatically installed during
the station software installation.
In two-computer operation the Vision computer software has to be installed explicitly.
The installation requires approx. 20 minutes.
► Connect the USB keyboard to the Vision computer.
► Connect the USB CD drive to the Vision computer.
► Switch the video multiplexer from the machine computer to the Vision computer.
► Log in to the Vision computer as Administrator.
► Insert the installation CD in the drive.
► Open the Explorer and start setup.exe under drive E: by double clicking it.
The SIPLACE Choice Center dialog box is opened.
Figure 6-1: "SIPLACE Choice Center" dialog box
► Click the Vision computer button to install the Vision computer software without
Coplan.
