1 Brief description
This installation manual provides instructions on installing the 705.04 SP2 version of the SIPLACE
®
station software and the Vision computer software on the SIPLACE X2, X3, X4, X4I, SX1/SX2,
SX4, DX1/DX2 and DX4 placement machines.
It contains information on the scope of delivery and requirements for successful installation.
5
Station Software 705.04 SP2 / Installation Manual Ausgabe 06/2012 Edition
2 Scope of delivery
2.1 Software components
705.04 SP2 software
Standard package: 00140035-04 Software SIPLACE Station 705.04 SP2 Basic
– Software CD-ROM
(1)
– Software DVD SIPLACE Smart GUI
– License/product certificate
– Software Installation Manual V705.04 SP2 D+E (00196771-04)
– Packaging
Languages: 00140036-04 SIPLACE foreign language software SC 705.04 SP2
– CD-ROM with software (language pack)
– License/product certificate
– Software Version Description for foreign languages V705.04 SP2 D+E (00196772-04)
– Packaging
(1)
The standard applications are contained on the CD:
– Embedded software for conveyor
– Embedded software for axes
– Embedded software for component tables
– Embedded software for tape cutter
– Embedded software for heads
– Embedded software for vision modules
– Embedded software for I/O modules
– Embedded software for X-feeders
– Embedded software for digital pressure regulation valve
– Embedded software for MTC2
– Embedded software for WPC5/WPC6
2.2 Hardware components
– Machine computer
– Vision computer (optional)
– Coplan computer (optional)
6
Station Software 705.04 SP2 / Installation Manual Ausgabe 06/2012 Edition
2.3 Languages
SIPLACE Station and SIPLACE Vision GUI:
The standard package contains German and English versions.
Other languages are contained in the optional languages package and available under item
number 00140036-04.
The following table indicates which languages are available for the station software and SIPLACE
Vision:
Language Station software / SIPLACE
Vision
French x
Italian x
Spanish (Mexico) x
Portuguese (Brazil) x
Czech
*)
x
Polish
*)
x
Hungarian x
Romanian
*)
x
Chinese (simplified) x
Korean x
Japanese x
Table 2-1: Languages
*)
GUI only (online help English)
