Overview NC SX2
Fig.9: NC – configuration SIPLACE SX2
Location 1/2, inner table position Location 1/2, outer table position
NC1-1 Location 1 NC position 1 NC1-1 Location 1 NC position 1
NC1-2 Location 1 NC position 2 NC1-2 Location 1 NC position 2
NC2-1 Location 2 NC position 1 NC1-3 Location 1 NC position 3
NC2-2 Location 2 NC position 2 NC1-4 Location 1 NC position 4
NC2-1 Location 2 NC position 1
NC2-2 Location 2 NC position 2
NOTICE
Nozzle changers row 1 and 2
The following applies for both locations:
► The NC at positions 1 and 2 together form NC row 1.
► The NC at positions 3 and 4 together form the optional NC row 2.
2.2 Preconditions
●
SW from 703.xx
●
Placement heads SIPLACE C&P20P/P2
●
FCU [03170631-xx]
2 Brief description
2.3 Scope of delivery
Assembly Instructions / Montageanleitung SIPLACE SX1/SX2 Nozzle Changer Pipettenwechsler 06/2020 59
2.3 Scope of delivery
2.3.1 SIPLACE CPP
NOTICE
The corresponding package must be ordered for each NC position, see notes.
Nozzle changer for positions 1 and 2
Nozzle changer SIPLACE CPP (row 1 / pos. 1 and 2) 00519841-xx
1 NC CPx/all short assemblies 03147925-xx
3 Nozzle magazine type 20xx/20 3 position fiducials 03226630-xx
1 Nozzle magazine type 28xx 03065782-xx
1 Assembly instructions nozzle changer SIPLACE SX-Series 00196578-xx
NOTICE
One package each [00519841-xx] for positions 1 and 2
Position 1 requires the package one time [00519841-xx] while position 2 requires this pack-
age once again [00519841-xx].
Nozzle changer for positions 3 and 4
Nozzle changer SIPLACE CPP (row 2 / pos. 3 and 4) 00519842-xx
1 NC CPx/all short assemblies 03147925-xx
3 Nozzle magazine type 20xx/20 3 position fiducials 03226630-xx
1 Nozzle magazine type 28xx 03065782-xx
1 NC holder / adjustable reject box 03032820-xx
1 Holder left NC row 2 assembly / SX 03066001-xx
1 Holder center NC row 2 assembly / SX 03066297-xx
4 ISO 8734 - 5 x 16 - A-ST 03015783-xx
4 ISO 4762 - M 5 x 16-A2-70 03042562-xx
1 Assembly instructions nozzle changer SIPLACE SX-Series 00196578-xx
NOTICE
Various packages for positions 3 and 4
Position 3 requires the package once [00519842-xx].
If this is fitted at pos. 3, you require the package [00519841-xx] only once for position 4.
2 Brief description
2.3 Scope of delivery
60 Assembly Instructions / Montageanleitung SIPLACE SX1/SX2 Nozzle Changer Pipettenwechsler 06/2020
2.3.2 SIPLACE C&P20 P/P2
NOTICE
The corresponding package must be ordered for each NC position, see notes.
Nozzle changer for positions 1 and 2
Nozzle changer SIPLACE C&P 20 (row 1 / pos. 1 and 2) 00519715-xx
1 NC CPx/all short assemblies 03147925-xx
4 Nozzle magazine type 40xx assembly / NCS 03218226-xx
1 Assembly instructions nozzle changer SIPLACE SX-Series 00196578-xx
NOTICE
One package each [00519715-xx] for positions 1 and 2
Position 1 requires the package one time [00519715-xx] while position 2 requires this pack-
age once again [00519715-xx].
Nozzle changer for positions 3 and 4
Nozzle changer SIPLACE C&P 20 (row 2 / pos. 3 and 4) 00519843-xx
1 NC CPx/all short assemblies 03147925-xx
4 Nozzle magazine type 40xx assembly / NCS 03218226-xx
1 NC holder / adjustable reject box 03032820-xx
1 Holder left NC row 2 assembly / SX 03066001-xx
1 Holder center NC row 2 assembly / SX 03066297-xx
4 DIN 6325 - 5m6 x 16 units 00359348 -xx
4 DIN912-M5 x 16-8.8 00845044 -xx
1 Assembly instructions nozzle changer SIPLACE SX-Series 00196578-xx
NOTICE
Various packages for positions 3 and 4
Position 3 requires this package once [00519843-xx].
If this is fitted at position 3, you require the package [00519715-xx] only once for position 4.
