Page
=
DD
HF
=HF+DD/11
10
Modification Date
Name Norm
Check.
Proj.
Origin
Date
Crea. f.
ERSA
Hotflow 3/xx
18.06.2009
=HF+DD/9
133953-V00
Otto-Schott-Straße 5
97877 Wertheim
GmbH
Plant designation
Project name
14:15:1908.07.2010
+
file name (*.pdf)
133953-V00_100705
basic-project
-
Device list
Description
Device list
DIN_PSL_50_2_ERSA_LS1
Part numberPage/Path
=HF+HM1-9B7 =HF+C1/160.08 140717 thermocouplepreheating zone 7bottom side HF3/20
=HF+HM1-9B7.1 =HF+C1/180.09 83324 thermocouplepreheating zone 7bottom side HF3/20
=HF+HM1-9E1 =HF+C1/285.00 6HKRO400V-3.3KW heating preheating zone 1 bottom side
=HF+HM1-9E2 =HF+C1/290.00 6HKRO400V-3.3KW heating preheating zone 2 bottom side
=HF+HM1-9E3 =HF+C1/295.00 6HKRO400V-3.3KW heating preheating zone 3 bottom side
=HF+HM1-9E4 =HF+C1/300.00 6HKRO400V-3.3KW heating preheating zone 4 bottom side
=HF+HM1-9E5 =HF+C1/305.00 6HKRO400V-3.3KW heating preheating zone 5 bottom side
=HF+HM1-9E6 =HF+C1/310.00 6HKRO400V-3.3KW heating preheating zone 6 bottom side
=HF+HM1-9E7 =HF+C1/315.00 6HKRO400V-3.3KW heating preheating zone 7 bottom side
=HF+HM1-9M1 =HF+C1/285.05 6HZL-MOT144B fan preheating zone 1 bottom side
6HZL-MOT145 Lüftermotor Typ L7, 1450rpm
=HF+HM1-9M2 =HF+C1/290.05 6HZL-MOT144B fan preheating zone 2 bottom side
6HZL-MOT145 Lüftermotor Typ L7, 1450rpm
=HF+HM1-9M3 =HF+C1/295.05 6HZL-MOT144B fan preheating zone 3 bottom side
6HZL-MOT145 Lüftermotor Typ L7, 1450rpm
=HF+HM1-9M4 =HF+C1/300.05 6HZL-MOT144B fan preheating zone 4 bottom side
6HZL-MOT145 Lüftermotor Typ L7, 1450rpm
=HF+HM1-9M5 =HF+C1/305.05 6HZL-MOT144B fan preheating zone 5 bottom side
6HZL-MOT145 Lüftermotor Typ L7, 1450rpm
=HF+HM1-9M6 =HF+C1/310.05 6HZL-MOT144B fan preheating zone 6 bottom side
6HZL-MOT145 Lüftermotor Typ L7, 1450rpm
=HF+HM1-9M7 =HF+C1/315.05 6HZL-MOT144B fan preheating zone 7 bottom side
6HZL-MOT145 Lüftermotor Typ L7, 1450rpm
=HF+C1-10F1 =HF+C1/5.02 6EBSIA-63A-B3 prefuse 400VACheating zone 1-10 top
=HF+C1-10F2 =HF+C1/5.04 6EBSIA-63A-B3 prefuse 400VACheating zone 1-10 bottom side
=HF+C1-10F3 =HF+C1/5.06 6EBSIA-16A-B3 supply 400VACover emergency off
=HF+C1-11F1 =HF+C1/395.03 6EBSIA-06A-B1 supply pump hot-water-circuit
=HF+C1-11K1 =HF+C1/395.01 6ETEM2-3 water pump on hot-water-circuit
=HF+WC-11M1 =HF+C1/395.03 147511 pump hot-water-circuit
=HF+WC-11S1 =HF+C1/395.05 142939 water min advance warninghot-water-circuit
=HF+WC-11S2 =HF+C1/395.07 142939 water min hot-water-circuit
=HF+WC-11S3 =HF+C1/395.08 147646 Temperaturwächter G1/2" - 80°C thermo controlhot-water-circuit
=HF+C1-12K1 =HF+C1/390.07 6ETEM2-3 cold water cooling unit internal stop valve on
=HF+C1-12K2 =HF+C1/390.09 6ETEM2-3 cold water cooling unit externalstop valve on
=HF+WC-12S1 =HF+C1/390.01 6BO305 cooling unit pressure ok
=HF+WC-12Y1 =HF+C1/390.02 6X00050 stop valve internal 1
=HF+WC-12Y2 =HF+C1/390.03 6X00050 stop valve internal 2
=HF+WC-12Y3 =HF+C1/390.04 6X00050 stop valve external 1
0 1 2 3 4 5 6 7 8 9
Page
=
DD
HF
=HF+DD/12
11
Modification Date
Name Norm
Check.
Proj.
Origin
Date
Crea. f.
ERSA
Hotflow 3/xx
18.06.2009
=HF+DD/10
133953-V00
Otto-Schott-Straße 5
97877 Wertheim
GmbH
Plant designation
Project name
14:15:2008.07.2010
+
file name (*.pdf)
133953-V00_100705
basic-project
-
Device list
Description
Device list
DIN_PSL_50_2_ERSA_LS1
Part numberPage/Path
=HF+WC-12Y4 =HF+C1/390.06 6X00050 stop valve external 2
=HF+C1-13F1 =HF+C1/380.02 6EBSI4,0A-T 24VDC cold water cooling unit
37420
=HF+C1-13K1 =HF+C1/380.00 6ETEM2-3 cold water cooling unit internal on
=HF+WC-13A1 =HF+C1/380.02 153594 switch cabinet cold water cooling unit internal
=HF+C1-14K1 =HF+C1/385.00 6ETEM2-3 cold water cooling unitexternal on
=HF+C1-15F1 =HF+C1/10.02 6EBSIA-20A-K1 main switch on ups
=HF+C1-15G1 =HF+C1/10.01 6ENETZT020 Geregelte Stromversorgung, 320-575 V // supply at ups
=HF+C1-15G2 =HF+C1/10.01 70588
ups
=HF+C1-15G3 =HF+C1/10.03 70545 battery modul
=HF+C1-15K1 6ESÜB7D-40-00 main switch on ups
=HF+C1-15KT1 64839 switch off battery-unit
=HF+C1-16F1 =HF+C1/400.01 6EBSI4,0A-T supply temperature-management
37420
=HF+E1-16Y1 =HF+C1/400.02 157156 Proportionaldruckregelventil pressure control valve temperature-management 1
=HF+E1-16Y2 =HF+C1/400.04 157156 Proportionaldruckregelventil pressure control valve temperature-management 2
=HF+E1-16Y3 =HF+C1/400.06 157156 Proportionaldruckregelventil pressure control valve temperature-management 3
=HF+E1-16Y4 =HF+C1/400.07 157156 Proportionaldruckregelventil pressure control valve temperature-management 4
=HF+E1-16Y5 =HF+C1/400.02 157156 Proportionaldruckregelventil pressure control valve temperature-management 5
=HF+E1-16Y6 =HF+C1/400.04 157156 Proportionaldruckregelventil pressure control valve temperature-management 6
=HF+E1-16Y7 =HF+C1/400.06 157156 Proportionaldruckregelventil pressure control valve temperature-management 7
=HF+E1-16Y8 =HF+C1/400.07 157156 Proportionaldruckregelventil pressure control valve temperature-management 8
=HF+E1-19A1 =HF+C1/505.07 189806 Desktop-PC, Windows 7 desktop pc
198292 Desktop-PC, Windows 7 mit RAID1
199336 Ersatzfestplatte Desktop PC (RAID1)
=HF+E1-19A2.1 =HF+C1/20.03 145113 keyboard
145114
=HF+E1-19A2.2 =HF+C1/20.04 144054 Trackball
=HF+E1-19A3 =HF+C1/20.07 142409
ups
=HF+E1-19A4 =HF+C1/20.03 140429
monitor
141360
=HF+E1-19A5 =HF+C1/20.02 30247 modem
=HF+E1-19A6 =HF+C1/20.00 109933 USB/Ethernet
=HF+E1-19A10 =HF+C1/900.06 control-panel
=HF+C1-21F1 =HF+C1/115.07 37420 supplyexhaust-air-flap
6EBSI2,5A-T Sicherung-G 2.5AT
=HF+C1-21K1 =HF+C1/115.01 6ETEM2-3 exhaust air on
=HF+E1-21B1 =HF+C1/115.04 6EBG00002 pressure switch exhaust air infeed
0 1 2 3 4 5 6 7 8 9
Page
=
DD
HF
=HF+DD/13
12
Modification Date
Name Norm
Check.
Proj.
Origin
Date
Crea. f.
ERSA
Hotflow 3/xx
18.06.2009
=HF+DD/11
133953-V00
Otto-Schott-Straße 5
97877 Wertheim
GmbH
Plant designation
Project name
14:15:2008.07.2010
+
file name (*.pdf)
133953-V00_100705
basic-project
-
Device list
Description
Device list
DIN_PSL_50_2_ERSA_LS1
Part numberPage/Path
=HF+E1-21B2 =HF+C1/115.04 6EBG00002 pressure switch exhaust air outlet
=HF+E1-21M1 =HF+C1/115.07 6KLS-MO-LF24-S exhaust-air-flaphood exhaust
=HF+C1-22A1 =HF+C1/30.06 147780 emergencyoff device
=HF+C1-22F1 =HF+C1/30.02 6EBSI2,0A-T supply emergency stop
37420
=HF+C1-22K1 =HF+C1/30.07 6ETEM2-3 power on
=HF+C1-22K2 =HF+C1/30.08 6ETEM2-3 power off
=HF+C1-22K3 =HF+C1/30.01 6ESÜB6S-30-01 emergency stop contactor 1400VAC/16A
=HF+C1-22K4 =HF+C1/30.02 6ESÜB6S-30-01 emergency stop contactor 2400VAC/16A
=HF+C1-22K5 =HF+C1/30.03 6ESÜB6S-30-01 emergency stop connecter 1 hood 24VDC/16A
=HF+C1-22K6 =HF+C1/30.04 6ESÜB6S-30-01 emergency stop connecter 2 hood 24VDC/16A
=HF+E1-22S1 =HF+C1/30.02 116412 emergency off switchfront on the left
=HF+E1-22S2 =HF+C1/30.03 116412 emergency off switchfront on right
=HF+E1-22S3 =HF+C1/30.04 116412 emergency stop bottom in the back left
=HF+E1-22S4 =HF+C1/30.05 116412 emergency stop bottom in the back right
=HF+E1-23H1 =HF+C1/35.01 141840 signal lamp green
141842
6ELEU-001F
165499 LED-Lampe grün 24V BA15D
=HF+E1-23H2 =HF+C1/35.02 141844 signal lamp blue
6ELEU-001F
165505 LED-Lampe blau 24V BA15D
=HF+E1-23H4 =HF+C1/35.04 141846 signal lamp redhorn
6ELEU-001F
165503 LED-Lampe rot 24V BA15D
=HF+E1-23H5 =HF+C1/35.03 141845 signal lamporange
6ELEU-001F
165504 LED-Lampe orange 24V BA15D
=HF+C1-24F1 =HF+C1/40.03 6EBSIA-16A-B1 supply hood-control
=HF+C1-24K1 =HF+C1/40.07 6ETEM2-4 Interf. Relais 24VDC 2 Wechsler interlocking hood
=HF+C1-24K2 =HF+C1/40.04 6ETEM2-3 hood control OK
=HF+E1-24A1 =HF+C1/40.02 172885 Gleichlaufregelung SCU, mit Freigabe (???)
199265 Gleichlaufregelung SCU, mit Freigabe
=HF+E1-24A2 =HF+C1/40.07 139998 terminal hood
=HF+E1-24M1 =HF+C1/40.02 6HUBMOT-002 hood motor infeed
=HF+E1-24M2 =HF+C1/40.04 6HUBMOT-002 hood motor outlet
=HF+E1-24M3 =HF+C1/40.05 6HUBMOT-002 hood motor middle
=HF+E1-24S1 =HF+C1/40.00 70598 Induktiver Sensor M12x1 bündig 4,0mm hood switchhood closesd =1
0 1 2 3 4 5 6 7 8 9
