PLC-diagram
PLC
I/O
Function text
terminal
133953-V00
Project
PLC Designation sheet
Modul Modul
DIN_SPS_DIA_ERSA_LS
I/O-Info
=HF+C1-A2 IF6.ST2.DI.01 =HF+C1/135.08 thermo control fan top
DI1 0 2
11
=HF+C1-A2 IF6.ST2.DI.02 =HF+C1/140.08 thermo control fan bottom side
DI2 0 2
21
=HF+C1-A2 IF6.ST2.DI.03 =HF+C1/175.08 exceed temperatur switch off heatings
DI3 0 2
12
=HF+C1-A2 IF6.ST2.DI.04 =HF+C1/150.08 thermo control cooling zone
DI4 0 2
22
=HF+C1-A2 IF6.ST2.DI.05 =HF+C1/425.01 sensoric ISEL 1
DI5 0 2
13
=HF+C1-A2 IF6.ST2.DI.06 =HF+C1/10.00 ups Malfunction
DI6 0 2
23
=HF+C1-A2 IF6.ST2.DI.07 =HF+C1/10.01 ups Voltage supply
DI7 0 2
14
=HF+C1-A2 IF6.ST2.DI.08 ups main switch on
DI8 0 2
24
=HF+C1-A2 IF6.ST2.DO.01 =HF+C1/35.01 signal light green
DO1
0 2
15
=HF+C1-A2 IF6.ST2.DO.02 =HF+C1/35.02 signal light blue
DO2
0 2
25
=HF+C1-A2 IF6.ST2.DO.03 =HF+C1/35.04 signal light red
DO3
0 2
16
=HF+C1-A2 IF6.ST2.DO.04 =HF+C1/35.03 signal light orange
DO4
0 2
26
0 1 2 3 4 5 6 7 8 9
Page
=
+
DE
HF
=HF+DE/4
3
Modification Date
Name Norm
Check.
Proj.
Origin
Date
Crea. f.
Hotflow 3/xx
18.06.2009
=HF+DE/2
133953-V00
Otto-Schott-Straße 5
97877 Wertheim
GmbH
Plant designation
Project name
ERSA
14:15:2108.07.2010
PLC-diagram
PLC
I/O
Function text
terminal
133953-V00
Project
PLC Designation sheet
Modul Modul
DIN_SPS_DIA_ERSA_LS
I/O-Info
=HF+C1-A3 IF6.ST3.DO.01 =HF+C1/65.07 chain-oiler 1 on
DO1
0 3
11
=HF+C1-A3 IF6.ST3.DO.02 =HF+C1/110.01 center support 1 on
DO2
0 3
21
=HF+C1-A3 IF6.ST3.DO.03 =HF+C1/40.07 hood interlocking
DO3
0 3
12
=HF+C1-A3 IF6.ST3.DO.04 =HF+C1/210.01 fan top switched on
DO4
0 3
22
=HF+C1-A3 IF6.ST3.DO.05 =HF+C1/210.02 fan bottom side switch on
DO5
0 3
13
=HF+C1-A3 IF6.ST3.DO.06 =HF+C1/210.03 fan cooling zone switch on
DO6
0 3
23
=HF+C1-A3 IF6.ST3.DO.07 =HF+C1/210.09 heating contactor on
DO7
0 3
14
=HF+C1-A3 IF6.ST3.DO.08 =HF+C1/370.05 controled cooling zone semiconductor relay
DO8
0 3
24
=HF+C1-A3 IF6.ST3.DO.09 =HF+C1/380.00 cold water cooling unit internal on
DO9
0 3
15
=HF+C1-A3 IF6.ST3.DO.10 =HF+C1/205.04 heating zone 8 bottom sidesemiconductor relay DO10
0 3
25
=HF+C1-A3 IF6.ST3.DO.11 =HF+C1/205.05 heating zone 9 bottom sidesemiconductor relay DO11
0 3
16
=HF+C1-A3 IF6.ST3.DO.12 =HF+C1/205.06 heating zone 10 bottom sidesemiconductor relay DO12
0 3
26
0 1 2 3 4 5 6 7 8 9
Page
=
+
DE
HF
=HF+DE/5
4
Modification Date
Name Norm
Check.
Proj.
Origin
Date
Crea. f.
Hotflow 3/xx
18.06.2009
=HF+DE/3
133953-V00
Otto-Schott-Straße 5
97877 Wertheim
GmbH
Plant designation
Project name
ERSA
14:15:2108.07.2010
PLC-diagram
PLC
I/O
Function text
terminal
133953-V00
Project
PLC Designation sheet
Modul Modul
DIN_SPS_DIA_ERSA_LS
I/O-Info
=HF+C1-A4 IF6.ST4.DO.01 =HF+C1/190.01 heating zone 1 topsemiconductor relay
DO1
0 4
11
=HF+C1-A4 IF6.ST4.DO.02 =HF+C1/190.02 heating zone 2 topsemiconductor relay
DO2
0 4
21
=HF+C1-A4 IF6.ST4.DO.03 =HF+C1/190.03 heating zone 3 topsemiconductor relay
DO3
0 4
12
=HF+C1-A4 IF6.ST4.DO.04 =HF+C1/190.04 heating zone 4 topsemiconductor relay
DO4
0 4
22
=HF+C1-A4 IF6.ST4.DO.05 =HF+C1/190.05 heating zone 5 topsemiconductor relay
DO5
0 4
13
=HF+C1-A4 IF6.ST4.DO.06 =HF+C1/190.07 heating zone 6 topsemiconductor relay
DO6
0 4
23
=HF+C1-A4 IF6.ST4.DO.07 =HF+C1/190.08 heating zone 7 topsemiconductor relay
DO7
0 4
14
=HF+C1-A4 IF6.ST4.DO.08 =HF+C1/200.04 heating zone 8 topsemiconductor relay
DO8
0 4
24
=HF+C1-A4 IF6.ST4.DO.09 =HF+C1/200.05 heating zone 9 topsemiconductor relay
DO9
0 4
15
=HF+C1-A4 IF6.ST4.DO.10 =HF+C1/200.06 heating zone 10 topsemiconductor relay DO10
0 4
25
=HF+C1-A4 IF6.ST4.DO.11 =HF+C1/195.07 heating zone 6 bottom sidesemiconductor relay DO11
0 4
16
=HF+C1-A4 IF6.ST4.DO.12 =HF+C1/195.08 heating zone 7 bottom sidesemiconductor relay DO12
0 4
26
