3.1 PanaProtocol Description
E35HEC-4A-151-B0
3.1-1
3.1. PanaProtocol Description
E35HEC-4A-151-B0
3.1.1 PanaProtocol Description
This chapter describes the data format of PanaProtocol LAN communication.
Information in this chapter are not necessary if the customer uses our host system software, but they are
required when structuring customer’s own host system.
The PanaProtocol LAN uses the socket communications method. It is a widespread technology for
general-purpose OS such as Windows and UNIX.
The PanaProtocol LAN uses the Winsock standard to accomplish communication.
In socket communication, computers are classified into server and client.
To perform communication between host computer and machine, set the computer on the machine side as
server to wait access from the host computer set as client
Socket communication physically uses a single LAN cable, while the PanaProtocol LAN has two logical
connections dedicated to C commands and R commands respectively, and different port numbers are
assigned to them.
This enables any R commands occurred during C command communication to be notified correctly.
Also, to increase communications speed during program download/upload, all lines of a program are
transferred in block.
Item Description Remarks
Protocol TCP/IP Socket method
Port No. 2 ports used for C commands
and R commands respectively.
Must not duplicate with other socket applications.
Port 1 (for C commands): 49152
Port 2 (for R commands): 49153
Client/server ‘Client’ -- Host computer
‘Server’ -- Machine
Socket
communication
Messages conform to
Panaprotocol
STX, ETX and check sum are not used.
